ASSEMBLY MANUAL
BRUKSANVISNING
NOTE: 50% TIGHTEN BEFORE FIXING ALL BOLTS
VIKTIGT – LÄS MONTERINGSANVISNINGARNA NOGA INNAN DU BÖRJAR
Please don't remove the batch code sticker at back side of this product!
Any feedback please take picture of this batch code for traceablity purpose
Ta inte bort ettiketten med batchnummer som finns på möbeln. Om du behöver hjälp med service eller reklamation av din möbel –
ange möblensbatchnummer till återförsäljaren, så att du kan få rätt reservdelar till just din möbel.
XX-YYWW
SKU:166-1-67
Haga
MODEL NAME: Haga
MODELLNAMN: Haga
Konsumentkontakt
Arc E-commerce AB
Box 3124
13603 Haninge
Advertisement
Table of Contents
Related Manuals for Lyfco Haga 166-1-67
Summary of Contents for Lyfco Haga 166-1-67
- Page 1 ASSEMBLY MANUAL BRUKSANVISNING NOTE: 50% TIGHTEN BEFORE FIXING ALL BOLTS VIKTIGT – LÄS MONTERINGSANVISNINGARNA NOGA INNAN DU BÖRJAR Please don’t remove the batch code sticker at back side of this product! Any feedback please take picture of this batch code for traceablity purpose Ta inte bort ettiketten med batchnummer som finns på...
- Page 2 Attention! Please note that at first all screws should be inserted slightly by hand! Turn 2-3 times so that the screw grips on its own and connects all elements loosely. The screws must only be driven in tightly when all elements are connected with each other in this way. Otherwise the setup won´t be possible.
- Page 3 Component Hardware 2 pcs Bolt M6x50 2 pcs Side Frame A Bolt M6x40 22 pcs 2 pcs Side Frame B 22 pcs Bolt M6x15 4 pcs Seat Frame C 2 pcs Seat Frame D 1 pc Frame 5 8 pcs 2 pcs Middle Frame E 4 pcs...
- Page 4 Step 1 Connect Side Frame (A) & Side Frame (B) with Bolt (2) Connect Middle Frame (E) & Middle Frame (E) with Bolt (1) & Nut (4) Step 2 Connect part from Step 1 & Seat Frame (C)
- Page 5 Step 3 Connect part from & Side Frame (D) with Bolt (2) Step 4 Connect part from step 3,Front Frame (G) & 4 x Frame (5) with Bolt (2)&(3)
- Page 6 Step 5 Connect part from Step 4 , Front Frame (G) & 4x Frame (5) with Bolt (2),(3) Step 6 Connect part from Step 5 , Side Frame (A), Side Frame (B) ,Connecting part (6) with Bolt (2),(3)
- Page 7 Step 7 Step 8 Connect Frame (F) & Fabric (8) Connect part from Step 7 & Frame (H) Step 9 Step 10 Do the same steps as Step 7 & Step 8 Connect part from Step 6 & Step 9 to complete canopy...
- Page 8 Step 11 Put on Seat Cushion (7) to complete 2 Seater Sun Lounger...
