- Page 1 Hampton 5 Large Page 1 of 15...
- Page 2 Version 1.1: 08/10/2018 SAFETY Safety is the most important consideration when using and installing your stove. If not installed and used correctly, a house fire could result. Installation must comply with relevant national and local Building Regulations and fire safety standards. IN THE EVENT OF A CHIMNEY FIRE, EVACUATE THE PROPERTY AND CALL THE EMERGENCY SERVICES.
-
Page 3: Installation
HETAS website – www.hetas.co.uk. If you are self- installing the stove must be signed off by the local authority. Technical Hampton 5 Large Weight 80kg Total Efficiency 83.9 % Nominal heat output kW 5.00 Mean CO emission (at 13 % O2) 0.06%... - Page 4 Suitable for a direct air feed / Sealed air – 100mm spigot on the stoves rear. Distances to combustibles: Back Wall – Including heat shield (optional extra) 250mm Back Wall –(without heat shield) 400 mm from the rear most point on the stove. If you purchase and fit the rear flue box as an optional extra the distance to combustibles will be 400 mm from the back of this box.
-
Page 5: Optional Extras
This stove cannot be installed into a shared flue. Optional Extras Heat shield – This can be bolted to the stoves rear and reduces distances to combustibles at the back of stove from 400mm to 250mm. The heat shield cannot be used at the same time as the flue box (below) The standard 125mm flue collar that comes with the stove can be used on the top or rear of the fire though. - Page 6 Further information on the requirements of the Clean Air Act can be found here: https://www.gov.uk/smoke-control-area-rules The Ecosy+ - Hampton 5 Large SE has been recommended as suitable for use in smoke control areas when burning seasoned wood logs. The appliance has a factory-fitted modification to the secondary air control to prevent closure beyond 4mm open position.
- Page 7 FUEL Wood- All types of wood are suitable provided they are well seasoned, UNTREATED, and have a moisture level between 12% and 20%. For soft woods, typically they will need to have been left in suitable storage for 9+ months for the moisture to evaporate. For hardwoods, this will usually be 18 months+.
-
Page 8: Air Controls
AIR CONTROLS Base lever - This controls the Secondary/Airwash and Tertiary burn system. Air is drawn through the rear and is fed over the fire through a series of holes above the bricks and on the baffle itself. This helps to burn off the initial smoke and gasses produced by the fire, prior to it going up the chimney. Air also flows past these holes and is fed over the glass through an internal layer of steel, helping it to keep clean and clear of smoke stains. - Page 9 Tools The glove is provided for adjusting the air inlets and for opening the door when the stove is hot, as these knobs will heat up when in use. NOTE – all parts of the stove will become hot during use and care needs to be taken to avoid injury through burning.
- Page 10 ‘normalising’ to release stresses in the metal formed during the casting process. The paint finish also requires an initial curing process to be followed and will release a smell when burning off: - You will need to have at least two Controlled kindling wood fires with each fire lasting around 40 minutes –...
- Page 11 When the stove is new the paint is very tacky where the stove is curing. The door locks very tight and when opened can pull away the fire rope from its chamber. If the instructions are followed above this should not happen. However, if it does the rope will need to be stuck back in place with “heat resistant fire rope glue”...
- Page 12 Air controls left open Operation with the air controls or appliance dampers open can cause excess smoke. The appliance must not be operated with air controls, appliance dampers or door left open except as directed in the instructions. WARNING- The high temperature paint covering the stove will give off some fumes during the initial few uses of the stove.
- Page 13 when it does eventually require re-finishing, black heat resistant paint in spray cans can be purchased from most hardware stores but we would suggest using “Calfire flat black paint”. – Do not use regular paint which is not high temperature resistant. After prolonged periods of not using the fire, the stove and flue system should be checked for blockages prior to relighting.
- Page 14 your local authority. Please keep hold of the invoice as this will be requested if a claim started, if this is not provided upon request, we will not be able to escalate your claim. The guarantee will begin from the sale date on the invoice and we do not cover any cost incurred when removing faulty appliances or installing new ones, even if it has been proven that the stove is faulty.
- Page 15 Page 15 of 15...
