M3 WIRELESS MOUSE USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the M3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Keychron M3

Summary of Contents for Keychron M3

  • Page 1 M3 WIRELESS MOUSE USER MANUAL...
  • Page 3 Type - A Type - C Middle wheel button RGB light effects button Modes toggle Report rate button 2.4GHz Type - A receiver 2.4GHz Type - C receiver - 1 -...
  • Page 4 3 Modes of connection 1. When the mode switch is in "OFF" position, the mouse won't respond if the cable is not connected. Connect the cable to the TYPE-C port of the mouse and the USB port on the device. The mouse is ready to use while the backlit lights up.
  • Page 5 RGB light effects button" for 4 seconds, wait for the green light indicator to start flashing, and plug the 2.4GHz receiver back in to complete the pairing process. Note: It is recommended that when pairing the M3 in 2.4GHz mode, the mouse should be within 20cm of the receiver. G = 2.4GHz mode Note: For the best wireless experience, we recommend using the cable and putting the 2.4GHz receiver somewhere on your...
  • Page 6 4 seconds to re-enter pairing mode. The mode indicator will slowly blink blue. 4. If the M3 is in Bluetooth mode and needs to pair with a new device, hold both the "Left button + RGB light effects button" for 4 seconds and wait for the blue light to flash on.

  • Page 7: Status Indicator

    Status indicator When the indicator on the side of the mouse wheel: *Slowly blinks green - Ready to be paired. *Quickly blinks green - Pairing with the previous device. When the indicator on the side of the mouse wheel: *Slowly blinks blue - Ready to be paired. *Quickly blinks blue - Pairing with the previous device.

  • Page 8: How To Factory Reset

    Report Rate indicator *Report Rate = Polling Rate How to factory reset Hold down both the "DPI button" and "Report rate button" for 4 seconds, and all the LED lights on the mouse will blink. It will blink three times to indicate that the factory reset is successful. simultaneously hold for 4 seconds (starts factory reset) - 6 -...

  • Page 9: Auto-Sleep Mode

    Auto-Sleep mode after 15 minutes of sitting idle to save the battery. Move or click the mouse to wake it up. The Keychron M3 mouse driver can be downloaded from www.keychron.com. If the driver software can't connect to the mouse, please contact us for technical support.
  • Page 10 The RGB backlit on the side of the mouse wheel will light up GREEN for 5s and then resume its previous light effects. The RGB backlit on the side of the mouse wheel will slowly blink RED. * The mouse is compatible with all USB ports. For the best signal and charging speed, connecting to the USB3.0 port is recommended when charging or in use.

  • Page 11: What's In The Box

    Report Rate(polling rate): 125(White) - 500(Blue) - 1000(Red) Sensor: PixArt 3395 Recharge time: 2.5 Hours Resolution: 100 - 26000DPI Mouse micro switches: Kailh GM8.0 (80 million clicks life time) 2.4GHz / Bluetooth connection range: Approx 10m of open space Device name: Keychron M3 - 9 -...
  • Page 12 - 10 -...
