Installation Preparation Document
Xerox DocuTech 6100/6115/6135
Physical requirements
The DocuSP Controller Monitor and Keyboard are designed to
be positioned on top of the DocuTech 61XX printer. The
controller platform is designed to either be mounted in a stand to
the left of the printer, or to be positioned on the floor to the left of
the printer.
Warning: Due to safety requirements, under no circumstances
should the user interface be visually separated from the printer
module. All system installations must enable mobility of the user
interface to within 30" (760 mm) of the printer for service and
customer maintenance actions
Environmental Requirements
Temperature
Humidity
Heat Emission - with
Binder On
Heat Emission - with
Binder Off
Power Consumption
Printer/Finisher w/ Binder
On
Power Consumption
Printer/Finisher w/Binder
Off
* The system will inhibit software problems and shut down above 90
F
Operating Supplies
Reorder No.
Dry Ink
Developer
Fuser Agent
Stitcher Wire
Binder Tape - Black
Binder Tape – White
Binder Tape – Gray
Binder Tape – Blue
Binder Tape – Brown
Binder Tape – Red
The Xerox Supplies Marketing Center, 1.800.822.2200, is available
for ordering Xerox supplies, including paper and other thruput
material.
Network Requirements
The Ethernet interface on the DocuSP controller is a 10/100-
MB/sec twisted pair standard (10BaseT).
Please ensure electrical, space, and supplies are available prior to equipment delivery.
701P43857
June 2005
.
Min.
Max.
o
o
50
F
85
F *
30% RH
60% RH
22,165
14,185 BTU/Hr
BTU/Hr
(With Vent Kits)
21,265
13,609 BTU/Hr
BTU/Hr
(With Vent Kits)
1,330 Watts
5,890 Watts
(Standby)
(Running)
1,000 Watts
5,630 Watts
(Standby)
(Running)
Impressions / Unit
6R206
220K/Carton at 6%
area coverage
5R161
750K / Carton
8R2955
250K / Bottle
8R1174
32K / Roll
8R2928
425 Binds / Reel
8R3601
425 Binds / Reel
8R3602
425 Binds / Reel
8R3603
425 Binds / Reel
8R3604
425 Binds / Reel
8R3824
425 Binds / Reel
(for physical installation of the product only)
The Ethernet connection to the DocuSP controller must be
compatible with the Institute of Electrical and Electronics
Engineers (IEEE) 802.3 standard. (The physical form of this
connecter is RJ45 and must be correctly wired.)
The DocuSP controller supports TCP-IP, SPX,/IPX, and
EtherTalk Link Access Protocol (ELAP) protocols if the proper
gateways are installed on the controller.
The DocuSP controller does not provide Novell Server network
services. To use the SPX/IPX protocol, a Novell server installed
on the network is required.
A Xerox Token Ring solution is available for the 61XX family.
When Token Ring is installed, it becomes a Token Ring only
connectivity solution. The NetWare gateway and AppleTalk
gateway will not function, and the built in Ethernet bge0 twisted
pair interfaces are disabled. (Gigabit Ethernet is supported with
a Sun controller card – some customers have asked for this
option.)
Telephone Requirements
A voice telephone line is required where the DocuTech 6100, 6115,
6135, is installed.
Voice line will be used when the operator, administrator, or Xerox
Service Personnel is asked to read the screen information from the
DocuSP controller dialogs to Xerox Customer Support or Technical
Support Center Personnel.
Position / Performance at Maturity
8
7
6
o
Average
5
Monthly
4
Service
Calls
3
2
1
300K
Note:
This product is targeted for the 300K to 2M copies per month market
segment. Usage above this range may result in a higher service
frequency
Optimum Range
500K
1M
1.5M
Average Monthly Copy Volume
2M
