Lumag MD300 Operator's Manual

Lumag MD300 Operator's Manual

Mini dumper
Hide thumbs Also See for MD300:
Table of Contents

Advertisement

Quick Links

Download this manual
Distribution Limited
Mini Dumper
Operator's Manual
MD300
FOR YOUR SAFETY
FOR YOUR SAFETY
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL
READ AND UNDERSTAND THE ENTIRE MANUAL
Ensure you read and understand how to operate
BEFORE OPERATING THIS MACHINE
the machine safely. Check your machines oil
BEFORE OPERATING THIS MACHINE
levels before every use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lumag MD300

Summary of Contents for Lumag MD300

  • Page 1 Distribution Limited Mini Dumper Operator’s Manual MD300 FOR YOUR SAFETY FOR YOUR SAFETY FOR YOUR SAFETY READ AND UNDERSTAND THE ENTIRE MANUAL READ AND UNDERSTAND THE ENTIRE MANUAL Ensure you read and understand how to operate BEFORE OPERATING THIS MACHINE the machine safely.
  • Page 3 Clutch & Steering Handles Check Function 1 – First service only, 2 = Should be carried out by your Lumag Dealer, 3 = May need to be done more often in dusty areas & 4 = Replace paper element only...
  • Page 6 The risk is borne solely by the user. From LUMAG GmbH own graphics, images, text and layout are subject to copyright and the laws protecting intellectual property. Any reproduction or use of graphics, images, texts and layouts in other electronic or printed publications is not permitted without the express consent of LUMAG GmbH.

  • Page 7: Table Of Contents

    CONTENT introduction Intended Use safety instructions General Safety Rules Workspace Personal security Fuel security Machine utilization and maintenance maintenance Specific Safety Rules Warning and information symbols used delivery Assembly Features and Controls business Filling with fuel Starting the engine Neutral Stopping the motor maintenance preventive maintenance...

  • Page 8: Introduction

    Unlocking and tilting is done manually by hand. The Mini-dumper is not approved for people promotion. Any use not in accordance with the above specifications, is considered improper. LUMAG GmbH will relieve against the consequences of any claims resulting from failure to comply with these provisions accordingly.

  • Page 9: General Safety Rules

    SAFETY INSTRUCTIONS People at risk due to improper use. The notices referring to your personal safety are highlighted by a warning triangle, notices referring only to property damage have no warning triangle. DANGER Failure to follow these instructions highest danger to life or the risk of life-threatening injuries.

  • Page 10: Workspace

    SAFETY INSTRUCTIONS 3.2 Workspace DANGER Internal combustion engines during operation and fueling a special hazard. Always read and follow the warnings and to the additional safety instructions given in parallel later in this manual. Failure to do so could result in serious injury or death. Do not allow engine start indoors, garages or enclosed areas or run.

  • Page 11: Fuel Security

    SAFETY INSTRUCTIONS are. Make sure that all nuts, bolts, etc. are tight. Damaged guards and covers must be intended repaired by an authorized service workshop or replaced, unless otherwise specified in the instructions. Moving parts must function properly and must not jam. All parts must be fitted correctly and fulfill all conditions to ensure the proper operation of the power tool.

  • Page 12: Machine Utilization And Maintenance

    SAFETY INSTRUCTIONS Keep avoiding grounded conductive objects such as tools, from exposed live parts and connections to sparking and arcing. These events could ignite fumes or vapors. Switch off the engine and always let it cool before filling the fuel. Do not remove the cap of the fuel tank or fuel fill in hot or running motor.

  • Page 13: Specific Safety Rules

    SAFETY INSTRUCTIONS Use only approved by the manufacturer, and accessories. Failure to comply may result in injury. Wait for the machine. Make sure that all movable and fixed parts are in the right position, no parts are broken or if there are other errors that may affect the smooth operation of the machine.
  • Page 14 SAFETY INSTRUCTIONS would bring laying in danger. keep bystanders, children and animals at least 22 meters away. When approaching stop operation immediately. Do not climb on the Tilting and do not transport people with it. put the machine, especially when loaded, never could yield to an unstable ground. In front disengage the engine is started.
  • Page 15 SYMBOLS USED ALARM AND SYMBOLS NOTE The machine is supplied without engine oil. Before the first start is thus fill the first motor oil. Failure to comply may result in irreparable damage to the engine. DANGER Health and explosion due to engine ■...
  • Page 16 SYMBOLS Trailer loading never flip on soft ground or in an inclined position Warning from flying objects Bystanders keep. Warning of hot surfaces! Contact can cause burns. perform maintenance, servicing and cleaning work when the engine is cold. Risk of injury. Hazard due to rotating parts such as chain or belt drive. Hands and feet away.

  • Page 17: Delivery

    DELIVERY DELIVERY The all-terrain Mini-dumper is partially assembled them and come in carefully wrapped packages. Once you have all the parts removed from the package, you should be: Ready mounted machine unit handlebar assembly tilt handle 16238 Extendable lift 4 35 Engine Guard Extendable lift Bottom plate (bottom)

  • Page 18: Assembly

    ASSEMBLY ASSEMBLY Follow the instructions to install the machine in minutes. Place the bottom plate in the mounting bracket. Align the holes with the mounting bracket. Insert the pin through the holes and secure each side with a flat washer and a cotter pin Align the holes of the handlebar with the mounting bracket, secure each hole with a...
  • Page 19 ASSEMBLY Position the motor protection in the mounting bracket and align them with the mounting bracket holes from. Back up the left side wall with two M8 35 M8x30 screw heads, four M8 30 Washers and two nuts. NOTE Mount the tilt handle on the right side panel. Align the holes and fasten with two M8x35 hex screws, four washers and two nuts.
  • Page 20 FUNCTIONS AND CONTROLS FUNCTIONS AND CONTROLS Engine switch throttle control lever right clutch lever Tilting steering lever left lever tilt handle Chain gearbox motor switch With the engine switch the ignition system on and off. Allow the engine to run, the engine switch to ON (ON) has to be connected. When the engine switch to OFF (OFF) is switched, the motor is turned off.

  • Page 21: Business

    FUNCTIONS AND CONTROLS BUSINESS gear lever With this lever, the forward and backward movements of the machine are controlled. tilt handle With the tilt handle the tilting of the tilting is controlled. For lifting of the tilting of the handle is pushed forward.

  • Page 22: Starting The Engine

    BUSINESS 8.2 Starting the engine A detailed description of the engine operation and all related warnings and measures found in the separate, included with the Mini-dumper engine manual. During cold starts comply with the following procedure: turning the choke lever to the motor in the Vollchoke position. Move the throttle lever on the handle in the central switching position.

  • Page 23: Neutral

    OPERATION / MAINTENANCE comes in considerable slopes when driving over bumps, holes and steps. ■ When the clutch lever is released, stops and automatically brakes the machine. ■ If the machine is stopped on steep slopes, one of the chains with a wedge must be secured.

  • Page 24: Preventive Maintenance

    MAINTENANCE 9.1 preventive maintenance Stop the engine and disengage all control levers. The engine must be cold. Check overall condition of the device. check for loose screws, misalignment or blockage of moving parts and other conditions that could affect the safe operation. Remove all dirt and other of chain and device materials present.

  • Page 25: Tightening The Chains

    MAINTENANCE 9.5 Tightening the chains With increasing service life, the chains may be loose. Operating with loose chains can cause these away slip over the drive wheel and cause them to jump out of its housing, or no longer work safely and so can damage the case. Proceed as follows for checking the tightness of the chains: Machine on a flat surface with the compact surface, preferably asphalt or stone floor filters.

  • Page 26: Replacement Of The Chains

    MAINTENANCE NOTE If the set screw does not allow further adjustment more, the chains should be replaced. Tilting bring them back to the starting position. 9.6 Replacement of the chains Check the condition of the chains regularly. If a chain is broken or become fibrous, they should be replaced soon as possible.

  • Page 27: Storage

    STORAGE / TRANSPORT 10. STORAGE DANGER Do not store engine with fuel in a non-ventilated area, may come into contact in the fuel vapors with flame, spark, pilot lamps or other sources of ignition. If the mini-dump unused state for more than 30 days, the following steps are designed for storing the device to perform: Drain fuel tank completely.

  • Page 28: Equipment

    TRANSPORT / ACCESSORIES ■ During transport always switch off the engine! ■ Make sure that Loading area and side walls are fixed. ■ Carrying the device in a horizontal position to prevent fuel or oil leakage. ■ When transporting over long distances, the fuel tank is completely emptied. ■...
  • Page 29 TROUBLE 13. TROUBLE disorder root cause remedy Spark plug cable attach the spark plug disconnected. wire to the spark plug. Lack of fuel or old fuel. fill with clean, fresh gasoline. not choke in the open Move the throttle lever to position.

  • Page 30: Technical Specifications

    TECHNICAL SPECIFICATIONS 14. TECHNICAL SPECIFICATIONS model MD-300 drive motor 1 cylinder 4-cycle OHV engine engine power 4.8 kW (at 3600 U / min) capacity 196 cc Working speed Gear 1 forward - 1.6 km / h Gang 2 forward - 2.9 km / h Gear 3 forward - 3.6 km / h Gang 1 reverse - 1.2 km / h starting device...
  • Page 31 WARRANTY LUMAG guarantees impeccable quality and will, without prejudice to statutory liability, in the case of material or manufacturing defects warranty. Which guarantee LUMAG products is 24 months for industrial or professional use or use or for rental for private use only;...

  • Page 32: Ec Declaration Of Conformity

    Phone: +49 (0) 85 71/92 556 - 0 – Electromagnetic compatibility 2004/108 / EC Fax: +49 (0) 85 71/92 556 - 19 declared the Company: LUMAG GmbH Robert-Bosch-Ring 3 D-84375 Kirchdorf / Phone: 0049 / (0) 8571/92 556-0 Fax: 0049 / (0) 8571/92 556-19...
  • Page 33 PARTS OF THE TOOL 17. PARTS OF THE TOOL...
  • Page 34 PARTS OF THE TOOL Tilting...
  • Page 36 Unit 1-3, Hatchmoor Industrial Estate, Hatherleigh, Okehampton, Devon EX20 3LP Lumag Distribution Limited Company Number: 09267547 VAT Number: GB154566788 Hatherleigh www.lumag-gb.co.uk 01837 811741 Plant and Tool Hire is a trading name of Lumag Distribution LTD Lumag Distribution Limited Company Number: 09267547 VAT Number: GB154566788 Hatherleigh...
