No. Pin Name
19 RXD2
20 GND
21 NC
22 GND
23 PPS
24 NC
25 NC
26 NC
27 NC
28 NC

The availability of the ports depends on the firmware version of the module UT986.
UC-08-M37 EN R1.0
I/O Description
I COM2 input, LVTTL
- Ground
- No connection inside
- Ground
O PPS output
- No connection inside
- No connection inside
- No connection inside
- No connection inside
- No connection inside
