Technical Data; Size 05 - D681 Proportional Valve - Moog D680 Series Manual

technical data

technical data

siZe 05 - d681 ProPortional valve

siZe 05 - d681 ProPortional valve
General technical Data
technical data and characteristic curves measured with system pressure p
and oil temperature +40 °c (+104 °f).
Valve design
Pilot valve
Pilot connection X and Y
Mounting pattern
installation position
Weight
Weight including fail-safe valve
storage temperature range
ambient temperature range
Vibration resistance
shock resistance
Hydraulic Data
operating pressure pilot valve
minimum pressure
operating pressure range X port
maximum pressure y port
Maximum operating pressure of main stage
port p, a, B
port t at y internal
port t at y external
rated flow at Δp
n
Maximum flow
Main stage leakage flow (≈ zero lap)
Pilot leakage flow
Pilot flow for 100 % step
Hydraulic fluid
temperature range
Viscosity range
recommended viscosity range at 38 °c (100 °f)
maximum permissible viscosity range at 38 °c (100 °f)
recommended cleanliness class according to iso 4406
for functional safety
for longer service life
1) unbiased pilot valve for fail-safe options w
2) Biased pilot valve for fail-safe options d, f, m and u
3) pressure peaks up to 210 bar (3,000 psi) permissible
4) the cleanliness of the hydraulic fluid strongly affects functional safety (e.g. safe positioning of the spool, high resolution) and wear
of lands (e.g. pressure gain, leak losses).
rev. c, april 2017 rev. c, april 2017
3)
3)
5 bar (75 psi)/spool land
moog d680 series proportional control valves moog d680 series proportional control valves
of 210 bar (3,000 psi), oil viscosity 32 mm
p
2-stage, with standard spool
d633 unbiased
1)
internal or external
iso 4401-05-05-0-05 with t
any
8 kg (17.6 lb)
9.7 kg (21.4 lb)
-40 to +80 °c (-40 to +176 °f)
-20 to +60 °c (-4 to +140 °f)
30 g, 3 axis, 10 hz to 2 khz
50 g, 6 directions
10 bar (145 psi) above t or y
10 to 350 bar (145 to 5,000 psi)
70 bar (1,000 psi)
350 bar (5,000 psi)
70 bar (1,000 psi)
250 bar (3,625 psi)
30/60/80/2 x 80 l/min (7.9/15.9/21.1/2 x 21.1 gpm)
180 l/min (47.6 gpm)
1.8 l/min (0.48 gpm)
0.4 l/min (0.1 gpm)
6.0 l/min (1.6 gpm)
hydraulic oil as per din 51524 parts 1 to 3 and iso 11158.
other fluids upon request.
-20 to +80 °c (-4 to +176 °f)
15 to 45 mm /s (cst)
2
5 to 400 mm /s (cst)
2
4)
18/15/12
17/14/11
2
d633 biased
2)
1
6.5 l/min (1.7 gpm)
/s
