- Page 1 SATURN CINEROID FLEXIBLE LIGHT SYSTEM FCB120V Safety Instructions / User's Manual SECULINE Co ., Ltd. Room 1105, Ace techno tower 8th, Seoul, Republic of Korea 08380 Tel: +82-70-4347-4901 Fax: +82-70-4347-4999 E-mail: support@secu-line.com www.cineroid.com...
-
Page 2: Safety Precautions
Thank you for choosing the Cineroid. Cineroid Saturn120 LED Light is high quality RGBW soft light with portable size. Light weight and thin panel makes easy to use and getting around any type, environment. Please thoroughly read the user manual for best operation and understanding of all of the functions of the Cineroid LED light. -
Page 3: Package Contents
Package Contents Please ensure all parts are present after opening the box. A. LED Panel B. Controller C. X-Bracket D. Adapter F. Diffuser G. 3M Extension Cable... -
Page 4: Specifications
Specifications Light Sources RGBWW Flexible LED Panel Consumption 120 W Photometric (lux) 1m:2,806 2m:829 3m:381 95 or above 2700ºK ~ 6500ºK Light Angle 140º Dimming 0~100% Power Input 12~24 V 512 Channels Dimensions Panel 46x24 cm (18.1x9.5 inch) Dimensions Controller 18x9x6 cm (7x3.5x2.4 inch) Weight Panel 0.3 kg (0.7 lb) - Page 5 Before Using FCB120...
- Page 6 Install the Bracket on LED Panel Unfold the bracket and secure it to the 4 corners on the back of the LED panel. Connect LED Panel to the Controller Connect the LED panel and Controller connectors. And then screw the nut to tight. It can be used extension cable between connectors.(optional)
- Page 7 Set the Softbox Install the Soft Box Body first. Open Soft Box Body and attach it to the Velcro on the back of the LED panel. After installing the Soft Box Body, cover the Soft Diffuser on Soft Box Body.
-
Page 8: Usb Output
Power by DC Power by V mount battery Input Power to FCB120 Power is supplied by the supplied DC Adapter or V mount Battery (V mount battery is not provided.). USB Output Controller can be used in a 5V, 2A USB output. Connect the power to the controller and use it with the switch turned on. -
Page 9: Basic Operation
Operating Basic Operation 1. Access the LED mode menu by pressing the mode button on Controller. 2. Turn the Setting Button to set the value and press the Setting Button to complete the setting. 3. Press Exit Button to return to the previous screen. 4. - Page 10 CCT Mode (White Color) ① Brightness Turning the brightness wheel button to the right to increase brightness. Turn to the left to decrease brightness. You can adjust the Brightness by 0~100% dimming. ② Color Temperature Turn the Setting Button to the right increases Color temperature and left decreases Color temperature.
-
Page 11: Rgb Mode
RGB Mode ① Brightness Turn the Brightness Wheel to adjust the brightness. Brightness can be set from 0 to 100%. The current color is displayed next to the brightness indicator. ② Color Temperature Select Internal Preset Color. The information of the 12 internal preset color values is displayed in the lower RGB boxes respectively. - Page 12 ③ Color manual setting You can specify RGB color values manually. Red, Green, Blue Specify a value for each color. ④ White Color intensify White color can be added to or subtracted from the RGB color value. White Color Intensify Sets the ratio values of RGB and White Color in the graph. ⑤...
- Page 13 Hue/Sat Mode ① Brightness Turn the Brightness Wheel to adjust the brightness. Brightness can be set from 0 to 100%. The current color is displayed next to the brightness indicator. ② Internal Preset Color Select Internal Preset Color. Information on the 12 internal Preset Color values is displayed in the lower HUE and SAT boxes respectively.
-
Page 14: Effect Mode
Effect Mode ① Select the Effcet DMX-1 Unit [%] Green cursor appears under the Thunder Bol t effect name you are selecting. You can select the arrow to move Night Clu b to the next or previous page. Camp Fire ②... - Page 15 System Frimware Update ① Download new firmware data to USB memory through Cineroid homepage. ② Connect USB memory that contains firmware data to controller. ③ If you click F/W Update in System, the update will start automatically. When the update is finished, controller restarts.
-
Page 16: Dmx Mode
Master / Slave You can control multiple CFL120 MASTER Unit [%] simultaneously by operating one CFL120. ① Connect the controller to be used as master SYNC MASTER and the controller to be used as slave by using RJ45 cable. SYNC SLAVE ②...
