KINSHOFER P30VHD Service Manual

Orange peel grab
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Servicehandbuch für
Mehrschalengreifer
Service manual
Orange peel grab
for
Manuel de service
Grappin Multiprise
pour
P30VHD / P40VHD / P51VHD
June 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P30VHD and is the answer not in the manual?

Questions and answers

Related Manuals for KINSHOFER P30VHD

Summary of Contents for KINSHOFER P30VHD

  • Page 1 Servicehandbuch für Mehrschalengreifer Service manual Orange peel grab Manuel de service Grappin Multiprise pour P30VHD / P40VHD / P51VHD June 2017...
  • Page 2 Kopien können vom Hersteller gegen eine geringe Gebühr bezogen werden. Änderungen vorbehalten, die durch stetige Produktentwicklung und Produktverbesserung entstehen. Herausgeber der Originalbetriebsanleitung und Hersteller des Anbaugerätes: KINSHOFER GmbH Hauptstrasse 76 83666 Waakirchen Deutschland Tel.: +49 (0)8021 - 88 99 0 Fax: +49 (0)8021 –...
  • Page 3 KInshofer Technische Daten / Technical Data / Données techniques P30VHD 5 Greifarme / 5 Gripping arms / 5 Griffes Artikel-Nr. Anzahl der Greifarme Ladevolumen Traglast Gewicht Type The gripping arms Capacity Capacity Weight Article No. Nombre de griffes Capacité Capacité...
  • Page 4 KInshofer P40VHD Artikel-Nr. Anzahl der Greifarme Ladevolumen Traglast Gewicht The gripping arms Capacity Capacity Weight Type Article No. Nombre de griffes Capacité Capacité Poids kg / lb P40VHD-600-4-H P40VHD060BVH5 1610 / 3542 1555 / 3420 P40VHD-600-4-W P40VHD060BVW5 P40VHD-600-5-H P40VHD060BFH5SK 1820 / 4004...
  • Page 5 KInshofer P51VHD Artikel-Nr. Anzahl der Greifarme Ladevolumen Traglast Gewicht Type Article No. The gripping arms Capacity Capacity Weight Nombre de griffes Capacité Capacité Poids kg / lb P51VHD-1000-4-W P51VHD100BVW5SK 1750 / 3850 P51VHD-1000-5-F P51VHD100BFF5 2165 / 4763 P51VHD-1000-5-H P51VHD100BFH5SK 2110 / 4642...

  • Page 6: Table Of Contents

    KInshofer Inhaltsverzeichnis / Content Dismantling the Grab ..................7 Replacing the Sealings in the Hydrauilc Cylinder .............12 Mounting the Grab..................13 Replacement of the Bearing Bushings ............17 Maintenance and Exchange of the Tine-Tip ..........18 Maintenance ......................18 Exchange of the tine-tip ....................18 Screw Survey and Fastening Torques ............

  • Page 7: Dismantling The Grab

    KInshofer Dismantling the Grab Warning from unexpected operation! Secure the lifting device in a way that it cannot be operated during any (maintenance) works. • Lower the orange peel grab in almost complete open position onto an adequate ground (for example table).
  • Page 8 KInshofer Then loosen and remove the cylinder screw (61, M16) between cylinder protection (60) and the lug of the piston rod eye. Now remove the cylinder protection (60) for the hydraulic cylinder. Then strike out the bolt (80) that connects the centre piece (10) and the hydraulic cylinder (40).
  • Page 9 KInshofer • Dismantle the rotary drive (70). Clean and loosen the hydraulic connections at the flange rotary feedthrough (D70), collect leaking oil. Fig. 1.6 Remove the bolts (D130) on the head unit D120 (D10). Now remove the cover (D120) and valve guard (D110).
  • Page 10 KInshofer Then loosen and remove the locking screws (D11, M16), that connect the head unit (D10) and the slewing ring (D20). Remove the head unit (D10) with individual components. Fig. 1.9 Then unscrew the hexagon head cap screws (D21, M16), that connect the slewing ring (D20) and the centre piece (10) of the grab.
  • Page 11 KInshofer Loosen the cylinder screws (D91, M12) on the left and right connection blocks (D90). Lift the connection blocks (D90) with screw fittings (D92) forwards out of the head unit (D10). D90 D92 Fig. 1.12 Now remove the rotary feedthrough (D60).

  • Page 12: Replacing The Sealings In The Hydrauilc Cylinder

    KInshofer Replacing the Sealings in the Hydrauilc Cylinder Unscrew the piston rod cpl. (20) with rod guide and piston from the cylinder tube (10) and pull out of the cylinder. Replace all sealings (30, 40, 50) without damaging the new sealings.

  • Page 13: Mounting The Grab

    KInshofer Mounting the Grab • See chapterl table (page 21) for the tightening torques. Place the oil distributor (80) on the weld- on plate (90) in the centre piece (10), align it and fix it with four safety screws (81, M12).
  • Page 14 KInshofer • Then install the gripping arm (20). Push the gripping arm (20) with arm head and washer discs (32) between the bearing lugs of the centre piece (10) and beneath the piston rod eye. Align the upper bore of the gripping arm...
  • Page 15 KInshofer • Mount the rotary drive (70). Fix the adapters right and left (D80) with four safety screws each (M12) at the rotary feedthrough (D60). Place the rotary feedthrough (D60) with adapters right and left (D80) in the head piece (D10) and secure with four cylinder screws (D61, M16).
  • Page 16 KInshofer Place the slewing ring (D20) onto the centre piece (10) of the grab and secure with thirty hexagon head cap screws (D21, M16x75). Fig. 2.9 Fit a V-ring (13) to the round tube on the centre piece (10). Fit the head unit (D10), with the individual...

  • Page 17: Replacement Of The Bearing Bushings

    KInshofer Now secure the valve guard (D110) to the D120 head unit (D10) with four locking screws (M16). Then install the cover (D120) and fasten it to the head unit with a locking screw D130 (M16) at the rear and with a locking screw at each side (M10).

  • Page 18: Maintenance And Exchange Of The Tine-Tip

    KInshofer Maintenance and Exchange of the Tine-Tip Maintenance Renew worn tine tips by hard-facing at regularly spaced time intervals. Weld metal: DIN EN 14700: S Z Fe6 DIN 8555: MSG 6-GZ-60-CG We.-Nr. 1.4718 Particularly, use on asphalt and concrete ground is very abrasive for the tine tips.
  • Page 19 KInshofer 2. Cut the inner band just beyond the 100 mm line, with a circular saw mounted on an angle grinder, approx. 17-20mm deep at a right angle to the outer surface. Cut the outer band approx. 12-15mm deep at a right angle to the outer surface.
  • Page 20 KInshofer Flame cutter 3. Carefully burn through the sides of the remains of the tip to remove it completely, and remove any remaining welded seams. Flame cutter 4. Fit on the new tip. New tip P51V-HD 26.02.2018...

  • Page 21: Screw Survey And Fastening Torques

    KInshofer 5. Weld on the new tip. Weld metal:: DIN EN 12070 Mn3Ni1CrMo (AWS A5.18/5.28: ER100S-G) Welding apparatus Screw Survey and Fastening Torques Table 1 (4 arms) Screw and nut type Screw and nut Fastening torque size and quality Safety nut (Pos. 62; 4x) M16;...
  • Page 22 KInshofer Table 3 (rotary drive 770067572SK) Screw and nut type Screw and nut Fastening torque size and quality Safety nut (Pos. D132; 1x) M48x3; 8 410-450 Cylinder screw (Pos. D71; 6x) M10x50; 8.8 Cylinder screw (Pos. D91; 8x) M12x45; 10.9 Cylinder screw (Pos.

  • Page 23: Ersatzteil-Stücklisten Und Zeichnungen / Spare Parts List And Drawing

    KInshofer Ersatzteil-Stücklisten und Zeichnungen / Spare parts list and drawing Allgemeines Die folgenden Seiten informieren über die verfügbaren Ersatzteile, die in den Explosionszeichnungen leicht zu finden sind. Bestellung Für eine Bestellung von Ersatzteilen müssen die Artikelnummer, die Stückzahl und die Seriennummer des Gerätes (auch als Gerätenummer bezeichnet) angegeben werden.

  • Page 24: Mehrschalengreifer / Orange Peel Grab P51Vhd (Blatt 1)

    KInshofer Mehrschalengreifer / Orange peel grab P51VHD (Blatt 1) P51V-HD 26.02.2018...
  • Page 25 KInshofer Pos. Bezeichnung Description Désignation Artikel-Nr. Menge Abmessung Order No. Qty. Dimension Pièce N°. Nbre. und/and/et Bemerkung Remarks Remarque 4 Arme 5 Arme 4 arms 5 arms 4 griffe 5 griffe Mittelstück centre part pièce centrale 645068985SK 645067556SK plaque de...

  • Page 26: Mehrschalengreifer / Orange Peel Grab P51Vhd (Blatt 2)

    KInshofer Mehrschalengreifer / Orange peel grab P51VHD (Blatt 2) P51V-HD 26.02.2018...
  • Page 27 KInshofer Pos. Bezeichnung Description Désignation Artikel-Nr. Menge Abmessung Order No. Qty. Dimension Pièce N°. Nbre. und/and/et Bemerkung Remarks Remarque 4 Arme 5 Arme 4 arms 5 arms 4 griffe 5 griffe Hydraulik- vérin zylinder hydraulic ram hydraulique 201064825 80/50x274 rondelle pour Stützscheibe...

  • Page 28: Servicepaket / Service Package

    KInshofer Mehrschalengreifer / Orange peel grab P51VHD (Blatt 3) Servicepaket / Service package P51V-HD 26.02.2018...
  • Page 29 KInshofer Pos. Bezeichnung Description Désignation Artikel-Nr. Menge Abmessung Order No. Qty. Dimension Pièce N°. Nbre. und/and/et Bemerkung Remarks Remarque 4 Arme 5 Arme 4 arms 5 arms 4 griffe 5 griffe Ölverteiler oil-distributer distributeur 272056936 Sicherungs- M12x 20 verzinkt schraube...

  • Page 30: Hydraulikzylinder / Hydraulic Ram 201064825

    KInshofer Hydraulikzylinder / Hydraulic ram 201064825 Montagehinweise / Mounting instructions / Instructions d’assemblage Verschraubung Gewinde Anziehmoment Sicherung Threaded union Screw thread Tightening moment Thread securing Raccord à vis Filetage Couple de démarrage Frein d’écrou Verschraubung G 1/2’’ 170 Nm verkleben / to glue...
  • Page 31 KInshofer Pos. Bezeichnung Description Désignation Artikel-Nr. Menge Abmessung Bemerkung Order No. Qty. Dimension Remarks Pièce N° Nbre. Remarque tuyau Zylinderrohr cylinder tube cylindrique 229064826 PEL-HP Buchse PEL- HP bushing PEL-HP bague 135059026 50x60x30 XGE 16-SR G1/2" Verschraubung screw fitting raccord 291010223 M24x1.5...

  • Page 32: Drehantrieb / Rotary Drive 770067572Sk (Blatt 1)

    KInshofer Drehantrieb / Rotary drive 770067572SK (Blatt 1) P51V-HD 26.02.2018...
  • Page 33 KInshofer Pos. Bezeichnung Description Désignation Artikel-Nr. Menge Abmessung Bemerkung Order No. Qty. Dimension Remarks Pièce N° Nbre. Remarque Kopfteil rotator head pièce de tête 560067547SK M16x50 verzinkt Sicherungsschraube locking screw vis de blocage 120013843 Tensilock 100 Drehverbindung rotary union raccord tournant 168055476 ø...

  • Page 34: Drehantrieb / Rotary Drive 770067572Sk (Blatt 2)

    KInshofer Drehantrieb / Rotary drive 770067572SK (Blatt 2) P51V-HD 26.02.2018...
  • Page 35 KInshofer Pos. Bezeichnung Description Désignation Artikel-Nr. Menge Abmessung Bemerkung Order No. Qty. Dimension Remarks Pièce N° Nbre. Remarque bloc de Anschlussblock terminal block connexion 773067668SK GE 20-SR nicht gezeichnet D90.1 Verschraubung fitting raccord 291060150 M30x2 not shown G1" EVW 20-S/M30x2 nicht gezeichnet D90.2...

  • Page 36: Drehdurchführung / Swivel 207058287

    KInshofer Drehdurchführung / Swivel 207058287 P51V-HD 26.02.2018...
  • Page 37 KInshofer Pos. Bezeichnung Description Désignation Artikel-Nr. Menge Abmessung Bemerkung Order No. Qty. Dimension Remarks Pièce N° Nbre. Remarque DD10 Gehäuse casing boîtier 241500833 VS R1/4“ WD- DD11 Verschlussschraube screw plug bouchon fileté DR500650 Viton DD12 Axial Ring axial ring anneau axiale...

  • Page 38: Drehdurchführung / Swivel 207072053

    KInshofer Drehdurchführung / Swivel 207072053 P51V-HD 26.02.2018...
  • Page 39 KInshofer Pos. Bezeichnung Description Désignation Artikel-Nr. Menge Abmessung Bemerkung Order No. Qty. Dimension Remarks Pièce N° Nbre. Remarque DD10 Gehäuse casing boîtier 241500833 bouchon fileté VS R1/4“ WD- DD11 Verschlussschraube screw plug DR500650 Viton DD12 Axial Ring axial ring anneau axiale...

  • Page 40: Drehdurchführung / Swivel 207077425

    KInshofer Drehdurchführung / Swivel 207077425 P51V-HD 26.02.2018...
  • Page 41 KInshofer Pos. Bezeichnung Description Désignation Artikel-Nr. Menge Abmessung Bemerkung Order No. Qty. Dimension Remarks Pièce N° Nbre. Remarque DD10 Gehäuse casing boîtier 241500833 DD20 Flanschwelle flange shaft arbre à bride 244075086 DD30 Deckel cover couvercle 220075085 deep grove ball roulement...
  • Page 42 Doherty Couplers & Attachments PO Box 9339, Greerton Tauranga 3142 Tel.: +64 7 574 3000 Fax: +64 7 574 8030 Email: sales@dohertydirect.net www.dohertydirect.net KINSHOFER is an ISO 9001 certified Company DVS ZERT is a registred trademark of DVS ZERT e.V., Düsseldorf...
