ASSEMBLY MANUAL
BRUKSANVISNING
NOTE: 50% TIGHTEN BEFORE FIXING ALL BOLTS
VIKTIGT – LÄS MONTERINGSANVISNINGARNA NOGA INNAN DU BÖRJAR
Please don't remove the batch code sticker at back side of this product!
Any feedback please take picture of this batch code for traceablity purpose
Ta inte bort ettiketten med batchnummer som finns på möbeln. Om du behöver hjälp med service eller reklamation av din möbel –
ange möblensbatchnummer till återförsäljaren, så att du kan få rätt reservdelar till just din möbel.
XX-YYWW
SKU: 166-1-58
MODEL NAME: Kivik
MODELLNAMN:
Kivik
Konsumentkontakt
Arc E-commerce AB
Box 3124
13603 Haninge
Advertisement
Related Manuals for Lyfco Kivik 166-1-58
Summary of Contents for Lyfco Kivik 166-1-58
- Page 1 ASSEMBLY MANUAL BRUKSANVISNING NOTE: 50% TIGHTEN BEFORE FIXING ALL BOLTS VIKTIGT – LÄS MONTERINGSANVISNINGARNA NOGA INNAN DU BÖRJAR Please don’t remove the batch code sticker at back side of this product! Any feedback please take picture of this batch code for traceablity purpose Ta inte bort ettiketten med batchnummer som finns på...
- Page 2 Attention! Please note that at rst all screws should be inserted slightly by hand! Turn 2-3 times so that the screw grips on its own and connects all elements loosely. The screws must only be driven in tightly when all elements are connected with each other in this way. Otherwise the setup won´t be possible.
- Page 3 Hardware Component 1 pc 40 pcs Back Frame A Bolt M6x40mm 28 pcs Seat Frame B 1 pc Bolt M6x35mm Bolt M6x30mm 1 pc 30 pcs Front Frame C 2 pcs Side Frame D 12 pcs Bolt M6x20mm 7 pcs Back Frame E 1 pc Bolt M6x60mm...
- Page 4 Hardware Component 6 pcs Back Pillow 1 pc Front Frame 1 pc Round Table 2 pcs Table Glass 2 pcs Table Top Frame Round Table Glass 1 pc 4 pcs Pillow 3 pcs Side Table Frame 2 pc Seat Cushion 6 pcs Behind Table Frame 2 pcs...
- Page 5 Component Component 1 pc Seat Frame 1 pc Front Frame 1 pc Front Frame Side Frame 2 pcs Side Frame 2 pcs 1 pc Back Frame 1 pc Back Frame Front Frame 1 pc Front Frame 1 pc 1 pc Bottom Frame 1 pc Back Frame...
- Page 6 STEP 1 Connect Back Frame A (A) & Seat Frame B (B) with Bolt (1) STEP 2 Connect part from STEP 1 & Side Frame D (D) with Bolt (3)
- Page 7 STEP 3 Connect part from STEP 2 & Front Frame C (C) with Bolt (3) STEP 4 Connect back Frame E (E) & Seat Frame F (F) with Bolt (1)
- Page 8 STEP 5 Connect part from STEP 4 & Side Frame D (D) with Bolt (3) STEP 6 Connet part from STEP 5 & Front Frame G (G) with Bolt (3)
- Page 9 STEP 7 Connect part from STEP 3 & STEP 6 with Bolt (1), Connecting part (12) & Bolt (4), (5) & Nut (6) STEP 8 Put on Seat Cushion (11) & Back Pillow (7) to complete round sofa...
- Page 10 STEP 9 Connect Back Frame (A1) & Seat Frame (B1) with Bolt (1) STEP 10 Connect part from STEP 9 & Side Frame (D1)
- Page 11 STEP 11 Connect part from STEP 10 & Front Frame (C1) with Bolt (3) STEP 12 Connect Back Frame (E1) & Seat Frame (F) with Bolt (1)
- Page 12 STEP 13 Connet part from STEP 12 & Side Frame (D2) with Bolt (3) STEP 14 Connect part from STEP 13 & Front Frame (G1) with Bolt (3)
- Page 13 STEP 15 Connect part from STEPS 14 & 11 with Bolt (1), (5) & Nut (6), (4) & Connecting part (12) STEP 16 Connect part from STEP 15 & Rain Cover (O)
- Page 14 STEP 17 Connect part from STEP 16 & Bottom Frame (M) & (N) with Bolt (1), (5) & Nut (6) STEP 18 Put on Seat Cushion (11) & Back Pillow (7) to complete bench round sofa...
- Page 15 STEP 19 Connect Back Frame (E2) & Seat Frame (B3) with Bolt (1) STEP 20 Connect part from STEP 19 & Side Frame (D2) with Bolt (3)
- Page 16 STEP 21 Connect part from STEP 21 & Front Frame (G2) with Bolt (3) STEP 22 Connect Back Frame (A2) & Seat Frame (B2) with Bolt (1)
- Page 17 STEP 23 Connect part from STEP 22 & Side Frame (D1) STEP 24 Connect part from STEP 23 & Front Frame (C2) with Botl (3)
- Page 18 STEP 25 Connect part from STEPS 21 & 24 with Bolt (1), (4) & Connecting Part (12), (5) & Nut (6) STEP 26 Connect part from STEP 15 & Rain Cover (O1)
- Page 19 STEP 27 Connect part from STEP 26 & Bottom Frame (M1), (N1) with Bolt (1), (5) & Nut (6) STEP 28 Put on Seat Cushion (11) & Back Pillow (7) to complete bench round sofa...
- Page 20 STEP 30 STEP 29 Connect Table Top Frame (I) & Behind Table Connect part from STEP 29 & Table Side Frame (J) Frame (K) with Bolt (2) with Bolt (2) STEP 32 STEP 31 Connect part from STEP 30 & Front Table Put on Table Glass (8) to complete the table Frame (L) with Bolt (2)
