Schematic Description - Termix Vx-Iv Rad; Schematic Description - Termix Vx-Iv Ufh - Danfoss 3 Series Operating Manual

Termix VX-IV - 3 Series DS Fully insulated

Schematic description - Termix VX-IV RAD

Mounting rail
Heat Network
Supply
01 14
01
Heat Network
Return
01 41
L
Your HIU may look different from the HIU shown
1 Isolation valve
4 Safety valve
7 Thermostatic valve, HTG
9 Strainer
10 Circulator pump

Schematic description - Termix VX-IV UFH

Mounting rail Heat Network
Supply
01 14
01
Heat Network
Return
01 41
L
Your HIU may look different from the HIU shown
1 Isolation valve
4 Safety valve
7 Thermostatic valve, HTG
9 Strainer
10 Circulator pump
14 Sensor pocket, energy meter
LGB53080
09
31
14 Sensor pocket, energy meter
20 Filling/drain valve
26 Pressure gauge
31 Differential pressure controller
38 Expansion tank
09
31
20 Filling/drain valve
26 Pressure gauge
31 Differential pressure controller
38 Expansion tank
41 Spacer piece, energy meter
48
A
07 69
M
48
A
07 69
M
M
4 bar
04 48
26 10 38
20
41 Spacer peice, energy meter
48 Air vent, manual
69 On/Off valve
A Heat exchanger, HTG
M Electrical wiring box
M
4 bar
04 48
26 10 38
20
48 Air vent, manual
60 Thermostat (only for UFH)
69 On/Off valve
A Heat exchanger, HTG
M Electrical wiring box
© Danfoss | 2022.11| 13
Heating
Supply
Heating
Return
09
Heating
60
Supply
T
Heating
Return
09
