Summary of Contents for Ecosy+ Hampton 6.4 DoubleSided
- Page 1 WWW.ECOSYSTOVES.CO.UK Ecosy+ Hampton 6.4 Double Sided Installation and Operating Instructions Page 1 of 13...
- Page 2 Version 1.1: 10/10/2019 Wood-burning / Multi-Fuel Stove Model: Ecosy+ Hampton 6.4 Double Side Dimensions: SAFETY Safety is the most important consideration when using and installing your stove. If not installed and used correctly, a house fire could result. Installation must comply with relevant national and local Building Regulations and fire safety standards.
-
Page 3: Installation
Your stove will have several of its components stored inside the stove itself for transportation. The main component is the flue collar; this will simply need attaching with the provided bolts. All vermiculite fire bricks inside the stove must remain in place, these are not a part of the packaging. INSTALLATION Installation of your stove must comply with relevant local and national Building Regulations and fire safety standards. - Page 4 All tests carried out at Kiwa Gastec UK Your stove will require a constant air supply and should not be used at the same time and in the same room/space as extractor fans or any device which may draw air supply away from the stove unless the stove is taking air directly from the outside through a pipe connect to the 100mm outlet on the stoves base.
- Page 5 under Section 16 of the Environmental Better regulation Act (Northern Ireland) 2016. In Wales appliances are exempted by regulations made by Welsh Ministers. Further information on the requirements of the Clean Air Act can be found here: https://www.gov.uk/smoke-control-area-rules The Ecosy+ - Hampton 6 has been recommended as suitable for use in smoke control areas when burning seasoned wood logs.
- Page 6 It is always important to load your stove at the correct time. If there is insufficient burning material in the fire bed to light a new fuel charge, excessive smoke emission can occur. Refuelling must be carried out onto a sufficient quantity of glowing embers and ash that the new fuel charge will ignite in a reasonable period.
-
Page 7: Air Inlet Controls
FUEL Wood – When burning wood, you want to ensure that the grate is closed. To do this, you simply push the bar on the side of the stove. Having this closed creates a better burn for wood - All types of wood are suitable provided they are well seasoned, UNTREATED, and have a moisture level between 12% and 20%. - Page 8 side and is fed over the glass, helping it to keep clean and clear of smoke stains. When the lever is pulled towards you, more air is fed into the fire, pushed away from you decreases the amount of air into the fire.
- Page 9 Ignition (FOLLOW INITITAL TEMPERING INSTRUCTIONS ABOVE FIRST TO AVOID DAMAGE) Construct a pile of kindling in the middle of the bed using approx 500g of kindling wood Light with a single chemical firelighter Partially shut the door but leaving it cracked open slightly After about 5 minutes or when the fire is well established, shut the door After a further 3-5 minutes as the fire starts to die, add a further three larger pieces of wood weighing approx.
-
Page 10: Cleaning & Maintenance
Operation with the air controls or appliance dampers open can cause excess smoke. The appliance must not be operated with air controls, appliance dampers or door left open except as directed in the instructions. WARNING- The high temperature paint covering the stove will give off some fumes during the initial few uses of the stove. - Page 11 chimney sweep or stove installer. For example, HETAS / METAC / NACS. In this service any perishable parts that are damaged will need replacing. Please keep hold of these receipts, as they will most likely be required in an unlikely event that a claim was to be made. We will only ever be liable for the stove itself and will not cover the cost of installation or de-installation of a product.
- Page 12 Cloudy, 'milky' or crazed glass is caused by unburned acidic condensates etching the ceramic glass and unfortunately this cannot be easily removed. It is definitely not faulty glass but instead does have more to do with the quality of the fuel that you burn and the way that you operate your stove (long slumbering).
- Page 13 -Ecosy+, Unit 22-26 – Folly farm, Ramsdell, Tadley, RG26 5GJ Page 13 of 13...
