UT986eb User Manual
4
5
6
(1) Ports used to connect jumpers
(3) Debug ports
(5) Dual-row pins as external interfaces
(7) 5 V DC/DC boost circuit for antenna feeding
UC-08-M37 EN R1.0
3
7
3
Figure 1-3 Bottom View of UT986eb
Product Overview
2
1
8
1
(2) Anti-static design and heat dissipation with
exposed copper
(4) VCC power supply and LDO circuit
(6) Backup battery
(8) Antenna feed circuit
3
