Mounting
1. Switch off the power supply to the distribution box where the
unit will be fixed.
2. Fix the device on the rail.
3. Connect the wires of the counting input to terminals 5 and 6.
4. Switch on the power supply to the distribution box and the
counter.
Wiring diagram
- 2 -
