Forensic DriveDock v4™
input/output status, hard drive access, host attachment, and write-blocking status.
Rugged design, built to last – Grab it and go! Forensic DriveDockv4 is tough as nails and made
•
to last. The small and rugged case contains a complete, high speed Oxford Semiconductor
OXFW911+ bridge and is constructed from briefcase-tough aluminum for durability. World-
compatible AC adapter accepts 100-240VAC so you can trot the globe.
Connect even more types of drives with Combo Adapters. Use Forensic DriveDockv4 in
•
conjunction with our lineup of Combo Adapters and retrieve data on other drive types such as
1.8" Toshiba (found in iPods), 1.8" Hitachi drives, MicroDrives (found in iPod mini), PCMCIA
drives, 2.5" notebook drives and SATA drives. See
Forensic Device User Advisory
We recommend that you perform a final check on this product.
Prior to first use, please verify that the write-blocking function of this product is working properly. This is
easily done: attach a known good formatted drive, and verify that the drive mounts properly on your
computer. Use a drive that has data on it that you are willing to overwrite. Transfer files to the drive. The
files will appear to transfer to the drive. Thereafter, dismount the drive and remount the drive. The files
that you wrote to the drive should not appear after the drive is remounted. If they do appear, there is a
problem with your Forensic Device, and you should contact tech support for further instructions.
F o r e n s i c D r i v e D o c k v 4 U s e r M a n u a l
USER'S MANUAL
Revised July 1, 2008
Features
•
•
•
•
NOTE: Forensic DriveDockv4 will only be
able to write-block over FireWire 400.
The USB port has read/write capabilities.
WiebeTech's new Forensic DriveDockv4 will
write-block over FireWire 400 and read/write
over USB.
Now with HPA/DCO detection. Forensic
DriveDock v4 will recognize and report the
presence of an HPA or DCO on a hard drive.
The accessories with this versatile bundle will
allow you to access 3.5" IDE and SATA drives,
as well as 2.5" IDE and SATA drives.
Multiple status indicators will show power
www.wiebetech.com
for more information.
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FODDv4-VBND and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WiebeTech FODDv4-VBND

Summary of Contents for WiebeTech FODDv4-VBND

  • Page 1 F o r e n s i c D r i v e D o c k v 4 U s e r M a n u a l USER’S MANUAL Revised July 1, 2008 Features WiebeTech’s new Forensic DriveDockv4 will • write-block over FireWire 400 and read/write over USB.

  • Page 2: Installation Instructions

    WiebeTech LLC Installation Instructions Check the accessories with your Forensic DriveDockv4 Versatile Bundle (FODDv4-VBND). Please contact WiebeTech if any parts are missing or damaged. The box should contain the following items: Accessories Forensic DriveDock with shrouded IDE connector SATA adapter 2.5″...
  • Page 3 WiebeTech LLC Note: Forensic DriveDock v4’s HPA/DCO detection can be seen with a fast blink of the forensic write-blocked LED (4 blinks per second). If the LED does not blink it is reporting that the drive is write-blocked, but there is not an HPA or DCO on the drive.

  • Page 4: Usage With Macintosh Computers

    The Forensic DriveDockv4 is Plug-and-Play compatible under Mac OS 9.2 and OS X. No drivers are needed. FireWire 400 ports are FireWire 800 host compatible (a FireWire 800-400 cable or adapter such as WiebeTech’s Cable-11 is necessary for use with FireWire 800 ports). The USB2 port is USB 1.1 compatible.

  • Page 5: Usage With Windows Computers

    The Forensic DriveDockv4 is Plug-and-Play compatible with Windows XP. No drivers are needed. FireWire 400 ports are FireWire 800 host compatible (a FireWire 800-400 cable or adapter such as WiebeTech’s Cable-11 is necessary for use with FireWire 800 ports). The USB2 port is USB 1.1 compatible.
  • Page 6 Use a power supply with an RFI reducing ferrite approximately 5 inches from the DC plug. If you have any questions or problems, please contact interested in purchasing more WiebeTech products, check our website or contact sales@wiebetech.com. We appreciate being able to serve you!
