Sub-Zero 700TC Specifications page 15

Planning Information
Integrated Model 700TC(I)
F R A M E L E S S C A B I N E T R Y
IMPORTANT NOTE: The depth of each Integrated
unit is 24" (610) from the front of the unit to its
back. Your design may necessitate moving the unit
back, or cabinets forward to achieve a flush fit.
1
(3) MIN.
8
REVEAL
24
(610)
TO BACK
OF UNIT
Door closed – full scale (top view)
Dimensions in parentheses are in
millimeters unless otherwise specified.
LINE OF INTERFERENCE*
AT MAXIMUM DOOR OPENING
MOUNTING BRACKET SCREW
3
PANEL
(19)
4
7
25
APPLIANCE DOOR WIDTH
8 (657)
SUB-ZERO DOOR
LINE OF INTERFERENCE*
SIDE MOLDING AND
INSTALLATION HARDWARE
PROVIDED BY SUB-ZERO
*If the panel is thicker than
utilize the built-in 90˚ door stop to prevent damage to the panel
and face frame.
SUB-ZERO DOOR
3
/ " DOOR PANEL
4 (19)
COUNTERTOP SIDE PANEL
24
(610)
TO
WALL
105˚ maximum door opening –
Adjacent side panel and countertop application
3
/ " (19), it is recommended that you
4
LINE OF INTERFERENCE*
1
/ scale (top view)
4
15
