c. Mount one of the supplied connectors from bag D or E (page 7)
on the dirty water outlet (G) of the pressure filter.
Connect to this the PVC pipe that runs to the sewer, in the
garden (or elsewhere) for draining the dirty water when rinsing.
There is also the possibility to connect PVC threaded fittings with 2'' inch
female thread directly to the threaded connections of the pressure filter.
To do this, seal the threaded connection with Teflon tape.
•
Check that everything is connected properly
•
Before starting up the system to filter check that the backwash lever (H)
is in the FILTER position.
•
Put the pump into operation by plugging in the mains plug. When doing
so, observe the pump's instructions.
•
If there is no leakage, the pressure filter can also be switched on by
plugging in the mains plug. The UV can be turned on by setting the UV
timer switch (K) to position 12 or 24 hours.
Operation UV Timer Switch (K):
A UV-c lamp does not have to be on 24/7 all year round and in winter it can
even be turned off. By means of the UV timer switch (K) you can determine
the number of burning hours per 24 hours.
•
Make sure that the mains plug of the pressure filter is plugged in and the
pressure filter is powered.
•
Slide the UV timer switch (K) to position 12 or 24 hours. On top of the
pressure filter is a control window (J), here you can see blue light when
the UV-C lamp is working.
•
The hour timer starts the moment the UV-c is turned on (as named
above) and will then stay on for the number of hours set (0, 12 or 24
hours).
Setting 0:
Setting 12:
Setting 24:
If the UV-c does not work at setting 12 or 24, check to see if the
pressure filter is plugged in or check the UV-c bulb for breakage.
Flushing and maintenance:
(Figure 6, 8 to 19A, page 5, 8 to 13)
To ensure a long life and with trouble-free operation of the filter, we recommend
regular flushing and maintenance of the filter.
English
The UV-C lamp will not switch on.
The UV-c lamp will turn on and stay on for 12 hours
from the time it is turned on. After 12 hours, the UV-c
lamp will turn off for 12 hours and will turn on again
after these 12 hours.
A switch-on time on a day is not programmable, when
the power supply to the pressure filter is interrupted
and switched on again the UV-c will start again with the
number of burning hours.
The UV-c will run 24/7.
