Mobile Lubrication Library
Komatsu HD785 Installation
Instructions
Instructions for installing a Graco Compact Dyna-Star automatic
lubrication system on the Komatsu HD785.
Part No. 132662
Maximum System Working Pressure: 3500 psi (24.13 MPa, 241.3 bar)
Important Safety Information
Before beginning any installation, read all warnings and instructions in all related Graco component
manuals (page 1) and all related Original Equipment Manufacturer (OEM) manuals, including the vehi-
cle's Operation and Maintenance Manual (OMM). Save all instructions.
FLUID INJECTION HAZARD
Fluid leaks from incorrectly installed or ruptured compo-
nents, and/or failure to verify the components are properly
installed and tested, can result in serious injury such as
fluid spraying in the eyes or on skin and fluid injection, or
equipment damage.
Related Graco Component Manuals*
Manual No.
3A6941
3A7031
335023
*Refer to these instruction manuals for additional information related to the
installation and operation of system components.
The installation instructions contained in this manual are only a recommendation for an automatic lubrication system. They are
not intended to replace any instructions provided in the OEM's manuals. Always refer to the OEM's manuals for details on lubri-
cation intervals.
Manual Title
®
Compact Dyna-Star
Electric Pump
GLC X Lubrication Controller
™
™
GL-1 X
, GL-1 XL
Injectors
For professional use only.
NOTICE
Welding can damage electronics and the equipment's
structure. To help prevent equipment damage caused
by welding:
•
Disconnect the vehicle battery before welding.
•
Follow all welding guidelines in the OEM manuals,
including the OEM service manuals.
•
Only weld in locations specifically approved by the
OEM. Consult OEM dealership for information and
recommendations.
•
Perform all welding in accordance with American
Welding Standard (AWS) standards.
