Solid State Logic PURE DRIVE OCTO User Manual page 29

Mic In to Insert Send
Measurement
Input Impedance
Output Impedance
Gain Matching
Noise Floor (Unweighted)
EIN
Frequency Response
THD+N Ratio
Crosstalk
Maximum Input Level
Line In to Insert Send
Measurement
Input Impedance
Gain Matching
Noise Floor (Unweighted)
THD+N Ratio
Maximum Input Level
Hi-Z to Insert Send
Measurement
Input Impedance
Insert Return to ADC
Measurement
Input Impedance
ADC Line-Up
Frequency Response
THD+N Ratio
Dynamic Range
PURE DRIVE OCTO User Guide
Value
12 kΩ
1.2 kΩ
600Ω
400Ω
70Ω
±0.1 dB
< -95 dBu
-125.0 dBu nominal
±0.2 dB
0.0025%
< -105 dB
> 21.5 dBu
Value
22 kΩ
±0.1 dB
-87dBu
0.004% typical
26.5 dBu
Value
1 MΩ (unbalanced)
Value
10 kΩ
24.0 dBu
±0.1 dB
0.0005% typical
117 dB
Conditions
Green setting
Dim White setting
Orange setting
Red setting
-
Any gain setting
gain
17 dB gain, unweighted, 20 Hz - 20kHz,
150R termination
65 dB gain, A-weighted, 20 Hz - 20kHz,
150R termination
20 to 20 kHz, any gain
17 dB gain, 20 dBu out, 1 kHz
Aggressor 15 dBu 1 kHz in, 5 dB gain,
20 dBu out
Adjacent channels 150R terminator, 35
dB gain
Minimum gain
Conditions
-
Any gain setting
gain
0 dB gain, unweighted, 20 Hz - 20kHz,
150R termination
0 dB gain, 0 dBu out, 1 kHz
Minimum gain
Conditions
-
Conditions
-
-
20 Hz to 20 kHz
20 dBu, 1 kHz
gain
20 Hz to 20 kHz, A-weighted
Appendices
