Keychron M4 - Wireless Mouse Manual

Overview

Overview

  1. Left button
  2. Right button
  3. Middle wheel button
  4. Forward button
  5. Backward button
  6. Mouse Indicator
  7. DPI button
  8. Modes toggle
  9. Report rate button
  10. 2.4GHz Type-A receiver

Modes of connection

Wired Mode

  1. When the mode switch is in "OFF"position, the mouse won't respond if the cable is not connected
  2. Connect the cable to the Type-C port of the mouse and the USB port on the device. The mouse is ready to use while the backlit lights up.
    *When connected by cable, the mode will default to wired mode even if the toggle is in Bluetooth mode or 2.4GHz mode.
    Wired Mode of connection

2.4GHz Mode

  1. Switch to "G" mode (2.4GHz mode), and the mouse will automatically turn on 2.4GHz paring. The mouse indicator will slowly flash green.
  2. Find the 2.4GHz receiver and connect it to the device's USB/Type-C port. Once successfully connected, the mouse indicator will turn green and stay on for 3 seconds, then dims off.
  1. In 2.4GHz paring mode, the mouse indicator will slowly blink green for 3 minutes. If it's not connected within 3 minutes, the indicator will turn off. If you need to reconnect, hold both the "Left button + Forward button" for 4 seconds to re-enter pairing mode.
    *If you need to repair the connection in 2.4GHz mode, please unplug the 2.4GHz receiver first. Then, hold both the "Left button + Forward button" for 4 seconds, wait for the green light indicator to start flashing, and plug the 2.4GHz receiver back in to complete the pairing process.

Note: It is recommended that when pairing the M4 in 2.4GHz mode, the mouse should be within 20cm of the receiver.
2.4GHz Mode - Step 1
2.4GHz Mode - Step 2
2.4GHz Mode - Step 3
Note: For the best wireless experience, we recommend using the extension adapter for receiver and putting the 2.4GHz receiver somewhere on your desk close to your mouse for a lower rate of latency and fewer signal interferences.

Bluetooth mode

  1. Switch to "B" Mode (Bluetooth), and the mouse will automatically turn on Bluetooth pairing mode. The mouse indicator will slowly flash blue.
  2. Open the Bluetooth settings, search for a device named "Keychron M4" then click "connect" to complete paring.
  3. When in Bluetooth pairing mode, the mouse indicator will slowly blink in blue for 3 minutes. If it's not connected within 3 minutes, the mouse indicator will turn off. If you need to reconnect, you need to hold the "Left button + Forward button" for 4 seconds to re-enter pairing mode. The mode indicator will slowly blink blue.
  4. If the mouse is in Bluetooth mode and needs to pair with a new device, hold both the "Left button + Forward button" for 4 seconds and wait for the blue light to flash on. At this point, Bluetooth has re-entered pairing mode, and you can connect the new device to the M4.
    Bluetooth mode

Status indicator

2.4GHZ Mode * The mouse indicator slowly blinks green - Ready to be paired.
* The mouse indicator quickly blinks green - Pairing with the previous device.
Bluetooth Mode * The mouse indicator slowly blinks blue - Ready to be paired.
* The mouse indicator quickly blinks blue - Pairing with the previous device.
Low power The mouse indicator will slowly blink red.

DPI indicator

White light 400 DPI
Green light 800 DPI
Blue light 1600 DPI (default)
Orange light 3200 DPI
Red light 5000 DPI

Report Rate indicator

Report Rate indicator

White light 125hz (Default in Bluetooth mode)
Blue light 500hz
Red light 1000hz (Default in wired & 2.4GHz mode)

How to factory reset

Hold down the "DPI" button and "Report Rate" button for 4 seconds, and all the LED lights on the mouse will blink. It will blink three times to indicate that the factory reset is successful.
How to factory reset

Auto-Sleep mode

Auto-Sleep mode will not be activated when in wired mode. When in 2.4GHz mode or Bluetooth mode, the mouse will go to Auto-Sleep mode after 15 minutes of sitting idle to save the battery. Move or click the mouse to wake it up.

Driver Software

The Keychron M4 mouse driver can be downloaded from www.keychron.com. If the driver software can't connect to the mouse, please contact us for technical support.

Charging indicator explanation

Fully charged The mouse indicator will stay GREEN.
Low Power The mouse indicator will slowly blink RED.
  • The mouse is compatible with all USB ports. For the best signal and charging speed, connecting to the USB 3.0 port is recommended when charging or in use.
  • If the mouse is connected by the USB Type-C cable when charging but not paired with any devices:
    • The mouse indicator will stay RED when charging.
    • The mouse indicator will stay GREEN when fully charged

Note: The product supports up to 5V charging voltage and 150 mA charging current. We are not responsible for any problems caused by improper recharging.

What's in the box

Mouse x 1
Type-C to Type-C cable x1
User manual x1
Type - A to Type-C adapter x1
Type-C receiver x1
2.4 GHz Type-A receiver x 1
Extension Adapter x 1

Mouse specification

Size: 86*54'32 mm
Weight: 35 ± 3g
Report Rate (polling rate):125 Hz (White) - 500Hz (Blue) - 1000Hz (Red)
Sensor: PixArt 3395
Resolution: 100-26000DPI
Mouse micro switches: Huano Micro Switch (80 million clicks life time)
2.4GHz / Bluetooth connection range: Approx 10m of open space
Battery capacity: 300 mAh
Usage duration: 67 Hours (1000 Hz)
Recharge time: 2 Hours
Charging port: USB Type- C
Connection mode: 2.4GHz - Bluetooth - Wired
Device name: Keychron M4

Keychron, Inc.
Dover, DE 19901, United States

Find us at:
https://www.keychron.com
Support@keychron.com
@keychron
@keychronMK

Designed by Keychron
Made in China
