FLYFANS SUKHOI SU-27 FLANKER Quick Start Manual

SUKHOI SU-27 FLANKER
64mm EDF RC JET
SPECIFICATIONS
Wingspan: 930mm
Length: 1380mm
Dry weight: 800g
Flying weight: 2300g (Full loading)
Wing loading: 72g/dm²
KIT
40g Retracting
KIT
Shock Absorber
9g Metal Servo x 5 (In-
Landing Gear
stalled)
9g Servo x 2 (Installed)
RECOMMENDED BATTERY
3300-4700mAh 6S High Discharge Lipo
KIT TYPE
KIT + Servos
ELECTRONIC
Power System: 2840/2300KV 64EDF x 2
ESC: 40A ESC x 2 + 5V5A BEC
Servos: 9g servos x 7
Battery: 3300-4700mah 6s Lipo
Radio: 6 Channel TX and RX
KIT
9g Metal Servo x 5 (Installed)
9g Servo x 2 (Installed)
40A ESC x 2 (Installed)
6S: 2840-2300KV 64mm EDF x 2 (Installed)
PNP
1
