sealed
BSW10S
Sealed Enclosure
Box Volume 0.90cu ft.
Ported Enclosure
Box Volume 1.23cu ft.
Box Tuning 39hz
Port Diameter 3in.
Port Length 8in.
BSW10D
Sealed Enclosure
Box Volume .90cu ft.
Ported Enclosure
Box Volume 1.23cu ft.
Box Tuning 39hz
Port Diameter 3in.
Port Length 8in.
BSW12S
Sealed Enclosure
Box Volume 1.35cu ft.
Ported Enclosure
Box Volume 2.19cu ft.
Box Tuning 39hz
Port Diameter 4in.
Port Length 7in.
BSW12D
Sealed Enclosure
Box Volume 1.35cu ft.
Ported Enclosure
Box Volume 2.19cu ft.
Box Tuning 39hz
Port Diameter 4in.
Port Length 7in.
ENCLOSURES
ported
232 mm / 9.13 in
262 mm / 10.31 in
232 mm / 9.13 in
262 mm / 10.31 in
278 mm / 10.94 in
316 mm / 12.20 in
278 mm / 10.94 in
316 mm / 12.44 in
Installation Instructions / Owner's Manual
Models:
BSW10S / BSW10D / BSW12S /
BSW12D
Advertisement
Table of Contents
Related Manuals for DB Research BASS INFERNO BSW10S
Summary of Contents for DB Research BASS INFERNO BSW10S
- Page 1 ENCLOSURES sealed ported BSW10S Sealed Enclosure Box Volume 0.90cu ft. Ported Enclosure Box Volume 1.23cu ft. Box Tuning 39hz Port Diameter 3in. 232 mm / 9.13 in 262 mm / 10.31 in Port Length 8in. BSW10D Installation Instructions / Owner’s Manual Sealed Enclosure Box Volume .90cu ft.
- Page 2 INTRODUCTION PRODUCT SPECIFICATIONS Congratulations on your purchase of a BASS INFERNO state-of-the-art subwoofer BSW10S BSW10D BSW12S BSW12D component. Your selection of a BASS INFERNO car audio product indicates a true appreciation of fine musical reproduction. Whether adding to an existing system (FS) 40.40Hz 40.80Hz...
