- Page 1 ASSEMBLY MANUAL SKU: 166-1-6 MODEL NAME: Fjällbacka Konsumentkontakt Arc E-commerce AB Box 3124 13603 Haninge...
- Page 2 Attention! Please note that at first all screws should be inserted slightly by hand! Turn 2-3 times so that the screw grips on its own and connects all elements loosely. The screws must only be driven in tightly when all elements are connected with each other in this way.
- Page 3 Component Hardware Right Frame 6pcs 12pcs M6 x 40 Left Frame 6pcs 24pcs M6 x 30 2pcs Back Frame 2pcs Seat Cushion 2pcs Seat Frame Bench Back Frame Bench Cushion Bench Seat Frame Table Glass Table Leg 2pcs Allen key 2pcs Table Side Frame...
- Page 4 STEP 2 STEP 1 (Single Chair Assembly) Connect part from STEP 1 & Left Frame (B) Connect Right Frame (A) & Seat Frame (D) with Bolt (1),(2) & Allen key with Bolt (1),(2) & Allen key STEP 4 STEP 3 Connect part from STEP 3 with Connect part from STEP 2 &...
- Page 5 STEP 5 Put on Seat Cushion (3) to complete Single Chair STEP 6 Connect Right Frame (A), Bench Seat Frame (F) with Bolt (1),(2) & Allen key.
- Page 6 STEP 7 Connect part from STEP 6, Left Frame (B) with Bolt (1),(2) & Allen key. STEP 8 Connect part from STEP 7, Bench Back Frame (E).
- Page 7 STEP 9 Connnect part from STEP 8 with Bolt (2) & Allen key. STEP 10 Put on Bench Cushion (4) to complete Bench.
- Page 8 STEP 12 STEP 11 Connect Table Leg (G), Table Side Connect part from STEP 11, Table Leg (G) Frame (H) with Bolt (2) & Allen key. with Bolt (2) & Allen key. STEP 14 STEP 13 Connect part from STEP 12, Table Side Put on Table Glass (5) to complete the Table.
