Summary of Contents for Jabra Speak 710
- Page 1 Jabra Speak 710 User manual...
- Page 2 ® © 2021 GN Audio A /S. All rights reserved. Jabra is a ® trademark of GN Audio A/S. The Bluetooth word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by GN Audio A/S is under license.
- Page 3 1. Welcome .........5 2. Overview .........6 3. Where To Position ......7 3.1 Small meeting room 3.2 Large meeting room 3.3 Desk 3.4 Stereo media 4. How To Charge ......11 4.1 USB charging 4.2 Automatic power off 4.3 Battery status 5.
- Page 4 7. Software ........23 7.1 Jabra Direct 7.2 Update firmware 8. Support ........24 8.1 FAQ and technical specifications 8.2 How to care for your Jabra device...
- Page 5 1. Welcome Thank you for using the Jabra Speak 710. We hope you will enjoy it! Jabra Speak 710 features • Immersive sound for calls and music • Intuitive plug and play connectivity - connect to computer via USB or Bluetooth adapter, or smartphone and tablet via Bluetooth •...
- Page 6 Battery status button button Volume down Volume up button button Link button Microsoft Teams button Answer call Power on/off End call button button button jabra USB cable Table stand and Jabra Link 380 USB-A Bluetooth adapter Bluetooth adapter storage Pouch...
- Page 7 3. Where to position 3.1 Small meeting room Position the speakerphone in the center of the table, up to 2m/6ft from each participant. A single Jabra Speak 710 is ideal for up to 6 people. 2m/6ft...
- Page 8 2m/6ft To temporarily link the audio between two Jabra Speak 710s, tap the Link button on both speakerphones when they are within 2m/6ft. max 2 m/6 ft jabra...
- Page 9 3.3 Desk When using the Jabra Speak 710 at your desk it is recommended to put the speakerphone into an upright position using the table stand. This will better direct the audio towards you for a richer music media experience.
- Page 10 To temporarily link the audio between two Jabra Speak 710s, tap the Link button on both speakerphones when they are within 2m/6ft. max 2 m/6 ft jabra...
-
Page 11: How To Charge
4.1 USB charging Plug the Jabra Speak 710 into a USB power source using the attached USB cable. The Jabra Speak 710 battery lasts for up to 15 hours of talk time and takes approx. 3 hours to fully charge. -
Page 12: Battery Status
4.3 Battery status To view the current battery status, tap the Battery status button. The LEDs around the edge of the Jabra Speak 710 will light up to indicate the current battery status. Medium battery Low battery... -
Page 13: How To Connect
The Bluetooth range is up to 30m. jabra For the Jabra Speak 710 to work correctly you may need to set the Jabra Link 380 Bluetooth adapter as the playback device in your operating system’s audio settings and in... - Page 14 5.2 Connect to computer (USB cable) Plug the Jabra Speak 710 into a USB port on your computer. You may need to set the Jabra Speak 710 as the playback device in your operating system’s audio settings and in Microsoft Teams’ audio settings.
-
Page 15: How To Use
The Microsoft Teams button, Link button, and Mute button will only be visible under certain conditions (e.g. the Link button is only visible when the Jabra Speak 710 is in close promixity to another Jabra Speak 710). - Page 16 6.2 Typical use WHAT Hold (1 sec) the Power Power on or off button Answer call Tap the Answer call button End or reject Tap the End call button call Turn on/off Hold (8 secs) the End call voice guidance button Volume down/ Tap (or hold) the Volume up...
-
Page 17: Multiple Call Handling
WHAT Tap the Link button (only Link two Jabra visible when within 2m/6ft Speak 710s range of another Jabra Speak 710) Bring Microsoft Teams to Tap the Microsoft Teams foreground on button* computer Join Microsoft Tap the Microsoft Teams Teams meeting... -
Page 18: Link Button
If two Bluetooth devices are currently connected to one of the Jabra Speak 710s, the last connected Bluetooth device will temporarily be replaced by the Jabra 710 link. When the Jabra 710s are unlinked, the Bluetooth device connection that was temporarily replaced, will be restored. - Page 19 The Microsoft Teams button is only visible when you are logged into Microsoft Teams, and behaves differently depending on the current status of Microsoft Teams. jabra JABRA SPEAK 710 LEDS WHAT THE LEDS MEANS Connected to Microsoft Solid LED Teams Notifications •...
- Page 20 When Microsoft Teams is running but is minimized, tap the Microsoft Teams button to maximise it to the foreground. 6.6 Voice guidance The voice guidance can be turned on or off by holding the End call button for 8 seconds. jabra...
- Page 21 6.7 Shared use If the Jabra Speak 710 is to be shared by many users, it is recommended to enable Shared use, which can be configured in Jabra Direct. When Shared use is enabled, the speakerphone will not automatically connect to a previously connected Smartphone or Jabra Link 380 Bluetooth adapter.
-
Page 22: Factory Reset
6.8 Factory reset Resetting the Jabra Speak 710 clears the list of paired Bluetooth devices and also clears all personalized settings. After a factory reset, it is necessary to re-pair the Jabra Speak 710 to your Bluetooth devices and Jabra Link 380 Bluetooth adapter. -
Page 23: Update Firmware
7.2 Update firmware Firmware updates improve performance or add new functionality to Jabra devices. 1. Connect the Jabra Speak 710 to a computer using the USB cable or Jabra Link 380 Bluetooth adapter. 2. Use Jabra Direct to check for the latest firmware updates. - Page 24 • The Jabra Speak 710 is for indoor use only. • Avoid storage at extreme temperatures (above 60°C/140°F or below -40°C/-40°F). • Do not expose the Jabra Speak 710 to rain or other liquids. • Do not cover the Jabra Speak 710 speaker...
