ASSEMBLY MANUAL
BRUKSANVISNING
NOTE: 50% TIGHTEN BEFORE FIXING ALL BOLTS
VIKTIGT – LÄS MONTERINGSANVISNINGARNA NOGA INNAN DU BÖRJAR
Please don't remove the batch code sticker at back side of this product!
Any feedback please take picture of this batch code for traceablity purpose
Ta inte bort ettiketten med batchnummer som finns på möbeln. Om du behöver hjälp med service eller reklamation av din möbel –
ange möblensbatchnummer till återförsäljaren, så att du kan få rätt reservdelar till just din möbel.
XX-YYWW
SKU: 166-1-64
Model name: Bäckviken
Modellnamn: Bäckviken
Konsumentkontakt
Arc E-commerce AB
Box 3124
13603 Haninge
Advertisement
Related Manuals for Lyfco Backviken 166-1-64
Summary of Contents for Lyfco Backviken 166-1-64
- Page 1 ASSEMBLY MANUAL BRUKSANVISNING NOTE: 50% TIGHTEN BEFORE FIXING ALL BOLTS VIKTIGT – LÄS MONTERINGSANVISNINGARNA NOGA INNAN DU BÖRJAR Please don’t remove the batch code sticker at back side of this product! Any feedback please take picture of this batch code for traceablity purpose Ta inte bort ettiketten med batchnummer som finns på...
- Page 2 Attention! Please note that at first all screws should be inserted slightly by hand! Turn 2-3 times so that the screw grips on its own and connects all elements loosely. The screws must only be driven in tightly when all elements are connected with each other in this way. Otherwise the setup won´t be possible.
- Page 3 Component Hardware Back frame 2 pcs Bolt M6x40mm 24 pcs Seat frame 3 pcs Bolt M6x35mm 62 pcs Side frame 2 pcs Bolt M6x25mm 40 pcs Connective back frame 1 pc Bolt M6x20mm 20 pcs Right frame 1 pc Gaslift 2 pcs Right back frame 1 pc...
- Page 4 Component Hardware Left back frame Seat cushion 5 pcs Left seat frame 1 pc Back pillow 5 pcs Left front frame 1 pc Small back pillow 2 pcs Table 1 pc Table glass 1 pc Ottoman 1 pc Connecting part 2 pcs Connecting frame 4 pcs...
- Page 5 Component Hardware Connecting frame 8 pcs 3 pcs Left side frame Front frame 3 pcs Bottom frame 3 pcs Right side frame 3 pcs...
- Page 6 STEP 1 ( Single sofa : 2 pcs) STEP 2 Connect Back frame (A) & Seat frame (B) Connect part from STEP 1 & Right side frame (Y) with Bolt (1) with Bolt (2) STEP 3 STEP 4 Connect part from STEP 2 & Front frame (X) Connect part from STEP 3 &...
- Page 7 STEP 5 STEP 6 Connect part from STEP 4 & Rain cover (17) Connect part from STEP 5 & Bottom frame (V) with Bolt (1) STEP 7 Connect part from STEP 6 & Leg soles (9) with Bolt (3)
- Page 8 STEP 8 ( Single Connective sofa : 1 pc) STEP 9 Connect part from STEP 8 & Right side frame (Y) Connect Connective back frame (D) & Seat frame (B) with Bolt (1) with Bolt (2) STEP 10 STEP 11 Connect part from STEP 9 &...
- Page 9 STEP 12 STEP 13 Connect part from STEP 11 & Rain cover (17) Connect part from STEP 12 & Bottom frame (V) with Bolt (1) In this STEP, don’t assembly the Leg soles (9)
- Page 10 STEP 14 STEP 15 Connect Right Back Frame (F) & Right Seat Connect part from STEP 14 & Right Frame (E) Frame (G) with Bolt (2) with Bolt (2) STEP 16 STEP 17 Connect part from STEP 15 & Side Frame (C) Connect part from STEP 16 &...
- Page 11 STEP 18 Connect Left Back Frame (J) & Left Seat Frame (K) with Bolt (2) STEP 19 STEP 20 Connect part from STEP 18 & Left Frame (I) Connect part from STEP 19 & Side Frame (C) with Bolt (2) with Bolt (2)
- Page 12 STEP 21 Connect part from STEP 20 & Left Front Frame (L) with Bolt (2) STEP 22 Connect part from STEPS 13, 17, 21 with Connecting part (6) & Bolt (4)
- Page 13 STEP 23 Connect part from STEPS 22 & Leg soles (9) with Connecting part (6) & Bolt (2) at this STEP don’t assemble washer on Bolt (2) STEP 24 Connect part from STEP 23 & Leg soles (9) with Bolt (3)
- Page 14 STEP 25 Connect part from STEP 24 & Connecting part (14) with Bolt (4) STEP 26 Connect 8 pcs Connecting Frame (T) &, 4 pc Connecting Frame (Q) with Screw (16)
- Page 15 STEP 27 Connect part from STEP 26 & Fabric (15) by inserting frames into holes on fabric STEP 28 Connect part from STEPS 27 & Connecting frame (P), (R),(S) with Screw (16) on STEP 26...
- Page 16 STEP 29 Connect part from STEPS 25, 28 with Bolt (4) STEP 30 Connect part from STEP 29 & Gaslift (5), Plastic washer (7) & Bolt (2)
- Page 17 STEP 31 STEP 32 Connect Table (M) & Leg soles (9) with Bolt (3) Put on Table Glass (13) to complete table STEP 33 STEP 34 Connect Ottoman (N) & Leg soles (9) with Bolt (3) Put on Table Glass (18) to complete ottoman...
- Page 18 STEP 35 Put on Seat cushion (10), Back pillow (11) & Small back pillow (12) to complete sofa...
