York International TM9T060B12MP11 Quick Reference Manual

NOTES:
1. Refer to the condensate management and drain hose
plumbing for different configurations in this document. No
hose clamps are needed for the condensate pan hook up.
2. Drip leg in the gas line must be installed.
3. The furnace controls require correct polarity on the power
supply and a proper ground.
4. Y & G must be connected to the control board for cooling
operation.
5. Measure the supply air static pressure after the furnace
before the indoor coil. Record this positive number. Measure
the return air static pressure after the filter. Record this neg-
ative number. Treat the negative number as a positive num-
ber, and add it to the recorded supply static pressure
reading. This sum is the total system external static pres-
sure.
Airflow CFM (Bottom Return without Filters)
Models
0.5" ESP (Nominal)
Low Med-Lo
TM9T060B12MP11 713 872
TM9T080B12MP11 854 1008
TM9T080C16MP11 838 1250
TM9T100C16MP11 819 1224
TM9T100C20MP11 1183 1430
TM9T120D20MP11 1190 1430
Input
Total Unit
Rate
Models
Max Min
TM9T060B12MP11 60,000 39,000
TM9T080B12MP11 80,000 52,000
TM9T080C16MP11 80,000 52,000
TM9T100C16MP11 100,000 65,000
TM9T100C20MP11 100,000 65,000
TM9T120D20MP11 120,000 72,000
†
Other airflows are available. see Tech Guide for all CFM options.
LED INDICATOR
Indication
Slow Green Flash
Slow Amber Flash
Any Red Flash
Any Rapid 4 Flashes
Subject to change without notice. Printed in U.S.A.
Copyright © 2018 by Johnson Controls, Inc. All rights reserved.
York International Corp.
Norman, OK 73069
6. Inlet gas pressure for natural gas should be 7" and that for
propane should be 11" w.c. Nominal manifold gas pressure
is 3.5" for natural gas and 10" w.c. for propane at high fire
and 1.6" for Natural gas and 4.0" for Propane on low fire.
7. If thermoplastic indoor coil drain pans are to be installed in
the up-flow/horizontal configuration, then extra 2" minimum
spacing may be needed to ensure against drain pan distor-
tion.
8. External filters required on all configurations.
9. Electrical entry is available on both sides of the casing.
10. All 33", 95% furnaces are approved for single-pipe and 2-
pipe systems. For single pipe systems it is recommended to
install the combustion air coupling provided and install
approximately 18" of PVC pipe on the furnace.
11. Do not install an external condensate trap on these fur-
naces, as it will prevent the unit from operating correctly.
Gas Pipe Fuse or Circuit
†
Connection, NPT
Med-Hi High
1082 1243 1/2"
1179 1370 1/2"
1465 1671 1/2"
1477 1706 1/2"
1712 1934 1/2"
1739 1977 1/2"
Time For 1 ft
Air Temp. Rise Air Temp. Rise
(1030 Btu/Ft
Amps Max Input °F Min Input °F
(On Max. Rate)
8.9 35 - 65 35 - 65
8.9 45 - 75 20 - 50
10.5 45 - 75 25 - 55
10.5 35 - 65 35 - 65
16 45 - 75 20 - 50
16 45 - 75 35 - 65
Condition
Normal operation.
Normal operation with call for heat.
Fault Condition.
Potential fault codes / conditions.
1083297-URG-B-0918
Supersedes: 1083297-URG-A-0114
5005 York Drive
This document does not replace the installation instructions, which must be referred to for
detailed information.
SUPPLY END
.56"
23.8"
Combustion
B
Air Inlet
.56"
.56"
20"
Combustion Air Inlet
Breaker
Condensate Drain
15
(Downflow)
15
Vent Connection
Outlet
15
15
20
20
3
Natural Gas
3
) Seconds
62
46
46
LEFT SIDE
37
37
Follow all national and local codes and standards in addition to this document.
The installation must comply with regulations of the serving gas supplier, local building,
31
heating, plumbing, and other codes. In absence of local codes, the installation must comply
with national codes and all authorities having jurisdiction.
DIMENSIONS:
CLEARANCES:
Application
Top
Vent
Rear
Side
1
Front
Floor
Closet
Line Contact
1. 24" clearance in front and 18" on side recommended for service access.
2. For combustible floors only when used with special sub-base.
QUICK REFERENCE GUIDE
96% TWO STAGE PSC MULTI-POSITION
RESIDENTIAL GAS FURNACES (33" TALL)
RETURN END
2" Diameter
Vent Connection
3"
Outlet
24.25"
Combustion Air Inlet
Gas Pipe
Condensate Drain
Entry
(Downflow)
Electrical
Entry
Vent Connection
Outlet
Condensate
Drain 23"
Thermostat
Wiring
Optional Return Air
Cutout (Either side)
28.5"
29.5"
RIGHT SIDE
Cabinet Size
All 'B' Cabinet Furnaces
All 'C' Cabinet Furnaces
All 'D' Cabinet Furnaces
All furnaces approved for alcove and attic installation.
Upflow Downflow
1"
0"
0"
0"
0"
Combustible
Combustible
Yes
No
B
Clips can be flipped
into the up position
for coil cabinet or
plenum attachment
A-COIL
14"
1"
33"
1.5"
A
FRONT
A (in) B (in)
17-1/2" 16-3/8"
21" 19-7/8"
24-1/2" 23-3/8"
Horizontal
0" 0"
0" 0"
0" 0"
0" 1"
0" 0"
2
Combustible
Yes Yes
No Yes
