- Page 1 Web Management Guide ( Hilbert PoE Smart Lite Switches )
- Page 2 FCC STATEMENT Manual Description This user guide is provided for using this type of switch. The manual includes the switch performance and function. Please read this manual before managing the device: Intended Audience This guide is intended for network administrators familiar with IT concepts and network terminology. SAFETY NOTICES Do not use this product near water, for example, in a wet basement or near a swimming pool.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Chapter 1: Introduction ..............................4 1.1 Features ..................................5 Technical Specifications ..............................5 Chapter 2: Mounting Device ............................5 2.1 Installation Precautions .............................. 5 2.2 AC POWER ................................... 5 Chapter3: Login The Device .............................. 6 3.1 configure the computer .............................. 6 3.1.1 Windows 7/Windows Vista .......................... - Page 4 6.1.2 MAC Constraint .............................. 28 6.2 Storm Control Setting ............................... 28 6.3 DHCP Snooping ................................. 29 Chapter7: Monitoring ..............................30 7.1 Port Statistics ................................30 Chapter8: Tools ................................30 8.1 Backup Configuration ............................... 30 8.2 Fimware Upgrade ..............................31 8.3 Reboot ..................................31 8.4 Save Configuration ..............................
-
Page 5: Chapter 1: Introduction
2. Execute the application “LevelOne IP Locator.exe”. 3. The LevelOne IP Locator Utility will search all Hilbert series switches based on the connect network interface card (NIC), instantly know the forgotten IP address and other info. 4. Simply click with the mouse on the device's IP address in the device list for configuration. On the displayed login... -
Page 6: Features
1.2 Features Support link aggregation. Ø Support port VLAN and IEEE 802.1Q VLAN. Ø Support rate limit, port statistics. Ø Support port mirroring. Ø Support QoS, providing strict priority. Ø Support Loop Prevention. Ø Support MAC Address binding. Ø Support storm control. Ø... -
Page 7: Chapter3: Login The Device
Chapter3: Login The Device You can use the web browser-based configuration to manage Web-Smart Switch. The Web-Smart Switch to be configured through a web browser, at least a reasonable allocation of computer through an Ethernet connection to Web-Smart Switch. Figure 3-1 Default IP address of the switch:192.168.1.1. - Page 8 2、Click ”Network and Internet ” Figure 3-1-9 3、Click ”Change adapter settings” Figure 3-1-10 4. click right-hand button on the adapter icon and click “Properties” Figure 3-1-11...
- Page 9 5.Double clik “Internet protocol Vertion 4(TCP/IPv4)” Figure 3-1-12 5、 Use the following IP address: input IP 192.168.1. *** (1 <*** <255, *** is not 11, because the default IP of the switch is 192.168.1.1), Subnet mask: 255.255.255.0. The default gateway and DNS server are optional, and then click “OK” to close the Internet TCP / IP properties window.
-
Page 10: Check The Connection
6、CLICK “OK” and Close the Local Area Connection Properties window Figure 3-1-14 3.2 Check the connection After setting the TCP / IP protocol, you can use the Ping command to verify whether the computer can communicate with Web-Smart Switch. To perform a ping command, open a command window, the IP address in the command prompt where the Ping Web-Smart Switch Windows XP，START-Control，type cmd in the search bar and press Enter Windows 7，Click Start, type cmd in the search bar and press Enter where the DOS prompt, enter the following command. -
Page 11: Login The Device
Then Connection between Web-Smart Switch and computer is successful If the computer failed to connect on of Web-Smart Switch, the command window will return the following content Figure 3-2-2 Then make sure that your computer's network settings are correct and the cable is intact. Caution: YOU need to use a twisted pair to connect the port of your computer's network card to the switch port before entering the above command... -
Page 12: Chapter4: System
Chapter4: System 4.1 The Home page After logging into the switch, the main page appears as the following. It contains three parts: Figure 4-1-1 zone"1"：The Port table lies at the top of the page. It provides a visual representation of the ports. The green icon indicates that the port is linked;... -
Page 13: Ip Address
The System Information shows the system information of the switch, such as Device Type, MAC address, IP Address, Hardware and Software version information. 4.3 IP Address Figure 4-3-1 On this page you can manually set the IP address, subnet mask, gateway and other information; can also use your network, among other DHCP SERVER switch automatically assigns an IP address. -
Page 14: Port Setting
You are kindly suggested to retype the new password in "Confirm new password" box instead of copying in order to avoid typing mistakes. Caution: Only letters, numbers and punctuations can be input into username and password. The other characters are considered illegal. -
Page 15: Chapter5: Configuration
Chapter5: Configuration 5.1 VLAN Figure 5-1-1 Introduction to VLAN The traditional Ethernet is a broadcast network, where all hosts are in the same broadcast domain and connected with each other through hubs or switches. Hubs and switches, which are the basic network connection devices, have limited forwarding functions. -
Page 16: Static Vlan (802.1Q Vlan) Configure
The Virtual Local Area Network (VLAN) technology is developed for switches to control broadcasts in LANs. A VLAN can span multiple physical spaces. This enables hosts in a VLAN to be located in different physical locations. By creating VLANs in a physical LAN, you can divide the LAN into multiple logical LANs, each of which has a broadcast domain of its own. -
Page 17: Port-Base Vlan Configure
5.1.2 Port-base VLAN Configure 2. Choose the menu Configuration →VLAN →802.1Q PVID to load the following page. Configure PVID on this page. Figure 5-1-3 1). Select the desired port which to set PVID. Here is port 2 e.g. 2). Specify the PVID number of this port. Here is VLAN 2 e.g. 3). - Page 18 3. Choose the menu Configuration →VLAN →802.1Q VLAN to load the following page. Configure 802.1Q VLAN member port on this page. Here configure port 2 as access=2, port 1,3 as trunk =2 e.g. 1). Specify the VLAN ID need to configure. Here is VLAN 2 e.g. 2).
-
Page 19: Qos
5.2 QoS QoS (Quality of Service) functions to provide different quality of service for various network applications and requirements and optimize the bandwidth resource distribution so as to provide a network service experience of a better quality. This switch classifies the ingress packets, maps the packets to different priority queues and then forwards the packets according to specified scheduling algorithms to implement QoS function. -
Page 20: Dscp Remapping
5.2.2 DSCP remapping The device provides various types of priority maps. By looking through a priority map, the device decides which priority value to assign to a packet for subsequent packet processing. You can configure the mapping relationship between dscp and priority. Choose the menu Configuration →QoS →DSCP Remapping to load the following page. -
Page 21: Port-Based Priority
5.2.4 Port-based Priority Port priority is a priority level of the port. After port priority is configured, the data stream will be mapped to the egress queues directly according to the priority level of the port. Choose the menu Configuration →QoS →Port-based Priority to load the following page. Figure 5-2-4 1. - Page 22 given to network traffic is inversely proportional to the signal bandwidth. Thus, narrowband signals are passed along first, and broadband signals are buffered. WRR-Mode: Weighted Round Robin (WRR) — In WRR mode the number of packets sent from the queue is proportional to the weight of the queue (the higher the weight the more frames are sent).
-
Page 23: Igmp Snooping
5.3 IGMP Snooping Internet Group Management Protocol Snooping (IGMP Snooping) is a multicast constraining mechanism that runs on Layer 2 devices to manage and control multicast groups. The switch, running IGMP Snooping, listens to the IGMP messages transmitted between the host and the router, and tracks the IGMP messages and the registered port. -
Page 24: Port-Based Mirroring
Select a aggregation group number, then add port in the left form to the right form, that make port join into aggregation group. Web-Smart Switch has max 8 groups, and one aggregation group can support max 8 member ports. 5.5 Port-based Mirroring Port mirroring allows you to duplicate the packets passing specified ports to the destination mirroring port. -
Page 25: Bandwidth Control
On the current device: Currently, each port can be configured on the device to forward data to other ports. 5.7 Bandwidth Control Rate limit functions to control the ingress/egress traffic rate on each port via configuring the available bandwidth of each port. - Page 26 Choose the menu Configuration→ Jumbo Frame to load the following page. Figure 5-8-1 you can set the length of jumbo frames that can pass through all the Ethernet ports. By default, the device allows jumbo frames with the length of 1522/1536/1552/9216/10000 bytes to pass through all Ethernet ports.
-
Page 27: Chapter6: Security
Chapter6: Security 6.1 MAC Address A switch maintains a MAC address table for frame forwarding. Each entry in this table contains the MAC address of a connected device, to which port this device is connected and to which VLAN the port belongs. 6.1.1 Static MAC A MAC address table consists of two types of entries: static and dynamic. - Page 28 The above configuration means that mac 0000.0000.0011 is bound to port 5 and can only communicate with vlan1. If you want the devices to be connected as planned, you can use this function. The mac can only be used on this port 5. 6.1.1.2 MAC Blocking If the MAC address blocking table entry is set in this switch, if the message with this MAC address whether in source MAC or destination MAC, it will be discarded as long as the switch receives it.
-
Page 29: Mac Constraint
6.1.2 MAC Constraint MAC address learning capability, If this function is enabled, the switch will not learn the MAC address on the port. Choose the menu Configuration→MAC Constraint to load the following page. Figure 6-1-5 6.2 Storm Control Setting Storm Control function allows the switch to filter Broadcast, Multicast and Unknown Unicast frame in the network. If the transmission rate of the three kind packets exceeds the set bandwidth, the packets will be automatically discarded to avoid network broadcast storm. -
Page 30: Dhcp Snooping
Destination Look Up Failure control is a method of shutting down a loop when a storm is formed because a MAC address cannot be located in the Switch’s forwarding database and it must send a packet to all ports or all ports on a VLAN. To configure Traffic Control, select the port, you want to configure. -
Page 31: Chapter7: Monitoring
Chapter7: Monitoring 7.1 Port Statistics The Traffic Monitor function, monitoring the traffic of each port, is implemented on the Traffic Summary and Traffic Statistics pages. Traffic Summary screen displays the traffic information of each port, which facilitates you to monitor the traffic and analyze the network abnormity. -
Page 32: Fimware Upgrade
Click the Backup button to save the current configuration as a file to your computer. You are suggested to take this measure before upgrading. Click the Restore button to restore the backup configuration file. Select “Configuration Restore”, click “Select File” button. -
Page 33: Save Configuration
8.4 Save Configuration When the switch is saved configuration, the settings will be immediately applied to the switching software in RAM, and will immediately take effect. Choose the menu Tools→ Save Configuration to load the following page. Figure 8-4-1 Click the save button, which can make parameters to be saved, your configuration will still work after restart. 8.5 Reset Factory Default On this page you can reset the switch to the default. -
Page 34: Chapter9: Poe
Chapter9: PoE 9.1 PoE Configuration Power over Ethernet (PoE) enables a network device to supply power to terminals over twisted pair cables. The device supports IEEE 802.3af and IEEE 802.3at. A PoE system includes the following elements: PoE power supply—The PoE power supply provides power for the entire PoE system. PSE—A power sourcing equipment (PSE) detects and classifies powered devices (PDs), supplies power to PDs, and monitors the PD power and connection status.
