  • Page 1 Products Solutions Services KA01474D/06/EN/02.24-00 71638101 2024-01-31 Brief Operating Instructions Flowmeter Proline Prosonic Flow P Ultrasonic time-of-flight sensor These Brief Operating Instructions are not a substitute for the Operating Instructions pertaining to the device. Brief Operating Instructions Part 1 of 2: Sensor Contain information about the sensor.
  • Page 2 Flowmeter Proline Prosonic Flow P Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
  • Page 3 Flowmeter Proline Prosonic Flow P Brief operating instructions Flowmeter Brief operating instructions Flowmeter The device consists of a transmitter and a sensor. The process of commissioning these two components is described in two separate manuals which together form the Brief Operating Instructions for the flowmeter: •...

  • Page 4: Table Of Contents

    Table of contents Flowmeter Proline Prosonic Flow P Table of contents About this document ............. . 5 Symbols used .

  • Page 5: About This Document

    Flowmeter Proline Prosonic Flow P About this document About this document Symbols used 1.1.1 Safety symbols DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury.

  • Page 6: Basic Safety Instructions

    Basic safety instructions Flowmeter Proline Prosonic Flow P Symbol Meaning Potential equalization connection (PE: protective earth) Ground terminals that must be connected to ground prior to establishing any other connections. The ground terminals are located on the interior and exterior of the device: •...

  • Page 7: Intended Use

    Flowmeter Proline Prosonic Flow P Basic safety instructions Intended use Application and media The measuring device described in these Operating Instructions is intended only for the flow measurement of liquids. Depending on the version ordered, the measuring device can also measure potentially explosive, flammable, poisonous and oxidizing media.

  • Page 8: Product Safety

    Incoming acceptance and product identification Flowmeter Proline Prosonic Flow P Product safety This measuring device is designed in accordance with good engineering practice to meet state- of-the-art safety requirements, has been tested, and left the factory in a condition in which it is safe to operate.

  • Page 9: Product Identification

    Date: Is the envelope present with accompanying documents? • If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center. • The Technical Documentation is available via the Internet or via the Endress+Hauser Operations app. Product identification The following options are available for identification of the device: •...

  • Page 10: Storage And Transport

    Storage and transport Flowmeter Proline Prosonic Flow P Order code: Ser. no.: Ext. ord. cd.: Order code: Ser. no.: Ext. ord. cd.: A0030196  1 Example of a nameplate Order code Serial number (Ser. no.) Extended order code (Ext. ord. cd.)
  • Page 11 Flowmeter Proline Prosonic Flow P Mounting procedure 5.1.1 Mounting position Mounting location A0042039 Orientation Down Down A0041970  2 Orientation views Channel 1 upstream Channel 1 downstream Recommended orientation with upward flow direction Non-recommended installation range with horizontal orientation (60°) Recommended installation range max.
  • Page 12 Mounting procedure Flowmeter Proline Prosonic Flow P Horizontal In the recommended installation range with a horizontal orientation (View B), gas and air accumulations at the top of the pipe and inteference from deposit buildup at the bottom of the pipe can influence the measurement to a lesser degree.
  • Page 13 Flowmeter Proline Prosonic Flow P Mounting procedure 2 × DN 2 × DN 2 × DN 2 × DN 0…15 × DN 0…15 × DN 0…15 × DN A0053229  3 Inlet and outlet runs DN 50 to 4000 (2 to 160") Inlet and outlet runs DN 15 to 65 (½...
  • Page 14 Mounting procedure Flowmeter Proline Prosonic Flow P 3× DN 15 × DN 10 × DN 20 × DN 0…15 × DN 20 × DN 15 × DN 0…15 × DN 15 × DN A0053303  4 Inlet and outlet runs DN 50 to 4000 (2 to 160") Inlet and outlet runs DN 15 to 65 (½...
  • Page 15 Flowmeter Proline Prosonic Flow P Mounting procedure 5.1.2 Environmental and process requirements Ambient temperature range For detailed information on the ambient temperature range, see the Operating Instructions for the device. If operating outdoors: • Mount the measuring device in a shady location.

  • Page 16: Mounting The Measuring Device

    Mounting procedure Flowmeter Proline Prosonic Flow P SW 2.5 5 (0.2) min. 15 (0.6) A0029799 Cover borehole for the securing screw Securing screw to lock the cover Mounting the measuring device 5.2.1 Required tools For transmitter Proline 500 For mounting on a post:...
  • Page 17 High-temperature applications (> 170°C) • Order code for "Process temperature", options H, I, J • Installation for high-temperature applications may only be performed by Endress +Hauser staff or by individuals authorized and trained by Endress+Hauser. Notes on mounting Mounting the high-temperature sensors CH-050/CH-100 For detailed information on mounting the CH-050/CH-100 high-temperature sensors (order code for "Sensor version", options AG, AH), see Special Documentation on "High-...
  • Page 18 Mounting procedure Flowmeter Proline Prosonic Flow P Sensor configuration and settings DN 15 to 65 (½ to 2½") DN 50 to 4000 (2 to 160") Strapping band Strapping band Welded bolt 2 traverses 1 traverse 2 traverses 1 traverse 2 traverses...
  • Page 19 Flowmeter Proline Prosonic Flow P Mounting procedure A0043369  6 Holder with U-shaped screws Sensor holder CAUTION Damage to the plastic, copper or glass pipes due to overtightening the nuts of the U- shaped screws! ‣ The use of a metal half-shell (on the opposite side of the sensor) is recommended for plastic, copper or glass pipes.
  • Page 20 Mounting procedure Flowmeter Proline Prosonic Flow P Wrap the strapping bands around the sensor holder and measuring pipe without twisting them.  A0043371  7 Position the sensor holder and fit the strapping bands. Sensor holder Guide the strapping bands through the strapping band locks.
  • Page 21 Flowmeter Proline Prosonic Flow P Mounting procedure Push down the tensioning screw and tighten the strapping bands so they cannot slip.  A0043372  8 Tighten the tensioning screws of the strapping bands. If necessary, shorten the strapping bands and trim the cut edges.
  • Page 22 Mounting procedure Flowmeter Proline Prosonic Flow P Push down the tensioning screw and tighten strapping band 1 so it cannot slip. Strapping band 2: proceed as for strapping band 1 (steps 1 to 6). Slightly tighten strapping band 2 for final assembly. It must be possible to move strapping band 2 for final alignment.
  • Page 23 Flowmeter Proline Prosonic Flow P Mounting procedure Sensor holder with strapping bands (large nominal diameters) ) Can be used for • Measuring devices with measuring range DN 50 to 4000 (2 to 160") • Mounting on pipes DN > 600 (24") •...
  • Page 24 Mounting procedure Flowmeter Proline Prosonic Flow P Position the two strap bolts on strapping band 1, arranging them at a half circumference in relation to one another (180° arrangement, e. g. 7:30 o' c lock and 1:30 o' c lock) or quarter circumference (90° arrangement, e.g. 10 o' c lock and 7 o' c lock).
  • Page 25 Flowmeter Proline Prosonic Flow P Mounting procedure A0043374  11 Holder with strapping bands (large nominal diameters) Strap bolt with guide* Strapping band* Tensioning screw *The distance between the strap bolts and strapping band lock must be at least 500 mm (20 in).
  • Page 26 Mounting procedure Flowmeter Proline Prosonic Flow P 13 mm A0043375  12 Holder with welded bolts Welding seam Locking nut Hole diameter max. 8.7 mm (0.34 in) Installing sensor – small nominal diameters DN 15 to 65 (½ to 2½") Requirements •...
  • Page 27 Flowmeter Proline Prosonic Flow P Mounting procedure Procedure: Set the distance between the sensors to the value determined for the sensor distance. Press the movable sensor down slightly to move it.  A0043376  13 Distance between sensors as per the installation distance →  17...
  • Page 28 Mounting procedure Flowmeter Proline Prosonic Flow P Attach the sensor housing to the sensor holder by locking the bracket into place.  A0043378  15 Fastening the sensor housing Connect the sensor cable to the adapter cable.  This completes the mounting procedure. The sensors can be connected to the transmitter via the connecting cables.
  • Page 29 Flowmeter Proline Prosonic Flow P Mounting procedure Material The following material is required for mounting: • Two strapping bands incl. mounting bolts and centering plates where necessary (already pre-assembled →  21, →  23) • Two measuring wires, each with a cable lug and a fixer to fix the strapping bands •...
  • Page 30 Mounting procedure Flowmeter Proline Prosonic Flow P Take the still movable strapping band 2, including the mounting bolt, and move it until both measuring wires are evenly tensioned and then tighten strapping band 2 so that it cannot slip. Then check the sensor distance from the middle of the strapping bands. If the distance is too small, release strapping band 2 again and position it better.
  • Page 31 Flowmeter Proline Prosonic Flow P Mounting procedure Check distance B.  d / 2 ‘ / 2 d ‘ / d / 2 A0052445  18 Positioning the strapping bands and mounting bolts with a tape measure (steps 2 to 4)
  • Page 32 Mounting procedure Flowmeter Proline Prosonic Flow P Stick the coupling pad under the sensor . Alternatively, coat the contact surfaces of the sensor evenly with coupling gel (approx. 1 mm (0.04 in)). In doing so, start from the groove through the center to the opposite edge.
  • Page 33 Flowmeter Proline Prosonic Flow P Mounting procedure Insert the sensor cable into each individual sensor until the end stop.  A0043383  21 Mounting the sensors and connecting the sensor cables This completes the mounting procedure. The sensors can now be connected to the transmitter via the sensor cables and the error message can be checked in the sensor check function.
  • Page 34 Mounting procedure Flowmeter Proline Prosonic Flow P • Two sensors incl. connecting cables • Open-ended wrench (13 mm) • Screw driver Procedure: Position the strapping bands using the mounting rail [only DN50 to 600 (2 to 24"), for larger nominal diameters, measure the distance between the center of the strap bolts...
  • Page 35 Flowmeter Proline Prosonic Flow P Mounting procedure Place the coupling pad under the sensor . Alternatively, coat the contact surfaces of the sensor evenly with coupling gel (approx. 1 mm (0.04 in)). In doing so, start from the groove through the center to the opposite edge.
  • Page 36 Mounting procedure Flowmeter Proline Prosonic Flow P Insert the sensor cable into each individual sensor until the end stop and tighten the locking nut.  A0043386  24 Mounting the sensors and connecting the sensor cables This completes the mounting procedure. The sensors can now be connected to the transmitter via the sensor cables and the error message can be checked in the sensor check function.
  • Page 37 Flowmeter Proline Prosonic Flow P Mounting procedure Wall mounting Required tools Drill with drill bit ⌀ 6.0 mm 18 (0.71) 10 (0.39) 20 (0.79) 100 (3.94) A0029068  25 Engineering unit mm (in) Endress+Hauser...
  • Page 38 Mounting procedure Flowmeter Proline Prosonic Flow P Pipe mounting Required tools Open-ended wrench AF 13 WARNING Order code for "Transmitter housing", option L "Cast, stainless": cast transmitters are very heavy. They are unstable if they are not mounted on a secure, fixed post.
  • Page 39 Flowmeter Proline Prosonic Flow P Mounting procedure – – 3 mm 4 mm 7 Nm (5.2 lbf ft) A0029993  27 Non-Ex housing Depending on the device version: Loosen the securing clamp of the connection compartment cover. Unscrew the connection compartment cover.

  • Page 40: Post-Mounting Check

    Mounting procedure Flowmeter Proline Prosonic Flow P Turn the housing to the desired position. Tighten the securing screws. 5.2.7 Turning the display module The display module can be turned to optimize display readability and operability. – – – 3 mm...

  • Page 41: Disposal

    Flowmeter Proline Prosonic Flow P Disposal Is the tag name and labeling correct (visual inspection)?  Is the device sufficiently protected from precipitation and direct sunlight?  Are the securing screw and securing clamp tightened securely?  Is the sensor holder properly grounded (in the event of different potential between the sensor holder ...
