EPS8
8-Inch Low Profile Amplified Subwoofer
USER MANUAL
Installation Instructions | Owners Manual
DB Research L.L.P. - 302 Hanmore Industrial Parkway - Harlingen, TX 78550
Ph: (877) 787-0101 - Fax: (956) 421-4513 - www.dbdrive.net
Due to continuous improvement of the product, specifications are subject to change without notice.
Advertisement
Related Manuals for DB Research EUPHORIA EPS8
Summary of Contents for DB Research EUPHORIA EPS8
-
Page 1: User Manual
USER MANUAL Installation Instructions | Owners Manual DB Research L.L.P. - 302 Hanmore Industrial Parkway - Harlingen, TX 78550 Ph: (877) 787-0101 - Fax: (956) 421-4513 - www.dbdrive.net Due to continuous improvement of the product, specifications are subject to change without notice. - Page 2 Panel controls and features A.POWER STATUS LED F.INPUT GAIN CONTROL This bi-color LED glows green when power is After you have installed your system, turn this on and no problems are present. If one of the control to minimum. protection circuits comes on, it will change to Turn the head unit on (and the subwoofer will red.
- Page 3 Low Level Input Wiring Low-level (RCA) input wiring is preferred for best audio performance. Most trunk or hatchback installations will require a 15-20 feet RCA cable, while pickup trucks and under-seat installations will require a 6-12 feet RCA cable. Always use a high quality cable.
-
Page 4: Power Connections
Power Connections Connect the ground terminal to the closest point on the chassis of the vehicle. Keep this ground wire to less than 12" (30.5 cm) in length. Use 8 gauge (or heavier) wire. Connect the remote terminal to the remote output of head unit using 16 gauge ( or heavier ) wire. -
Page 5: Remote Level Control Connection
Remote Level Control Connection Fig.5 Install the remote control securely under the dash or in a similar location where using it will Remote not distract the driver. Level Control MODEL: EPS8 RMS power 225W <0.4% Signal-to-noise ratio >90dB Frequency response 20Hz - 150Hz Input sensitivity, high level 0.5V... - Page 6 fuses...
- Page 7 LIMITED WARRANTY DB Drive warrants any Euphoria products purchased in the U.S.A. from an authorized DB Drive Euphoria dealer. All products are warranted to be free from defects in material and workmanship under normal use and service for a period of one (1) year when purchased over the counter.
- Page 8 GARANTÍA LIMITADA DB Drive™ garantiza cualquier Euphoria producto comprado en USA de un vendedor autorizado por DB Drive™ Euphoria. Todos los productos están garantizados de nó tener defectos en material y manufactura bajo un uso normal y servicio por un período de un año a partir de la fecha de a la compra.
