WiebeTech SDKv4 User Manual

• Power status LED verifies that unit is switched on (or off)
• Host-detection LEDs indicate connection to either FireWire or USB host
• Access LED shows hard drive activity
• Aluminum case is briefcase tough, with excellent heat dissipation
• Small size for easy portability. Carry it anywhere!

Installation Instructions

1.
Check the accessories packaged with your SATADock. Please contact WiebeTech if any items are missing
or damaged. The box should contain:
SATADock
AC adapter & power cord
FireWire 800 cable
USB cable
Metal bottom plate
Hard drive screws
Rubber bumpers
Manual and Warranty information
2.
Attach bottom plate to your 3.5" hard drive. This step is optional but
recommended. The purpose of the bottom plate is to provide protection to your
drive electronics and aid heat dissipation. Attach the bottom plate to your drive using
the four screws supplied. Attach a rubber bumper to each corner. Extra bottom
plates are available from WiebeTech.
S A T A D o c k v 4 U s e r M a n u a l
SATADock™ v4
USER'S MANUAL
Revised September 25, 2006

Features

• Connects any 3.5" or 2.5" SATA drive through FireWire
800 (400 compatible) or USB2.
• Fully plug & playable, working with almost any Mac or
PC without requiring drivers.
• Power switch allows drives to be powered off when not
in use, and helps prevent damage to FireWire ports.
• Two options for power input: Use the included AC
adapter, or use a 4-wire connector from a computer's
power supply
• LEDs show when unit is receiving power as well as
power output status
1
1
1
1
1
4
4
(on CD)
- 1 -
