- Page 1 Kit Instructions Coupon Chute with Proximity Sensor Assembly 7357-K910 Issue A...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Software screen images are representative, and in some cases, may not match a customer’s installed software exactly.
-
Page 3: Revision Record
Revision Record Issue Date Remarks Mar 2020 First Issue... -
Page 5: Kit Contents
Coupon Chute with Proximity Sensor Assembly This publication provides instructions for installing a Coupon Chute with Proximity Sensor Assembly to an NCR FastLane SelfServ™ Checkout (7357) R6LN Plus unit. Kit Contents Part Number Description 497-0527126 7357-K910 Coupon Chute with Proximity Sensor Assembly... - Page 6 Coupon Chute with Proximity Sensor Assembly Part Number Description * 497-0423108 Instructions - Kit (Reference Sheet) * 497-0477142 Receipt Label without text * Items marked with an asterisk are not called out on the image.
-
Page 7: Installation Procedure
Coupon Chute with Proximity Sensor Assembly Installation Procedure To install the Coupon Chute with Proximity Sensor Assembly, follow these steps: 1. Open the Core Door. For more information, refer to Opening the Core Door on page 7. 2. Install the Proximity Sensor Assembly to the Coupon Chute using two (2) M3 screws, as shown in the image below. - Page 8 Coupon Chute with Proximity Sensor Assembly 4. Detach the Coupon Bin Throat from the back of the Core Door by removing two (2) screws. Set these aside for reinstallation later. 5. Detach the existing Coupon Chute from the back of the Core Door by removing four (4) hex nuts.
- Page 9 Coupon Chute with Proximity Sensor Assembly 6. Attach the Coupon Chute with Proximity Sensor Assembly to the back of the Core Door by reusing the four (4) hex nuts that were previously removed from the existing Coupon Chute. 7. Re-attach the Coupon Bin Throat to the back of the Core Door using two (2) screws.
- Page 10 Coupon Chute with Proximity Sensor Assembly 8. Route the Proximity Sensor cable along the Core Door and connect to the I/O Box, as shown in the image below. 9. Close the Cabinet Door. For more information, refer to Closing the Core Door page 8.
- Page 11 Coupon Chute with Proximity Sensor Assembly Opening the Core Door To open the Core Door, follow these steps: 1. Insert key into lock on door latch and turn key counterclockwise. 2. Remove key and then press the keylock to unlatch and open the door.
- Page 12 Coupon Chute with Proximity Sensor Assembly Closing the Core Door To close the Core Door, follow these steps: 1. Push the core door to the core cabinet and push the door latch until it closes. 2. Insert key in door latch lock and turn it clockwise to lock door. 3.
