DISPOSAL OF PACKAGING MATERIALS

After unpacking everything, ensure that the packaging material is properly disposed of. The disposal must conform to relevant
waste disposal laws valid in your country.
In the event that you are unsure about the disposal procedure, have this performed by a specialised company.
3.5 ASSEMBLY OF THE SEPARATELY PACKED ASSEMBLIES
Due to the technical nature of this task, the mower is prepared for operation by the vendor of your riding mower
(according to the following instructions).
Before starting the installation, remove all covering protective materials, locate the riding mower on an even surface
and align the front wheels to face forward.
3.5.1 STEERING WHEEL, SEAT AND BATTERY
a) Attach the seat:

Screw the attachment plate (1) to the underside of the seat. For this purpose, use four nuts (2) (M8×25).

Tilt out the seat console (3) by approximately 90° upwards.

Screw the seat with the attachment plate to the console using:
3.5.1a
- two upper lock nuts (4); for each nut, use two washer (ø 8.4)
- two bolts (5) (M8×25); for each bolt, use a washer (ø 8×12), washer (ø 8.4) and a spring washer (ø8)
b) Connect the cable of the safety switch:

In the event that the safety switch (6) was removed from the seat prior to transport, slide it into the hole on the
3.5.1b
underside of the mower and connect the electric cable (7) to it.
c) Install the steering wheel:
Steering wheel rod (1) has two holes enabling the steering wheel to be set to two heights. Select the hole based on
your body dimensions and individual preferences, put the steering wheel on to the rod and turn it so that the hole
3.5.1c
(2) in the steering wheel overlaps the selected hole in the rod. Then insert the pin (3) into the hole and knock it in
using a hammer.
d) Connect the battery:

Turn the lever of the storage space cover located under the steering wheel to open the cover and take it out.

Loosen the bolts on the pole terminals.

Red wire Place on the (+) pole of the battery and secure in place with the bolt.
3.5.1d 
Brown wire Place on the (-) pole of the battery and secure in place with the bolt.

Place the rubber caps on to both leads.

Put the storage space cover back and secure with the lever.
Bolts and rubber battery caps are located in the bag with the documentation and other joining material.
Connecting the wires in opposite to that described above will damage the mower.
When disconnecting the battery, always disconnect the negative (–) terminal of the battery first.
When putting the battery into operation and when performing maintenance on it, proceed according to the instructions
in the user's manual for the battery. Also follow all safety instructions contained therein.
e) Fit the bumper bar in the correct position:

Open the hood.

Slide the bumper bar consoles away from the seat – the correct position is clearly marked on the frame.
3.5.1e

Properly tighten the bolts of the consoles on both sides of the mower and close the hood.

3.5.2 GRASS CATCHER

The grass catcher is supplied packed in a separate box. For transportation reasons some of its parts are demounted and they first
need to be assembled. The following chapters provide a rough indication of their assembly.
