INSTALLATION INSTRUCTIONS
NCR OPTIC 12 FOR WAYNE HELIX (STANDARD)
6002-0007-8801
497-0524410
Issue A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OPTIC 12 and is the answer not in the manual?

Questions and answers

Related Manuals for NCR OPTIC 12

Summary of Contents for NCR OPTIC 12

  • Page 1 INSTALLATION INSTRUCTIONS NCR OPTIC 12 FOR WAYNE HELIX (STANDARD) 6002-0007-8801 497-0524410 Issue A...
  • Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
  • Page 3 PREFACE Audience This book is written for end users (System Administrator and Maintenance Technician), NCR Field Engineering, and VAR/OEM Hardware and System Integrators Notice: This document is NCR proprietary information and is not to be disclosed or reproduced without consent.
  • Page 4 SAFETY AND COMPLIANCE INFORMATION This section introduces the hazards and safety precautions associated with installing, inspecting, maintaining or servicing the Wayne Helix . Before proceeding, check the relevant hazard and safety information. Fire, explosion or electrical shock could occur and cause death or serious injury if these safe service procedures are not followed. All work must be carried out in accordance with NFPA (National Fire Protection Association) 30, 30A, and 70, and any local authority.
  • Page 5 Read, understand and follow this manual and any other labels or related materials supplied with the equipment. If you do not understand a procedure, call NCR. It is imperative to your safety and the safety of others to understand the procedures before beginning work.
  • Page 6 SAFETY SYMBOLS AND TERMINOLOGY Caution: This safety alert symbol is used in this manual and on warning labels to alert you to a precaution which must be followed to prevent potential personal safety hazard. Obey safety directives that follow this symbol to avoid possible injury or death. Signal Words Warning: Alerts you to a hazard or unsafe practice which will result in death or...
  • Page 7 If you do not have access to a computer, you may leave a voice message at: 1-800-528- 8658 (USA), or (International) +1-770-623-7400. When leaving a message, please provide a phone number and/or an email address so NCR can contact you if additional details are needed.
  • Page 8 WARRANTY Warranty terms vary by region and country. All parts of this product that are subject to normal wear and tear are not included in the warranty. In general, damages due to the following are not covered by the warranty. •...
  • Page 9 • Description of the problem, including any system error codes, error condition, or guidance to the area of failure. The NCR Agent will provide you with a work order number, which serves as your Return Material Authorization (RMA). Please provide the RMA on the outside of the shipping box.
  • Page 10 viii...
  • Page 11 REVISION RECORD Issue Date Remarks Jan 2019 First Issue...

  • Page 13: Table Of Contents

    FROM THE DISPENSER INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX PREPARE AND INSTALL THE HELIX POWER SUPPLY ASSEMBLY INSTALL THE COLLAR FRAME PREPARE TO INSTALL THE OPTIC PANEL INSTALL THE OPTIC 12 ASSEMBLY INTO THE HELIX STD DISPENSER...

  • Page 15: Installation Components

    INSTALLATION COMPONENTS INSTALLATION COMPONENTS REQUIRED ADDITIONAL KITS Additional Required Retrofit UL Listing Information Amount Required Kits Dispenser Cub UL Listed by Report Retrofit Kit Part Number One per dispenser. Installed on 6009-0008-8801 (InvencoLink Converter) PSU Bracket accessed on Side B. OPTIC 12 Printer UL Listed by Report Retrofit Kit Part Number One per side of the dispenser.
  • Page 16 Speaker Gasket Bracket 497-0519552 Speaker Gasket, set of 2 006-8626488 Speaker Bracket Screw 497-0520601 Helix OPTIC Speaker 006-8626667 Helix OPTIC Speaker Screw 497-0515297 NCR Lock Assembly (Optional per installation location) 497-0513687 CABLE, EARTH, BRAIDED, 1.2M 006-8611152 Washer - #8 External Tooth Lock, Clear Zinc...

  • Page 17: Required Tools

    REQUIRED TOOLS REQUIRED TOOLS • T7 Torex Key • 3mm Allen Key • Phillips head screw driver • Flat head screw driver • Helix dispenser key • Rubber mallet • Tin Snips...

  • Page 19: Recommended Materials

    RECOMMENDED MATERIALS RECOMMENDED MATERIALS Solvent to remove gasket material Scraping tool Cloths for cleaning...

  • Page 21: Prepare The Wayne Helix Standard (Std) For Ncr Optic

    PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC Follow these steps to uninstall Helix STD components prior to installing the NCR OPTIC 12 components. OPEN THE WAYNE HELIX STD 1. Using the provided key for the dispenser, unlock the lower metal frame on the Helix dispenser.
  • Page 22 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC 3. Remove the lower metal Collar Frame. a. Unscrew the two attaching screws using a T7 Torex driver holding the upper and lower collar frame sections together. Retain the screws and set aside.
  • Page 23 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC Caution: When the lower metal frame disengages from the upper plastic frame it could fall causing injury to the installer or damage to the frame itself. Hold in place to prevent injury or damage.
  • Page 24 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC b. Pry up on the points indicated until the shoulder is loosened. Pull the rest of the way off. c. Repeat the removal step on the other dispenser shoulder. Retain both shoulder...
  • Page 25 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC Caution: Be careful to apply enough force to loosen the shoulder piece but not enough to snap off the capturing feature. These components will be reinstalled. 6. Verify the upper plastic collar frame on each side of the dispenser is raised and the...

  • Page 26: Uninstall The Helix Cabinet Components

    PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC UNINSTALL THE HELIX CABINET COMPONENTS 1. Uninstall all components from the upper Plastic Collar Frame. a. Note all connections to the Helix Customer Display. Unplug all connections to the Helix Customer Display and unscrew the grounding wire screw from the plastic collar frame using a T7 Torex driver.
  • Page 27 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC c. Remove any remaining gasket material from the outer speaker housing and clean any adhesive residue. Place speaker inside the dispenser cavity. Retain attaching hardware. d. Uninstall the speaker attachment bracket using a T7 Torex driver (or Phillips head driver depending on screw type) on the center screw.
  • Page 28 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC 3. Uninstall the PPU panel. a. Pull out the Helix STD components and PPU Panel attached to the slide rails.
  • Page 29 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC b. Note the cable connections to the PPU Board (located below the Helix STD components), PPU Grade Select Buttons Cable, Totalizer Cables, and Call/Intercomm Button cable for re-installation. Disconnect all cables from the PPU board, totalizers (if present), Grade Select Buttons, and Call Button (if present on PPU panel).
  • Page 30 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC e. Remove the PPU board from the metal bracket. Retain the PPU board and attaching hardware. Discard the metal bracket. Note: Depending on the PPU configuration, the PPU board could be held on by 2 to 5 screws to the metal bracket.
  • Page 31 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC g. Remove and discard the string gasket from the PPU panel. 4. Remove the Helix STD Components. a. Unplug all cables included in the black sleeved cable bundle from the Helix STD components attached to the slide rail pullout (Card Reader, Screen, etc.).
  • Page 32 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC b. Open the printer door using the site assigned printer key and pull out the printer.
  • Page 33 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC c. Unplug the printer cables from the printer unit. d. Unclip the Printer Cables from the routing channel along the side of the printer. Pull the cables through the printer door opening. Close and re-lock the printer...
  • Page 34 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC e. Check that all connections are unplugged from the Helix STD components (including grounding wires) and unzip the cable bundle from the STD slide bar and place into the dispenser.
  • Page 35 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC f. Remove the Helix STD components by disengaging the slide bars and pulling the components fully out of the dispenser. Depress the plastic catch lever on each slide bar track and pull out the STD components until the slide bars clear the dispenser.
  • Page 36 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC g. Remove both slide rails from inside the dispenser. Depress the red security latch on the back side of the slide rail and pull the track out of the dispenser slide rail.

  • Page 37: Uninstall The Dispenser Upper Collar Frame

    PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC a. Remove any restraints holding the Black Sleeve Cable Bundle to the inside of the dispenser and remove the Black Sleeve from the cable bundle. Discard the black sleeve. b. Identify the PPU cables for power and communication, PPU Grade Select Cable, Totalizer Cables (if present), and Call/Intercomm Button cables (if present on the PPU panel) from the Cable Bundle.
  • Page 38 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC 3. Lift up on the collar frame until the hinge pin clears the hinge tab. Rest the right side of the frame on the dispenser. 4. Repeat the process on the left side hinge pin and hinge tab. Push out on the tab and...
  • Page 39 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC 5. Uninstall the Prop Rod Bracket. a. Turn the Upper Collar frame on its side with the Prop Rod Bracket facing up. b. Push up on the bracket while wiggling side to side until it clears the edge of the...
  • Page 40 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC c. Continue to push up on the bracket until it is fully removed. Retain the Prop Rod Bracket. 6. Remove the Customer Display from the plastic collar frame. Unscrew the remaining three screws holding the Customer Display with a T7 Torex driver.

  • Page 41: Uninstall The Metal Bracket Components From The Dispenser

    PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC 8. Repeat for the opposite side of the dispenser. UNINSTALL THE METAL BRACKET COMPONENTS FROM THE DISPENSER 1. Remove the metal cross bar bracket and attaching hardware from the dispenser. a. unscrew the two screws from the bracket.
  • Page 42 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC c. Remove and discard the bracket and attaching hardware. 2. Repeat the previous steps for the opposite side of the dispenser. 3. Remove both bottom side metal brackets and attached components from the dispenser.
  • Page 43 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC 4. Remove the Helix STD Payment Controller Board components. a. Identify the board displayed below. b. Unplug all cables from the STD controller board.
  • Page 44 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC c. Remove the STD controller board using a T7 Torex driver on the 4 corner screws holding the metal plates together. Note: Unscrew the outside screws attaching the STD Controller Board Plate to the larger metal plate, not the board screw themselves.
  • Page 45 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC 5. Remove the lower metal plate from the dispenser to access the large metal plate previously holding the STD payment controller board. a. Unscrew the buzzer from the lower metal plate.
  • Page 46 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC b. Attach the buzzer to the Pump Controller Metal Panel using the supplied adhesive pad (497-0521281).
  • Page 47 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC c. Remove the nuts on the bottom plate stud and any nuts holding a ground wire to the bottom plate. Discard all hardware.
  • Page 48 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC d. Using a pair of tin snips or hand cutters, cut the bottom plate on the side of the buzzer as shown below. Caution: Before making the cut, clear all cables away in the path of the hand cutters.
  • Page 49 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC f. Behind the Large Metal STD Payment Controller Board plate, cut the plate in the location below. Push on the plate until the cutter can get enough purchase on the plate. g. Move to the opposite side of the dispenser and cut the metal plate in the location...
  • Page 50 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC h. Once the plate is cut, bend down until the plate is pulled out of the dispenser side bosses holding it in place. You may also need to bend the Stud tabs up and out of the way with a flat head driver located on the right side of the panel on each side of the dispenser.
  • Page 51 PREPARE THE WAYNE HELIX STANDARD (STD) FOR NCR OPTIC 6. Remove the remaining plate that held the STD payment controller board. a. Push from the back of the plate so it bulges towards you. b. Continue to pull on the plate until it disengages from the dispenser side bosses.

  • Page 53: Install The Optic 12 Into The Standard (Std) Wayne Helix

    INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX Identify Side A and B by looking at the designation on the inside of the dispener. PREPARE AND INSTALL THE HELIX POWER SUPPLY ASSEMBLY 1.
  • Page 54 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX b. Install PSU Screw A (006-8617819) into the back of the Helix PSU Mounting Bracket. Install the screw into the stud on one side and a PSU Screw B (006- 8611215) and nut (006-8611426) assembly on the other side.
  • Page 55 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX d. Install the PSU Screw B (006-8611215) and nut (006-8611426) assembly into the location below. 2. Install the Dispenser Cub to one of the PSU brackets. Follow the Cub Installation Instructions (497- 0514466). Acquire the Cub Retrofit Kit, UL Listed by Report...
  • Page 56 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX 3. Install the Helix PSU Assembly with the Dispenser Cub facing out towards you on the dispenser side opposite the pump controller board. Place the full Helix PSU Assembly into the dispenser cavity in the farthest back plastic bracket slots located in the center of the dispenser.
  • Page 57 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX b. Disconnect the main AC line. c. Acquire the Helix power adapter cable. Plug in the pigtail end of the cable to the main AC line.
  • Page 58 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX d. Connect the second Helix power adapter cable to the other pigtail end of the first connected cable. e. Connect the free pigtail end of the Helix power adapter cable to the Main Power...
  • Page 59 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX 5. Route both Helix Power Adapter Cables into the upper dispenser cavity. a. On Side A of the dispenser, identify the cable routing duct in the lower right corner of the dispenser.
  • Page 60 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX Note: Use a length of wire or twine to help route the cables up the duct. Drop the wire or twine into the top of the duct, wrap/tie the wire or twine to the cable and guide into and up the routing duct.
  • Page 61 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX b. Route the comm connection through the cable routing duct and pull out from the bottom. c. Plug the four pin connector to the comm pass through on the comm board.
  • Page 62 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX d. Plug in the green connector to the Dispenser Cub. 7. Connect the preinstalled PSU power cables to the previously routed Helix power adapter cables.
  • Page 63 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX 8. Install the CAT network cables, Yellow for LAN (497-0513384) and Red for Data (497- 0513383), to the Dispenser Cub. a. Connect the Side A connection in the LAN 1(Yellow)/RS232-1(Red) connections.

  • Page 64: Install The Collar Frame

    INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX b. Connect the Side B connection in the LAN 2(Yellow)/RS232-2(Red) connections. Allow the B side network cables to fall into the B side dispenser cavity. INSTALL THE COLLAR FRAME 1. Acquire the Plastic Upper Collar Frame (497-0517598). Install the retained Prop Rod bracket to the new plastic collar frame in the noted position from the uninstall process.
  • Page 65 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX b. Push in the Prop Rod Bracket until the retaining feature engages and holds the Bracket in place. 2. Slide the new top plastic collar frame into the lower metal collar frame until the...
  • Page 66 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX 3. Secure the upper and lower frame collars together with the retained screws. 4. Place in the hinge pin section of the upper collar into the hinge.
  • Page 67 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX 5. Install the other hinge pin into the hinge and apply force until the hinge engages onto the hinge pin. 6. Repeat the previous steps for the opposite side of the dispenser.
  • Page 68 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX a. Both dispenser frames should be lowered and lifted until each shoulder piece on each side is in position. b. Apply force to the top of each shoulder until it seated into the top of the...

  • Page 69: Prepare To Install The Optic Panel

    INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX c. Reopen the dispenser frames and engage the prop rods after both shoulders are reinstalled. PREPARE TO INSTALL THE OPTIC PANEL 1. Install the Customer Display onto the OPTIC Panel (497-0520725).
  • Page 70 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX 2. Install the Speaker Gasket Brackets and Helix OPTIC Speaker. b. Remove the Speaker Hole Breakaways on each side of the OPTIC panel with a pair of pliers.
  • Page 71 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX c. Acquire the new speaker gasket bracket (497-0520603), retained bracket, and new speaker gaskets (497-0519552). Install the gaskets to both brackets. Install the Speaker Gasket Brackets to the Speaker Openings with one provided screw (006- 8626488) and one retained screw.
  • Page 72 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX e. plug in the Helix OPTIC Speaker to the OPTIC head unit. 3. Prepare the PPU Panel and Slide Rails. a. Install the retained PPU board onto the new OPTIC metal PPU bracket (497- 0521060) using the retained hardware.
  • Page 73 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX b. Remove the two outside slide rail sections from the Helix STD slide rail and bracket assemblies (Printer Side Slide Rail, 497-0520739; Card Reader Side Slide Rail, 497-0520740) by pulling back on the plastic latches as shown below.
  • Page 74 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX d. Rotate the remaining attached slide rails into position and secure with the provided screw (006-8611475) and nut assembly (006-8611847). Repeat on the opposite side. 4. Combine the PPU and Slide Rail components to make the PPU Slide Rail Assembly.
  • Page 75 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX b. If present place the Totalizer Bracket Assemblies in the previously noted location. Keep in place and install inbetween the PPU Bracket and Slide Rail Assembly. If no totalizers are present, use the supplied washer (006-8626923) instead in the...
  • Page 76 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX c. Attach the Printer Side Slide Rail onto the right side of PPU assembly with the screens facing away from you. Place the Slide Rail over the bracket and insert the screw (006-8611475) into the top of the PPU Plate and metal bracket.
  • Page 77 Repeat on the Card Reader side to attach the Card Reader Side Slide Rail. 5. Install the Slide Rail and PPU assembly to the Helix OPTIC 12 panel. a. Remove the 4 screw and nut assemblies from the Helix OPTIC 12 Panel and...
  • Page 78 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX b. Place the PPU Plastic panel onto the bottom edge of the Helix Panel, making sure the gasket stays in place between the PPU and Helix panels. c. Adjust the brackets until the screw locations and panel holes align correctly.
  • Page 79 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX d. Install the previously removed screw and nut assemblies to attach the Slide Rail PPU assembly to the OPTIC 12 panel. e. Install the bottom gasket around the PPU Plastic Plate. Start at the top edge of...

  • Page 80: Install The Optic 12 Assembly Into The Helix Std Dispenser

    0517666). 7. Repeat the previous steps for the second side's OPTIC 12 Assembly. INSTALL THE OPTIC 12 ASSEMBLY INTO THE HELIX STD DISPENSER 1. Install the slide rails into the previously installed outer slide rails. Push the OPTIC 12 panel into the dispenser until the slide rail catches engage and the OPTIC 12 Panel Assembly's gasket is flush against the dispenser edge.
  • Page 81 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX 2. Repeat the previous step for the opposite side of the dispenser. 3. Pull out the OPTIC 12 Panel. Install the power cable, network cables, and grounding wire to the OPTIC panel components.
  • Page 82 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX c. Remove the existing earth ground screw from the pump and retain for re installation. d. Attach the unused end of the 497-0513687 earth ground cable and 006-8611152 lock washer to the retained earth ground screw.
  • Page 83 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX e. Reinstall the earth ground screw with earth ground ring terminal and lock washer attached allowing the PSU to be grounded to the pump chassis as depicted in the photo below.
  • Page 84 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX b. Install the Comm Speaker to the left side Speaker Gasket Bracket using the retained hardware with the speaker cables oriented down. 5. Reconnect all PPU, Grade Select Button, totalizers (if present), and Call/Intercomm...
  • Page 85 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX 6. Replace the dispenser frame lock if (per installation site order). Located at the bottom of the metal dispenser frame. a. Take out the old lock, remove the lock cam screw and cam. unscrew the lock...
  • Page 86 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX...
  • Page 87 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX b. Install the new NCR lock assembly (497-0515297). Slide in the lock barrel and gasket. Install the lock barrel nut and tighten the lock into place. Install the new lock cam in the unlocked position with the bend towards the metal frame as shown below.
  • Page 88 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX 8. Lower the Frame Collar and lock into place.
  • Page 89 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX 9. Repeat for Side B. 10. Return Power to the dispenser.
  • Page 90 INSTALL THE OPTIC 12 INTO THE STANDARD (STD) WAYNE HELIX Caution: Follow local regulations for certification and inspection prior to returning power or reopening the dispenser for costumers.
