SMC Networks LAT3 Series Operation Manual

Card motor
Hide thumbs Also See for LAT3 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Doc No. LA-OMP0023-D
PRODUCT NAME
Card Motor
MODEL / Series / Product Number
LAT3 Series
Controller
Series
LATCA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LAT3 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SMC Networks LAT3 Series

Summary of Contents for SMC Networks LAT3 Series

  • Page 1 Doc No. LA-OMP0023-D PRODUCT NAME Card Motor MODEL / Series / Product Number LAT3 Series Controller Series LATCA...
  • Page 2 About this operation manual This operation manual summarizes how to operate the LAT3 Card Motor. For operation of the Card motor Controller, refer to the operation manual for the [Card Motor Controller]. For initial setting and installation of the LAT3 Card Motor refer to the operation manual [Card Motor Simple Setting Manual].

  • Page 3: Table Of Contents

    Contents 1. Safety Instructions ..............3 2. Product Outlines ..............5 2. 1 How to Order ................5 2. 2 System structure ................ 6 3. Specifications ................8 3. 1 Card Motor .................. 8 3. 2 Card Motor Return to Origin ............ 15 3.

  • Page 4: Safety Instructions

    LAT3 Series/Card Motor 1. Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
  • Page 5 LAT3 Series/Card Motor 1.Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.

  • Page 6: Product Outlines

    If the I/O cable is required, please order separately. (Refer to section “3.5 I/O cable” (P.19) Note 3) The DIN rail is not included. If the DIN rail is required, please order separately. (Refer to the LAT3 series catalogue for details.) Note 4) The I/O cable attached is changed from LATH5 to LATH2.

  • Page 7: System Structure

    2. 2 System structure 　 Note 1) “Options” such as controller and cables can be added to the How to Order for the main products (Card Motor and Card Motor controller). Refer to How to Order for details. Note 2) “Separately sold products” cannot be added to the How to Order for the main products (Card Motor and Card Motor controller).
  • Page 8 Caution Refer to the Card Motor Controller operation manual for detailed wiring. Refer to section “5. Common Precautions for wiring and cables” (P.28) for instructions regarding wiring and handling of cables. Refer to the Card Motor Controller operation manual for parts which are not included. - 7 -...

  • Page 9: Specifications

    3. Specifications 3. 1 Card Motor (1) Card Motor specifications Model LAT3-10 LAT3F-10 LAT3-20 LAT3F-20 LAT3-30 LAT3F-30 LAT3M-50 LAT3F-50 Stroke [mm] Type Moving magnet type linear motor Maximum instantaneous thrust [N] Motor Note 1) Note 2) Note 3) Continuous thrust Note 1) Note 2) Note 3) Type Linear guide with circulating balls...
  • Page 10 (2) Card motor characteristics Pushing direction Pushing direction Connector side Opposite side of the connector Connector side Opposite side of the connector LAT3□-10 LAT3□-10 Thrust Setting Value：5 Thrust Setting Value：3 Thrust Setting Value：1 Pushing Position [mm] LAT3□-20 LAT3□-20 Thrust Setting Value：4.8 Thrust Setting Value：2.8 Thrust Setting Value：1 Pushing Position [mm]...
  • Page 11 Pushing direction Pushing direction Connector side Opposite side of the connector Connector side LAT3□-50 LAT3□-50 Opposite side of the connector Thrust Setting Value：2 Thrust Setting Value：1.5 Thrust Setting Value：1 Pushing Position [mm] Operating conditions: Operating conditions: Mounting orientation: Mounting orientation: Horizontal table mounting.
  • Page 12 LAT3□-10 LAT3□-20 Ambient Ambient 周囲温度 temperature temperature 5℃ 20℃ 40℃ Duty [%] LAT3□-50 LAT3□-30 Ambient Ambient 周囲温度 temperature temperature 5℃ 20℃ 40℃ Duty [%] Fig. 4-3 Allowable thrust force setting values. LAT3-□ LAT3M-□ LAT3F-□ Load weight：1000g Load weight：1000g Load weight：1000g 700g 700g 700g...
  • Page 13 Table displacement due to Table displacement due to Table displacement due to pitching moment yawing moment rolling moment Displacement when a load is applied Displacement when a load is applied Displacement when a load is applied to the point indicated by the arrow. to the point indicated by the arrow.
  • Page 14 (3) Card motor dimensions LAT3□-10 、LAT3□-20、 LAT3□-30 Note 1) Refer to “Mounting screw specifications and tightening torques” in section “4.3 Mounting” (P.24). Note 2) The length of the part of the dowel pin inserted into the positioning hole should be shorter than the specified depth. Note 3) This drawing shows the Origin Position.
  • Page 15 LAT3□-50 Note 1) Refer to “Mounting screw specifications and tightening torques” in section “4.3 Mounting” (P.24). Note 2) The length of the part of the dowel pin inserted into the positioning hole should be shorter than the specified depth. Note 3) This drawing shows the Origin Position. Note 4) The G and H Origin position dimensions are reference values (guidelines).

  • Page 16: Card Motor Return To Origin

    3. 2 Card Motor Return to Origin The Card Motor uses an incremental type of sensor (linear encoder) to detect the position of the table. Therefore, it is necessary to return the table to the Origin Position after the power has been switched on. There are three [Return to Origin Position] methods as described below.

  • Page 17: Card Motor Controller

    Without cable Note 1) The DIN rail is not included. If the DIN rail is required, please order separately. (Refer to the LAT3 series catalogue for details.) Note2) When the standard I/O cable option is selected, the I/O cable (LATH5-□...
  • Page 18 (2) Controller Screw mounting type (LATCA-□□) DIN rail mounting type (LATCA-□□D) - 17 -...

  • Page 19: Actuator Cable

    3. 4 Actuator cable (1) How to Order L A T H １ - １ Cable length (L) (2) Dimensions Card Motor side Controller side Raised area Note) The actuator cable is direction dependent. Connect the Card Motor side of the cable to the Card motor, and vice versa. A small area of the connector is raised on the controller side.

  • Page 20: I/O Cable

    3. 5 I/O cable (1) How to Order (2) Parallel I/O plug terminal table L A T H ２ － １ LATH2- LATH5- Terminal Insulator Insulator number Dot colour colour colour Light ■ brown Grey Black Grey ■ Yellow Grey Black I/O cable type Cable length(L)

  • Page 21: Card Motor / Specific Product Precautions

    4. Card Motor / Specific Product Precautions ® 4. 1 Design / Selection Warning (1) Make sure that you have read and understood this operation manual for the Card Motor and the one for the LATCA series controller. Handling, usage or operation other than that specified in the operation manuals may lead to breakage, malfunction and operation failure of the product.
  • Page 22 Caution (1) Operate within the limits of the maximum usable stroke. The stopper will be damaged if the Card Motor is used with a stroke outside the maximum stroke limits. Refer to the Card Motor specifications for maximum strokes. (2) Do not apply a load outside the specifications. The Card Motor should be fitted for the application based on the maximum workload and allowable moments.

  • Page 23: Handling Precautions

    4. 2 Handling Precautions Warning (1) Do not touch the product when it is energized or for some time after it has been de-energized. The surface temperature of the Card Motor can increase up to approximately 70 C depending on the operating conditions.
  • Page 24 (9) Be careful not to touch, get caught or hit by the work piece while the actuator is moving. It may cause an injury. (10) The table and guide rail are made of special stainless steel, but can rust in an environment where droplets of water adhere to it.

  • Page 25: Mounting

    4. 3 Mounting Warning (1) Read and understand the Operation Manual before installing and operating the product. Also keep this manual available whenever necessary. (2) Strong magnet. The Card Motor contains a strong rare-earth magnet. If magnetized work pieces, tools and metallic parts are brought in the vicinity of the Card Motor, they will be attracted, which could cause injury to operators and damage the equipment.
  • Page 26 (4) When mounting the Card Motor, use stainless steel screws with appropriate length and tighten with recommended tightening torque. If the maximum screw-in depth is exceeded, it may damage the internal components. Using a tightening torque higher than the specified torque may cause malfunction, and using a lower tightening torque may displace the work piece or cause it to drop off.

  • Page 27: Operating Environment

    4. 4 Operating environment Caution (1) Avoid use in the following environments. 1． Locations where large amounts of dust or cutting chips are airborne. 2． Locations where the ambient temperature is outside the operating temperature range (refer to the specifications for details). 3．...

  • Page 28: Maintenance

    4. 5 Maintenance Warning (1) Before performing installation, wiring and maintenance, check for accumulated voltage using a tester at least 5 minutes after the power supply has been switched off. Accumulated voltage can result in electric shock, fire, and injury. Caution (1) Perform regular maintenance and inspections.

  • Page 29: Common Precautions For Wiring And Cables

    5. Common Precautions for wiring and cables Warning (1) The power supply to the product must always be switched off before adjusting, mounting, inspection or wiring is done. An electric shock, malfunction, and breakage can result. (2) Never disassemble the cable. Never use cables other than specified. (3) Never connect or disconnect a connector and cable when it is energized.

  • Page 30: Troubleshooting

    6. Troubleshooting Refer to the table below for troubleshooting. When none of the causes in the troubleshooting can be confirmed, it is presumed that the product is faulty and normal operation can only be recovered by the replacement of a part. There is a possibility that this product has been damaged due to the operating conditions (problems relating to the application), so please contact SMC to discuss appropriate measures.

  • Page 31: Position / Speed / Thrust Troubles

    6. 2 Position / Speed / Thrust troubles Error Investigation method and the Error Countermeasures Possible location of possible causes Problem causes In case of return to origin position on the Displaced pushing or retracting end position, does from the Check actuator's operation (if foreign matter the actuator travel to the origin position? origin...
  • Page 32 Revision history 1st printing: Revised in May 2012 A: Revised in November 2012 B: Revised in April 2013 Addition to note Correction of words Correction of timing chart C: Revised in November 2015 D: Revised in February 2024 Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.

This manual is also suitable for:
