DB Research Hypnotic HW12D4 Installation Instructions & Owner's Manual

Hide thumbs
1
2

Advertisement

Quick Links

Download this manual
Recommended Enclosures
SEALED
PORTED
HW12D4
Sealed Enclosure
Box Volume 1.15cu ft.
Ported Enclosure
Box Volume 1.42cu ft.
Box Tuning 39Hz
Port Diameter 4in
Port Length 18in
HW12D4
Installation Instructions / Owner's Manual
12.40in./315mm
5.51in./140mm
10.82in./275mm
Please Note: Our suggested box volumes are given as internal air requirements.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Hypnotic HW12D4 and is the answer not in the manual?

Questions and answers

Related Manuals for DB Research Hypnotic HW12D4

Summary of Contents for DB Research Hypnotic HW12D4

  • Page 1 Recommended Enclosures SEALED PORTED HW12D4 Sealed Enclosure Box Volume 1.15cu ft. Ported Enclosure Box Volume 1.42cu ft. Box Tuning 39Hz Port Diameter 4in Port Length 18in HW12D4 Installation Instructions / Owner’s Manual 12.40in./315mm 5.51in./140mm 10.82in./275mm Please Note: Our suggested box volumes are given as internal air requirements.
  • Page 2 INTRODUCTION PRODUCT SPECIFICATIONS Congratulations on your purchase of a HYPNOTIC state-of-the-art subwoofer com- HW12D4 ponent. Your selection of a HYPNOTIC car audio product indicates a true apprecia- (FS) 32.810 Hz tion of fine musical reproduction. Whether adding to an existing system or including (Qts) 0.833 a HYPNOTIC subwoofer in a new system, you are certain to notice immediate...
