- Page 1 KCD-1000 KCD-1000 4-Way Money Detector...
- Page 2 While every effort has been made to include all features into this user manual, specifications stated may not reflect all the features of the later software versions. If you have questions about your KCD-1000 and its operation, please contact technical support at www.kolibriusa.com/contact/. DO NOT DISPOSE WARNING: HAZARDOUS CHOKING HAZARD.
-
Page 3: Table Of Contents
1. INTRODUCTION 1.1 About the KCD-1000 _____________________________________________________1 1.2 Important Safety Notes ___________________________________________________1 1.3 Box Contents ____________________________________________________________2 1.4 Specifications ____________________________________________________________2 1.5 Views of the KCD-1000 __________________________________________________3 1.6 Membrane ______________________________________________________________4 2. GETTING STARTED 2.1 Powering Up ____________________________________________________________5 2.2 Checking a Bill’s Condition _______________________________________________5 2.3 Inserting the Bill _________________________________________________________5... -
Page 4: Introduction
About the KCD-1000 Thank you for choosing the KCD-1000 4-way money detector. The KCD-1000 is an automatic and powerful tool for identifying suspected counterfeit bills. With its advanced sensors, the KCD-1000 verifies UV signatures, magnetic marks and double notes with infrared. -
Page 5: Box Contents
Box Contents KCD-1000 4-Way Money Detector AC/DC Power Adapter User Manual Cleaning Brush 1.4 Specifications Weight: 0.95 lbs (0.43 kg) Dimensions: 6.3” x 5.1” x 3.6” (160mm x 130mm x 92mm) Sensors: Ultraviolet (UV), Magnetic (MG), Infrared (IR) Power Supply AC/DC adapter, 5V 2000mA Power Consumption: 3.5W... -
Page 6: Views Of The Kcd-1000
Views of the KCD-1000 TOP VIEW Membrane Front Slot BACK VIEW Rear Slot Power Switch Micro USB Port Power Input Jack... -
Page 7: Membrane
Membrane MEMBRANE Function Display Displays PASS or FAIL message Light Indicators Shows GREEN light for PASS or RED light for FAIL... -
Page 8: Getting Started
Inserting the Bill The KCD-1000 is a 4-way detector, meaning that bills can be inserted in any 4 possible orientations. After the bill is positioned in the insertion slot properly and aligned in the middle, the detector will automatically feed and scan the bill. -
Page 9: Pass/Fail Mode
PASS/FAIL Mode Pass/Fail mode displays if the bill is recognized or not with a clear PASS and FAIL message on the screen. BILL RECOGNIZED BILL NOT RECOGNIZED... -
Page 10: Maintenance And Troubleshooting
Note: that several factors can cause a KCD-1000 to not recognize a genuine bill: Overly wrinkled, overly creased and overly worn bills If the unit is dropped or bumped... -
Page 11: Troubleshooting
Unit does not read the bills or fails to Turn off the unit. Open lid. Use an air duster or soft detect counterfeit brush to clean the interior sensors of the KCD-1000. See section 5.1 ‘’MAINTENANCE’’ Close lid tightly. Turn unit on. -
Page 12: Warranty
Warranty The KCD-1000 is warrantied for a period of one year from the date of purchase. In most cases a unit malfunction can easily be corrected by performing a thorough cleaning. • Customer should allow the manufacturer the time and opportunity to test and diagnose the machine to determine warranty and non-warranty claims •... -
Page 13: Contact Information
Contact Information Technical Support contact information: http://kolibriusa.com/contact/ When contacting Technical Support, please have the following available: • Product Model – Located on the bottom of the machine. • Serial Number – Located on the bottom of the machine. • Nature of the problem – What happened, and when did it happen? Did the machine display an error message? - Page 14 Kolibri ©2018 Printed in China. Specifications subject to change without notice. www.KolibriUSA.com FNKCD1000072018...
