Safety Instructions & Operator's Manual for
21" STEEL DECK
WALK MOWERS
SERIES 19
Models
RP2167519BDV (7800066)
RP2187519BV (7800172)
RP2187519BVE (7800173)
RP216019KWV (7800199)
2167519B (7800217)
P2167519B (7800218)
P2187519BV (7800176)
P2187519BVE (7800178)
P216019KWV (7800193)
N2167519B (7800133)
NP2167519B (7800134)
NP2187519BV (7800131)
Manual No. 7101587 (I.R. 9/25/2007)
TP 100-5289-IR-WB-N
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Snapper NP2167519B
Summary of Contents for Snapper NP2167519B
- Page 1 Safety Instructions & Operator's Manual for 21” STEEL DECK WALK MOWERS SERIES 19 Models RP2167519BDV (7800066) RP2187519BV (7800172) RP2187519BVE (7800173) RP216019KWV (7800199) 2167519B (7800217) P2167519B (7800218) P2187519BV (7800176) P2187519BVE (7800178) P216019KWV (7800193) N2167519B (7800133) NP2167519B (7800134) NP2187519BV (7800131) Manual No. 7101587 (I.R. 9/25/2007) TP 100-5289-IR-WB-N...
-
Page 2: Product Registration
Serial Number ______________________________________________________________ Engine Model_________________________Type__________________Trim___________________ It is very important that you register your purchase with Snapper to ensure warranty coverage. Please mail your product registration card to: Snapper at P.O. Box 777, McDonough, Georgia 30253. Or you may register online at www.snapper.com. -
Page 3: Table Of Contents
Table of Contents Operator Safety ..........2 Important Operator Safety Instructions . -
Page 4: Operator Safety
If you have any questions pertaining to your machine which your dealer cannot answer to your satisfaction, call or write the Customer Service Department at SNAPPER, McDonough, Georgia 30253. Phone: (1-800-935-2967). Protection for Children Tragic accidents can occur if the operator is not alert to the presence of children. -
Page 5: Maintenance And Storage
10. DO NOT test for spark by grounding spark plug next to spark plug hole; spark plug could ignite gas exiting engine. 11. Have machine serviced by an authorized SNAPPER dealer at least once a year and have the dealer install any new safety devices. -
Page 6: Features And Controls
Features and Controls IMPORTANT The figures and illustrations in this manual are provided for reference only and may differ from your specific model. Contact your Snapper dealer if you have questions. Features and Controls Oil Fill Cap and Dipstick Fuel Filler Cap... -
Page 7: Starting And Operation
Operation Pre-Start Check List Make the following checks and perform the service required before each start-up. 1. Check the guards, deflectors, grass bag, adapter, and covers to make sure all are in place and securely tightened. 2. Check the blade control (A, Figure 1), wheel drive control (B), and ground speed control (C) to insure they work freely. -
Page 8: Propelling Mower
DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. www.snapper.com... -
Page 9: Cutting Height Adjustment
Operation (Continued) WARNING DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. Cutting Height Adjustment 1. -
Page 10: Installing The Discharge Deflector
(C) to the bracket on the bag adapter Lay the standoff between the bolt holes in the engine recoil and the bag adapter pulley bracket. (Position the standoff so that the bent end (D) is toward the engine recoil cover.) www.snapper.com... -
Page 11: Installing The Recycling Plug
Figure 15: Installing the grass bag WARNING Grass Catcher bags used on SNAPPER products are made of woven fabric, and are subject to deterioration and wear during normal usage. Check condition of bag before each use. Immediately replace worn or damaged catcher bags with only bags recommended by SNAPPER. -
Page 12: Maintenance
Maintenance Maintenance - Introduction To retain the quality of the mower, use genuine SNAPPER replacement parts only. Contact a local SNAPPER dealer for parts and service assistance. For the correct part or information for a particular mower, always mention the model and serial number. -
Page 13: Check Mower Blade
Maintenance (Continued) WARNING DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. Wear heavy leather gloves when handling or working around cutting blades. -
Page 14: Mower Blade Replacement
If contamination does occur, the air filter will have to be replaced. 3. Remove the blade (B, Figure 22). Figure 22: Removing the mower blade Make sure that blade hub is seated between flanges www.snapper.com... -
Page 15: Wheel Drive Control Adjustment
Maintenance (Continued) WARNING DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. Blade Sharpening (Continued) 4. -
Page 16: Driven And Drive Disc Service
If the drive disc and driven disc are clean and the mower drive is still slipping, adjust the driven disc as follows: 1. Move the ground speed control (A, Figure 27) into the ‘fast’ position. Figure 27: The ground speed control www.snapper.com... -
Page 17: Driven Disc Replacement
Maintenance (Continued) WARNING DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. Driven Disc Adjustment (Continued) 2. -
Page 18: Driven Disc Bearing Replacement
5. Install a new bearing and secure to the thrust plate with four retaining screws. Tighten the screws securely. 6. Reassemble the components in reverse order. NOTE: Be sure to replace the shim washer (D) when reassembling the driven disc assembly. Figure 32: Replacing the driven disc www.snapper.com... -
Page 19: Belt Service
Maintenance (Continued) WARNING DO NOT attempt any maintenance, adjustments or service with engine and blade running. STOP engine and blade. Disconnect spark plug wire and secure away from spark plug. Engine and components are HOT. Avoid serious burns, allow sufficient time for all components to cool. Replacing the Bearing On the Pulley End Of the Hex Shaft To replace the bearing on the pulley end of the hex shaft,... -
Page 20: Transmission Belt Replacement
5. Twist the belt sideways and pull it upward between the differential bracket (E) and driven pulley (F) and then down into the pulley groove. Make sure the Poly-V Belt is above the belt guide (G). Figure 36: Poly-v belt routing www.snapper.com... -
Page 21: Battery Service
Maintenance (Continued) Battery Service New Battery Preparation 1. Remove the battery from the carton. 2. Place the battery in a well ventilated area on a level non- concrete surface. 3. Remove the battery cell caps. Fill the cells as required with electrolyte (supplied with battery) to the proper level. -
Page 22: Service Schedule
Page 11 Engine Manual Engine Manual Engine Manual Engine Manual Page 11, 17 Page 12 Page 5 Page 10 Page 10 Page 13-16 EACH SEASON 7074460 7074138 7034608 7074141 7034604 7019795 7017168 7026691 7026407 7012354 7046784 7073528 7041855 7006149 7006150 www.snapper.com... -
Page 23: Troubleshooting
4. Replace belt. 1. Clean debris. 2. Clean or replace driven disc. 3. Replace drive belt. 4. Contact authorized SNAPPER dealer. 1. Adjust cutting height. 2. Move engine speed control to ‘Fast’ position. 3. Move ground speed control to a slower speed. -
Page 24: Warranty
For ninety (90) days from purchase date for the original purchaser’s commercial, rental, or other non-residential use, SNAP- PER, through any authorized SNAPPER dealer will replace, free of charge, any part or parts found upon examination by the factory at McDonough, Georgia, to be defective in material or workmanship or both. - Page 26 Notes www.snapper.com...
- Page 27 Notes...
-
Page 28: Product Specifications
(temperature, humidity, altitude), and engine-to-engine variability. Due to manufacturing and capacity limitations, Briggs & Stratton may substitute an engine of higher rated power for this Series engine. Snapper Products 535 Macon Street McDonough, GA 30253...
