Summary of Contents for Konka KDL55XS780AN

  • Page 1 KDL55XS780AN PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...
  • Page 2 SPECIFICATION.....................02 ADJUSTMENT INSTRUCTION................18 PROGURAM WRITING...................19 Appendix 2: debug introduction of network module part.........45 SVC.SHEET....................PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
  • Page 3 1 1 1 1 前言 前言 前言 前言 1.1 适用范围 本调试说明适用于 KDLxxXSxxxAN 液晶电视机。 1.Preface 1.1 Applicable area This test manual is applicable for KDLxxXSxxxAN LED TV. 1.2 调试注意事项及要求 1.2.1 请按下列调试步骤和指定的测试仪器进行调试,否则将不能调好电视机,为了保证满意 的测试结果,在调试中必须保证所指定的偏压值。 1.2.2 调试之前请务必戴好静电手套。 1.2.3 本调试说明适用于 KDL42XS712AN 及其他采用 MSD6369 平台的 KDLxxXSxxxAN 系列液晶电 视机。...
  • Page 4 4)彩色分析仪(Chroma Model 7120 或同类产品) 1 台 5)TV 视频信号发生器 FLUKE PM54200 1 台 6) 带工厂设置键的遥控器 1 个 7)AV,VGA, HDMI,YPbPr,专用 USB 线信号线等 1 套 8)DDC 卡彩富电子 D8330 1 片 9)UPM-USB 烧录器 1 台 10)EMMC 拷贝器 1 台 11)USB 接口红外扫描枪 1 支 12) 串号红外扫描软件 netfactory.exe 1 套...
  • Page 5 2. BOOTLOADER 烧 PC ,通用烧 详细内容请参考 5.0.0 录方法 录器 ,SO8 适 Please refer to appendix 5.0.0 配座 2.BOOTLOADER or follow the RD engineer PC,IC Burn method guidance. Programmer S08 IC adaptor 3. 软件程序烧录 详细内容请参考 5.1.0、 更新软件 5.6.0、5.8.0; 3.Software Please refer to appendix Upgrade 5.1.0、5.6.0、5.8.0 or follow the RD engineer guidance.
  • Page 6 and press "OK" button ,choos e “YES ” on the Confirm men u, the LED TV reset and restart.(on the process of pro ducing SKD,this step can be canceled,but make sure po wer on until the power logo was displayed on the first power on process ) 进入工厂区方法同上,在工厂...
  • Page 7 begin adjusting. Successful show "SUCCESS", failed show "FAIL", to be re- adjusted. (YPbPr channels generally do not have to adjust, use the default value can be; VGA channels such as making adjustments, please note that the adjusted R, G, B values should not be that much difference) �...
  • Page 8 � 在工厂菜单下,选择 a AV 下色温及亮、 视频信号发 输入 100% 灰阶信 “White Balance”,选 暗平衡调整 生器 号(11 阶) (FLUKE 择“TEMPERATURE/标 Input gray step a. AV: PM54200 signal (100%) 准”。调整菜单中两组 PM5418) Color R/G/B 值,使灰阶第 2 阶 彩色信号分 析仪 和第 8 阶色温坐标满足要 temperature 求(U’=0.189±0.015, Signal adjustment Generator, V’=0.447±0.015),即...
  • Page 9 get black calibration; Test the second gray step signal and the eleventh gray step signal and adjust R/G/B GAIN to get (U’=0.189 ± requirement. 0.015,V’=0.447±0.015), color temperature is 9300. � 在工厂菜单下,选择 c VGA 下 色 温 及 输入 100% 灰阶信 高清视频信...
  • Page 10 1. Enter User menu, Check whether the pictures normal or not, and snowflake points come forth in no signal background. It would enter standby state in 5 minutes if no signal inputs. Check Auto Search Manual Search 播放 DVD 画面清晰流畅 ,声音是否 �...
  • Page 11 clear and fluent, Audio checks if the output is normal. SAMSUNG HDMI Mode 参见附 表 5.6 DVD-HD948 选 SOURCE 选到 HDMI � 步 步 高 HDMI Mode 各 Mode 的画面均能正常 (或带 HDMI � 显示 , 画面清晰流畅 ,声 的 DVD) 音是否正常 HDMI Cable 13.
  • Page 12 播放。 Storage 1. Select SOURCE to the Device USB; 2. Insert U disk, should be able to quickly identify the corresponding letter the screen; 3. Select the file playing, should be able to play correctly 插上耳机,主喇叭无声,耳 � 机 声音正常,按 VOL+-,耳机 �...
  • Page 13 序号 项目 测试点 标准 电源 交流输入端电阻 交流输入连接器 无短路 The resistance of AC input AC input connector no short of the power module circuit 直流输出端电阻 直流输出连接器 无短路 The resistance of DC DC input connector no short output of the power module circuit 12V输出端电阻...
  • Page 14 4.3 信号处理板 4.3.1 信号处理板电源部分 4.3.1 Signal board power part 信号处理板电源分配图 Signal Board power distribution 1 0.16A 0.16A 1117-3.3 3.3Vstb 5Vstb 0.3A(85%) 0.8A SY8087 +1.5V_DDR 3V3_Normal 0.3A 0.6A AP3502 AP2114 2.5V_Normal 0.9A 0.2A 1117-1.2 1.2V_Demod 0.4A 3V3_Normal(WiFi) 0.4A 1117-3.3 3.3V_Tun(3.3V_Demod) 2.5A 1.5A 2110 VUSB...
  • Page 15 4.3.3 Verify the state of TV set Set “ON/OFF” on the right side of the TV set to “ON” and verify the LED indicator’s color . If the LED color is red, TV is in standby state. If the LED color is green, TV is in working state.
  • Page 16 c) Check whether the backlight control signal (BKL_EN) of the 2th pin socket XS808 is high level (beyond 3V) or not, if not, check whether the backlight control circuit is open or short. 4.3.6 网络功能 a) 检查 TU01 供电电压 2.5V 是否正常。 b) 检查...
  • Page 17 output on the main board 2.5V端输出电阻 C860,L506 无短路 The resistance of 2.5V no short output on the main board PANEL 12V输出端电阻 C829 无短路 The resistance of 12v- no short Panel output on the main board 若有短路则为不良,检查线路找出短路处。 If there has short circuit, it’s unqualified, Check the circuit and find it . 4.4.2 检查供电电压...
  • Page 18 The resistance of 2.5V output on the main board PANEL 12V输出端 C829 The resistance of 12V – panel output on the main board 4.4.3 Bootloader 程序烧录办法 烧录方法请参照 5.0.0。 4.4.3 Bootloader programming method Please refer to appendix 5.0.0 4.4.4 EMMC 程序无法升级的可能原因及解决办法 a)、供电电压不正常:根据...
  • Page 19 Power on check 1)Please Use a multimeter to check voltage on the test point whether meet the requirement or not. 被测网络 电压 测试点 Tested net Test point voltage 3.3V_Tun 3.30 C104 2)测试时钟 用示波器测量测试晶体 Z110 是否有 16MHz 信号; 2)Test clock Use a oscilloscope test whether the crystal oscillator Z110 output 16mhz signal or not 3)信号测试,...
  • Page 20 Adjust R-GAIN 0-255X8 default:128X8 G-GAIN 0-255X8 default:128X8 B-GAIN 0-255X8 default:128X8 R-OFFSET 0-255X8 default:128X8 G-OFFSET 0-255X8 default:128X8 B-OFFSET 0-255X8 default:128X8 Set the coordinate of black, white Color Temperature as requirement value(X=0.285, Y=0.293). or use Automatic calibration instrument to auto adjust White Balance 程序拷贝...
  • Page 21 EMMC 主程序拷贝步骤 5.2 EMMC EMMC EMMC 5.2 EMMC main program writing step 一、打开烧录软件C-Ming UPM,界面如下: Open writing program C-Ming UPM ,interface like: 二、点击“IDENTIFY”,自动识别EMMC 芯片的参数和性能,如下图, Click “IDENTIFY”, identity the argument and performance of EMMC CHIP automatically as follow picture: 20 / 54...
  • Page 22 点击EXT_CSD,弹出数据框,查阅是否[167]为“1F”或者“01” ,如果是,按第四步操作;不 是则按第三步操作。 Click EXT_CSD, popup data frames , check whether[167]is “1F”or “01”.if it’s “1F”,go to step 4 otherwise go to step 3. 三、点击 “PARTITION”,弹出数据框,如下图 ,点击 “OK”,然后,重复第二步操作,确认 [167]值为“01” Click PARTITION, popup data frames,like follow picture, click ok. repeat step2.make sure the value of [167] is “01”.
  • Page 23 四,点击“AUTO” Click “AUTO” 5.3 烧录 HDCP KEY 和 MAC MAC 地址步骤 HDCP HDCP HDCP KEY 参见后面“附录 2:网络模块部分调试说明书-串号扫描软件使用说明”部分 5.3 the step of burn HDCPKEY and MAC address Refer to appendix 2 : “ network module debug instruction book- Series number scan software instruction”...
  • Page 24 and the other side connect to the VGA port on the main board . 2) Start MStar ISP Utility, click “Config”, set the parameter as follow picture: 3)点击 Read 按钮,选择要升级的 SpiFlash.bin 文件,如图所示: 3) Click read botton ,choose the file named “SpiFlash.bin” ,as follow picture. 4)打开电视机,然后再点击...
  • Page 25 xxx " or it show “Can’t find device type.” it mean connect unsuccessfully, need to click the button “Dis Con ”,then click “Connect” to try more times. Or restart the TV try again until success. 5)点击上方的 AUTO 按钮到烧录界面,再点击 RUN 按钮开始烧录 mboot 程序,当下方出 现 PASS是表示烧录成功。...
  • Page 26 5.6 通过 USB USB 升级程序 5.6.1 开机直接升级 5.6.1 5.6.1 5.6.1 mboot 1)开机直接升级 mboot mboot mboot 步骤 1、拷贝要升级的 mboot.bin 文件到 U 盘根目录下 步骤 2、把 U 盘插入电视机的 USB 口 步骤 3、将电视机处于断电状态 步骤 4、按住遥控器的 “音量减”键不要释放,然后给电视机上电,大概 10 秒钟后可以释放遥控 “音量减” 键,此时 mboot 已经在升级,升级完成后会自动重启(这个过程会比较快) 注意:步骤 4 4 4 4 的过程中确保不要给电视机断电 2)开机直接升级主程序...
  • Page 27 after 10s ,release “volume -”. The mboot is upgrading now, When upgrade is finished TV will Restar( this process is quickly). Attention : keep the TV power on at the step 4. 2). Main program upgrade directly when power on. Step 1.
  • Page 28 may take 15 minutes)( if it display power up logo quickly ,it mean upgrade failed, maybe missing the file- “MstarUpgrade.bin” ). Attention : keep the TV power on at the step 5. 2 2 2 2 ) 通过工厂菜单升级 mboot mboot mboot mboot 步骤...
  • Page 29 图 1 图 2 28 / 54...
  • Page 30 图 3 图 4 3)通过工厂菜单升级 HDCP KEY A A A A .准备 HDCP_KEY HDCP_KEY 相关文件 HDCP_KEY HDCP_KEY 1、用切割工具从总 KEY 中把当天要生产的 KEY 切割成一个文件,不能切割成单个文件(该 文件可保存不超过 2000 个 key,如超过了,烧录时读取会较慢)。 2、把该 KEY 文件改命名为 hdcpkey.bin。 29 / 54...
  • Page 31 3、制作辅助文件 hdcpkey_index.bin,该文件保存当前 KEY 的索引值,每烧录一次该值会 递增 1。初始值设置为 0 即可。该文件制作方法同 mac.bin 的制作方法,初始化只需要在第一 个字节写入 00 即可,如下图所示: 3) upgrade HDCP_KRY by factory menu A . prepare relevant document about HDCP_KEY 1. use slice tools to incise a file from master key ,which include the keys should be used to product the same day 2.
  • Page 32 止序列号,在下班时可将 hdcpkey_index.bin 文件拷贝到电脑上备份,如 U 盘丢失,可直接把 备份的 hdcpkey_index.bin 文件拷贝到另外一个 U 盘上直接生产。 Illustrated : the file hdcpkey_index.bin has a memory. In case can not know the end of the key serial number. When off duty, the hdcpkey_index.bin can be copyed to computer for backup.
  • Page 33 Burn Mac Address in factory menu A.Make mac address file mac.bin After SMT, burn mac address by USB flash disk. Mac.bin file include the start of mac address and the end of mac address, every one take 6 bits. Its Method as follow: 1.install authoring tool UltraEdit.
  • Page 34 6、光标定位的第 0 字节,开始输入 MAC 起始地址,例如 00 00 00 00 00 00,一共 6 个字节,如下图所示: cursor located in the zeroth bit, enter the start of mac address, for example :00 00 00 00 00 00,there is 6 bits in all. as follow: 7、然后接着输入...
  • Page 35 total to MAC address-1.for example the start of MAC address is 00 00 00 00 00 00, The distribution of total to MAC address is 1000,then The end of MAC address is 00 00 00 00 03 E7(hexadecimal 999 is 3E7);as follow pic: 8、MAC 地址文件制作完毕,保存文件并拷贝到...
  • Page 36 need to check out one by one. Illustrated:the file hdcpkey_index.bin has a memory. In case can’t know the end of the key serial number. When off duty, the hdcpkey_index.bin can be copyed to computer for backup. If usb disk flash is losed, copy the back up file to anther usb flash disk for produce directly.
  • Page 37 2.运行 SecureCRT 软件,点击“文件”菜单中的“快速连接”选项,在出现的小窗口中做 如下选择: 协议:Serial 端口:根据自己机子端口来设置。具体方法如下:我的电脑 ---右键选择属性---硬件---设备 管理器---端口 比特率:115200 其它的请参考下图设置。 2. Run SecureCRT, click “connect quickly” under “folder ”option, make the same Choose as follow pictures on the Add Member Function Agreement: Serial port: according your computer to set. Its concrete method is: my computer-- Right choice attributes---hardware--Device Manager—port.
  • Page 38 点击连接即可。 Click connect quickly 3.开机,注意 SecureCRT窗口中的打印信息,当出现“Hit any key to stop autoboot”倒计时 时(大约在开机 5 秒钟的时候)按下电脑回车键停止 autoboot。 3.power on, pay attention to the type information on the window of SecureCRT, when it display “Hit any key to stop autoboot”(about 5s after power on ),press enter to stop autoboot 37 / 54...
  • Page 39 4.设置 IP 地址,开始升级。按一下回车键,出现 “<<MStar>>#”的提示符,后依次输入 命令(输入一条命令需按一次回车): ①setenv serverip xxx(xxx 代表所用电脑的 IP 地址,在电脑的本地连接—>属性—>TCP IP 协议中可以查到)。 ②set ipaddr xxx(xxx 代表和上面所设的 IP 地址同一网段的 IP 地址,即前三个相同,第 四个数任意) ③saveenv(保存 IP 设置) ④mstar mscript /auto_update.txt(开始烧录程序) 5.烧录完成后会自动重启。 4. enter IP address to begin upgrade. Press rerurn , display a prompt”<<MStar>>#”,then enter an order one by one (every other end by return): 1.
  • Page 40 5.8 感应按键烧录程序 一:工具: 1. cypress 烧录工具 MiniProg 一套; 2. 自制连接线一根,如图所示 3. 电脑一台 5.8 burn program of induction key 1.a set of cypress burn tool—miniProg 2. a piece of connecting line that make yourself, as image show: 3. a set of PC 39 / 54...
  • Page 41 二:准备工作: 1. 将 MiniProg 连接到电脑上, 2. 将连接线一头接到 MiniProg,一头接头感应按键板,如图所示: Prepare work 1. connect MiniProg to computer 2.connect MiniProg to induction key ,as follow picture: 40 / 54...
  • Page 42 三:烧录步骤: 1. 双击 PSoC Programmer,弹出烧录界面,如下图, Device Family 下拉项选择 “20X24”,即 Device 处选择对应 IC 3:burn step: 1:double click PSoC Programmer,popup burner boundary,as follow picture,choose 20x24 under Device Family,it mean choose corresponding IC. 2. Port 项选中对应端口,然后点击 Connect 按钮,如下图,右下角红色 “Not Connected”变为 41 / 54...
  • Page 43 绿色“Connected”,出现红色“Not Powered”,表示已经连接上感应 IC; 2. choose corresponding Port,click “connect”,as follow pic,when the red “not connected”become to the green“Connected” ,and show the “not powered”,it mean the induction IC had been connected. 3. 点击 File Load ,选择合适烧录文件; 3.click File Load, choose appropriate file 42 / 54...
  • Page 44 4. 点击 Program,如下图所示,右下角进度条显示烧录进度,黄色 “BUSY”,绿色 “Power” 显示烧录中;红色框文字显示具体操作; 4.click Program, as follow pic, the progress bar on the bottom right corner show burning progress, yellow mean “BUSY”, GREEN mean “Power”, the characters on the red bar show specific operation. 5. 烧录成功后,右下角黄色 “ BUSY”变为绿色 “ PASS”,绿色 “ Power”变为红色 “Not Powered”,红色框中文字显示烧录成功...
  • Page 45 exit factory menu:press EXIT key. enter the secondary Menu of factory menu:use direction key to select the option that going to enter,press“ok”. exit the secondary Menu of factory menu:press“EXIT”key go back to homepage of factory menu. 输入:选择信号输入通道(USB 通道不可选) White Balance:白平衡调节, Enter: choose signal channel (USB channel is unavailable) TEMPERATURE:选择色温模式,暖和,正常,冷艳...
  • Page 46 操作此项,所有参数将变回到电视机程序里的最初设定。 复位时电源指示灯会熄灭,再次亮起出现 logo 时,重 默认设置 启机器,复位完成 Default setting Excute this option,every parameter will reset to initial setting 升级 升级电视软件 Upgrade Upgrade TV software 附录 附录 附录 附录 2 2 2 2 :网络模块部分调试说明书 :网络模块部分调试说明书 :网络模块部分调试说明书 :网络模块部分调试说明书 串号扫描软件使用说明 一、 概述 本说明适用于串号扫描软件 3.8.5.0 及以上版本; 软件支持网络机串号扫描、mac 地址和...
  • Page 47 串号扫描软件为绿色软件,无需安装,把压缩包解压即可。 压缩包包含的文件如下图,因为运行过程中会生成一些数据库文件,所以最好保持压缩包的目 录结构。 2.Install Series number scanning software is green program. needn’t install .just need to unzip the package. This package include those folder as follow picture show, its best to keep directory structure,because some database file will be product on the running process. 三、...
  • Page 48 如果该台电脑没有申请过授权,请填写“串号扫描软件申请授权.doc”发送给田灯友,等待服务 器端开通授权; 如果已经开通过授权,请点击“确认”进行在线认证。 在线认证需要联网与通讯,请确认网络连接正常,否则会弹出“网络通信错误”的提示。 If present computer didn’t apply for a license, please fill in “串号扫描软件申请授权.doc” and sent to 田灯友, waiting the serves open a authorization. If the license had be obtained, click “confirm” to approve online. Online the authentication need to connect to internet and communicate with the servicers, please make sure connection is normal.
  • Page 49 如果出现其他提示,请联系田灯友确认问题。 If there has some other presentation, please ask 田灯友 to confirm the problem. 四、 扫描 1. 1. 1. 1. 设备连接 非网络机(VGA 线方式需电视硬件支持) 4 .scanning device connection Non network television(connecting by VGA line need hardware support) 电视机 四芯线或 VGA 线 扫描枪...
  • Page 50 扫描枪 电视机 usb 连接 网线 电脑 网络机(带路由器,一般用于生产线) network television(with router,use for production line) 电视机 网线 外网 扫描枪 路由器 USB 连接 网线 电脑 2. 2. 2. 2. 连接设置 串口设置(非网络机) � 插入 USB 升级小板,打开电脑的 “我的电脑 -》属性-》硬件-》设备管理器 ”,查看升级小 板的串口; 2.connect setting Serial port setting(Non network television) Inset USB upgrade board ,check its serial port from“my computer—property—hardware –device manager”...
  • Page 51 � 运行串号扫描软件,点击 “选择串口 ”(见下图绿色圈圈处),从下拉列表中选择相应的 串口即可(必须先插升级小板,再打开软件,否则会找不到串口)。 Run Series number scanning software,click“choose port”(which the green circle mark as follow picture),choose corresponding port from comboBox. 网络设置(网络机) Internet setting(network television) � 电脑网卡设置 IP 地址 192.168.0.100 ,子网掩码 255.255.255.0 ,默认网关 192.168.0.1 , DNS192.168.0.1。 � 无 路 由 器 时 , 电 视 网 络 设 置 为 “...
  • Page 52 “192.168.0.110”,subbet mask 255.255.255.0,default gateway 192.168.0.1,DNS192.168.0.1 When there has a router, TV network set as “automatic acquisition”, according outer net to set the router, the segment of intranet set as 192.168.0.1, default gateway 192.168.0.1,DNS192.168.0.1 mac 地址和 hdcpkey hdcpkey 设置 3. 3. 3. 3. mac hdcpkey hdcpkey �...
  • Page 53 4. 4. 4. 4. 扫描 � 用扫描枪扫描待录入的串号条形码,软件会自动录入串号,如果是 20 位串号,电脑界面上 显示“串号 xxxxxx 等待记录 ”,如果是 29 位串号且校验码正确,电脑界面上显示 “串号 xxxxxx(CRC)等待记录”,如果串号不合法,电脑界面会根据错误的情况显示; � 电视机开机,网络机连接网线,非网络机连接四芯线或 VGA 线,然后进入工厂菜单的相应 菜单项,烧录正常时电视会显示串号、电脑会显示 “正常记录: xxxxxx”,烧录错误时电 视和电脑会显示错误信息; 4 . scanning Use scanning gun enter Series number barcode, the software will record Series number, if it’s 20 bit Series number, computer will display “Series number waiting to record”...
  • Page 54 1. 软件启动时,可能会弹出如下界面,原因是软件扫描非网络机时采用串口通讯,所以启动时 会按照配置文件打开指定的串口,如果串口不存在或已被占用则会提示弹出该界面。如果是 扫描网络则不用理会该提示;如果是扫描非网络机,请正确设置串口。 2. 串号扫描软件界面请不要打开输入法,保持为英文输入状态,否则会影响扫描枪读取串号。 3. 扫描网络机时,因为电视使用网络与串号扫描软件通讯,所以请关闭电脑的网络防火墙软件 (包括杀毒软件的网络防火墙),否则电视可能无法获取数据。 4. 串号扫描软件使用了加密算法,部分杀毒软件可能会误报为病毒并自动删除 netfactory.exe, 需要在杀毒软件中把 netfactory.exe加入白名单,具体操作请参考杀毒软件使用说明。 5. 串号自动上传功能一般只授权给生产线,需在申请授权时填写,同时电脑需连接外网。 5.other 1 . When the software starting , may popup follow boundary , the reason is program use serial port Communication to scanning Non network television,so it will according to the configuration file to open a specified serial port,if this serial port isn’t exist or have been used,program will popup this note.
  • Page 55 Mai n Boar d Boar d Ci r c ui t Di a gr a m...
  • Page 56 RS15 RS15 NC/100K NC/100K AMP_12V 5V_Normal Thermal 低音滤波电路 AMP_EN AMP_EN PVCCL CS30 CS30 CS31 CS31 CS32 CS32 CS33 CS33 LS01 LS01 FB_600mA FB_600mA 0.1uF 0.1uF 220uF 220uF 220uF 220uF FAULT PVCCL CS07 0.1uF CS07 0.1uF RS13 RS13 OP_VCC2 SAMP_Lin+ CS11 0.47uF CS11 0.47uF CS28 CS28...
  • Page 57 +12V Power LY09 NC/FB_2A LY09 NC/FB_2A 5V-6M40 12VIN_6M40 VY07 VY07 CY64 CY64 +12V_6M40 RY115 RY115 100K 100K RY116 RY116 2.2K 2.2K CY65 CY65 3.3nF 3.3nF 3.3V Power for 6M40 AO3401A AO3401A +12V_6M40 CY60 CY60 0.1uF 0.1uF LY10 FB_2A LY10 FB_2A CY63 10nF CY63 10nF 538MA...
  • Page 58 VBY0N VBY0N_1 VBY0N_2 R390 R390 0.1uF 0.1uF VBY8N RY60 RY60 VBY8N_1 RY73 RY73 VBY8N_2 SPI3_CK RY76 RY76 3D_EN 3V3_P R399 R399 0.1uF 0.1uF RY69 RY69 RY83 RY83 3V3_P 3V3_P 3V3_P 3V3_P Panel-VCC SPI3_CK VBY0N_TX VBY8N_TX VBY0P VBY0P_1 VBY0P_2 RY29 RY29 0.1uF 0.1uF VBY8P...
  • Page 59 2N7002 2N7002 主板电源接口 V803 V803 NC/2N7002 NC/2N7002 V810 V810 CORE POWER POWER INPUT 12VIN +12V FB=0.8V XS808 XS808 C807 C807 5V_Normal R804 R804 R805 R805 D2006-5A D2006-5A 2.2uF 2.2uF 12V_VCC 12V_VCC R806 R806 VCC_VSENSE F801 F801 F5A/32V F5A/32V R803 R803 59K/1% 59K/1% VID1...
  • Page 60 HDMI & Audio NAND & CI & TS & Front End N501B N501B PCM_D[7:0] TS0_D[7:0] PCM_D0 AJ28 AG15 TS0_D0 HDMI Interface N501C N501C PCM_D0 TS0_D0 PCM_D1 TS0_D1 AH28 AJ15 PCM_D1 TS0_D1 PCM_D2 TS0_D2 R479 R479 C560 C560 AJ29 AH15 PCM_D2 TS0_D2 HDMI1-RX0N C501 1uF...
  • Page 61 Power interface VDDC1.15V C502 C502 C503 C503 C505 C505 C511 C511 C512 C512 C516 C516 C567 C567 C815 C815 C817 C817 C592 C592 C819 C819 C577 C577 C820 C820 N501F N501F 2.2uF 2.2uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF...
  • Page 62 VIDEO OUT 5V_Normal N602 N602 L602 L602 XS605 XS605 5V_AMP C603 C603 C602 C602 FB_600mA FB_600mA R613 R613 R614 R614 0.1uF 0.1uF 10uF 10uF 5.1K 5.1K RGB1-VGA_B IP4223CZ6 IP4223CZ6 V602 V602 VGA-Bin+ 3906 3906 RGB1_VGA-G CVBS_OUT C605 10uF C605 10uF V603 V603 VGA-Gin+...
  • Page 63 GAIN0 GAIN1 GAIN (dB) R201 R201 NC/100K NC/100K AMP_12V Thermal AMP_EN PVCCL C202 C202 C203 C203 C208 C208 +12V AMP_12V 0.1uF 0.1uF 220uF 220uF FAULT PVCCL L201 L201 FB_6A FB_6A AUOUTL0 C209 0.47uF C209 0.47uF C206 C206 AUOUTL0 LINP BSPL C210 C210 C204...
  • Page 64 Hot-Plug Control 2st HDMI & ARC MHL for MSD6369 HDMI1-5V XS601 XS601 HDMI HDMI HDMI1_RX2P R601 R601 5.1R 5.1R HDMI1-RX2P HDMI1-RX2P DATA2+ R607 R607 DATA2 SHIELD HDMI1_RX2N R604 R604 5.1R 5.1R HDMI1-RX2N R612 R612 HDMI1-RX2N DATA2- HDMI1_RX1P R602 R602 5.1R 5.1R HDMI1-RX1P HDMI1-RX1P...
  • Page 65 3.3V_Demod RESETn R111 R111 C131 C131 XTAL_IN 27pF 27pF RESETn Z102 Z102 Demod_RST R151 R151 Close to Demod. C130 C130 XTAL-24MHz XTAL-24MHz 0.1uF 0.1uF XTAL_OUT R113 R113 C132 C132 27pF 27pF R109 0R R109 0R I2CS_SDA R126 R126 TUNER_SDA TUNER_SDA I2CS_SCL R152 R152...
  • Page 66 C140 C140 C139 C139 NC/15pF NC/15pF Z110 Z110 NC/15pF NC/15pF 16MHZ 16MHZ C126 C126 RF IN RF IN 10nF 10nF N101 N101 MxL601 MxL601 3.3V_Tun XS101 XS101 VDD_3p3_1 CLK_OUT C107 0.1uF C107 0.1uF L104 NC/560nH L104 NC/560nH R104 R104 TUNER_SDA TUNER_SDA LIN_INP C105...
  • Page 67 VCC3.3 USB HUB USB POWER NU01 NU01 1.5A Switch VUSB NU22 NU22 5V_USB AVDD1 USB_DP1 CU05 CU05 CU06 CU06 CU07 CU07 CU08 CU08 CU01 CU01 CU10 CU10 5V_Normal MC2110 MC2110 AVDD DP1_DP RU19 RU19 USB_DM1 LU03 LU03 UP_RREF DP1_DM 680R 680R PVDD AVDD0...
  • Page 68 3.3Vstb 蓝牙发射接口 D1250-03 D1250-03 3D_SYNC XS647 XS647 3D_SYNC 3D_SYNC 5V_Normal LY03 LY03 FB_600mA/NC FB_600mA/NC CY05 CY05 CY09 CY09 CY06 CY06 RY09 RY09 RY10 RY10 0.1uF 0.1uF 10uF 10uF 4.7R/1206 4.7R/1206 4.7R/1206 4.7R/1206 10uF 10uF 3D_3V3 3D_3V3 3D_IROUT 3D_IROUT RY12 RY12 VY02 VY02 XS646...
  • Page 69 iNAND FLASH 3V3_Normal NF_POWER EMMC_D0 NAND_RBZ EMMC_D1 NAND_ALE R502 0R R502 0R EMMC_D2 NAND_WPZ EMMC_D3 N510 N510 NAND_WEZ C594 C594 C598 C598 C595 C595 EMMC_D4 NF_CLK NF_D4 NAND_REZ C597 C597 C596 C596 0.1uF 0.1uF 0.1uF 0.1uF EMMC_D5 NF_CMD NF_D5 NAND_CLE 0.1uF 0.1uF 2.2uF...
  • Page 70 A-DDR3-ODT-T1 R439 R439 A_DDR3_ODT A_DDR3_ODT R470 R470 A-DDR3-ODT-T2 A-DDR3-BA0-T1 R440 R440 A_DDR3_BA0 A_DDR3_BA0 R473 R473 A-DDR3-BA0-T2 0RX4 0RX4 RA401 RA401 0RX4 0RX4 RA404 RA404 N501A N501A A-DDR3-BA2-T1 A_DDR3_BA2 A_DDR3_BA2 A-DDR3-BA2-T2 A-DDR3-A3-T1 A_DDR3_A3 A_DDR3_A3 A-DDR3-A3-T2 A-DDR3-A5-T1 A_DDR3_A5 A_DDR3_A5 A-DDR3-A5-T2 A_DDR3_A0 B_DDR3_A0 A_DDR3_A0/DDR2_A5 B_DDR3_A0/DDR2_A5 A-DDR3-A7-T1...
  • Page 71 日期 AD22 AC22 拟 制 拟 制 拟 制 <拟制> <拟制> <拟制> 审 核 审 核 审 核 <审核> <审核> <审核> KONKA KONKA KONKA 工 艺 工 艺 工 艺 <工艺> <工艺> <工艺> MST6M40 MST6M40 MST6M40 标准化 标准化 标准化 <标准化>...
  • Page 72 日期 日期 拟 制 拟 制 拟 制 <拟制> <拟制> <拟制> 审 核 审 核 审 核 <审核> <审核> <审核> KONKA KONKA KONKA 工 艺 工 艺 工 艺 <工艺> <工艺> <工艺> MST6M40 DDR3 MST6M40 DDR3 MST6M40 DDR3 标准化 标准化...
  • Page 73 Power Boar d Ci r c ui t Di a gr a m...
  • Page 74 日期 拟 制 拟 制 拟 制 COLD 审 核 审 核 审 核 1.0 FAN7930C+FSL206MR 1.0 FAN7930C+FSL206MR 1.0 FAN7930C+FSL206MR 工 艺 工 艺 工 艺 KONKA KONKA KONKA 标准化 标准化 标准化 KPS+L195C3-02 第 第 第 张 张 张 共...
  • Page 75 单号 单号 签名 签名 签名 日期 日期 日期 拟 制 拟 制 拟 制 审 核 审 核 审 核 KONKA KONKA KONKA 工 艺 工 艺 工 艺 KPS+L195C3-02 标准化 标准化 标准化 批 准 批 准 批 准 第...
