- Page 1 用户手册 INSTALLATION AND OPERATION USER MANUAL WWW.UNICORECOMM.COM High Precision Products Evaluation Kit (EVK) Copyright© 2009-2023, Unicore Communications, Inc. Data subject to change without notice.
- Page 2 HPL EVK5.0 CD-Kit User Manual Revision History Version Revision History Date R1.0 First release Mar., 2023 Add a note to RS232 to USB cable R1.1 Dec., 2023 Add Appendix...
- Page 3 Information, such as product specifications, descriptions, features and user guide in this manual, are subject to change by Unicore at any time without prior notice, which may not be completely consistent with such information of the specific product you purchase.
- Page 4 HPL EVK5.0 CD-Kit User Manual Foreword This document provides information about the HPL EVK5.0 CD-Kit from Unicore. Target Readers This document applies to technicians who possess the expertise on GNSS receivers.
- Page 5 Contents OVERVIEW ....................1 INTERFACE ..................... 2 CONNECTION ..................3 APPENDIX: DIMENSIONS ................4...
-
Page 6: Overview
HPL EVK5.0 CD-Kit User Manual 1 Overview The HPL EVK5.0 CD-Kit is mainly used to evaluate the function and performance of Nebulas modules and boards from Unicore for the convenience of users. Figure 1-1 shows the items in the package box. -
Page 7: Interface
COM2 Connect to COM2 of the board to be tested RJ45 Ethernet interface The four SMA interfaces are: FWR, EVENT1, PPS1, SPEED 28-pin connector to connect Unicore 28-pin board interface products 42-pin connector to connect Unicore 42-pin board interface products Refer to the related user manuals of the boards/modules to be tested to confirm whether this function is supported. -
Page 8: Connection
Carefully check the EVK to make sure that there is no apparent loose or damaged components. If you have any questions, please contact Unicore or the local distributors. Do the following steps to evaluate. Ensure adequate antistatic measures, such as wearing a grounded antistatic wrist strap, using a grounded workbench, etc. -
Page 9: Appendix: Dimensions
Install the UM980eb on the EVK by aligning the dual-row pins to the pinholes. Connect one end of the serial port cable to the COM1 on the EVK, and connect the other end of the cable to the computer if your computer has RS232 ports; otherwise, you need a RS232 to USB cable to connect to the computer. - Page 10 HPL EVK5.0 CD-Kit User Manual UC-00-E60 EN R1.1 Appendix: Dimensions...
- Page 11 和芯星通科技（北京）有限公司 Unicore Communications, Inc. 北京市海淀区丰贤东路 7 号北斗星通大厦三层 F3, No.7, Fengxian East Road, Haidian, Beijing, P.R.China, 100094 www.unicorecomm.com Phone: 86-10-69939800 Fax: 86-10-69939888 info@unicorecomm.com www.unicorecomm.com...
