The analyser consists of the sensor, a box with integrated electronics and a gas-tight
DN40-KF clamp flange. The sensor is protected against mechanical damage by a pro-
tective cage. The sensor leads are connected to the electronics by a vacuum-tight feed-
through. The electronics are contained in a box mounted directly behind the DN40-KF
flange. The electronic measuring equipment is supplied with 24 V DC. It provides an out-
put voltage signal of 0 ... 10 V DC proportional to the oxygen concentration.
The heater of the sensor element is controlled by an additional input. If this external input
is not used, a jumper (bridge) must be placed on the electronics.
8A.3.2

Technical data

Dimensions
Sensor
Flange
Weight
Supply voltage
Ambient temperature
Pressure
Measuring range
Sensitivity
Response time (0 ... 90 %)
Warm-up phase
Accuracy
Drift at 10 ppm
Sensor life span
1
In a clean argon atmosphere, without trace gases such as H
2 Without influence of reactive gases
8A.3.3

Installing the oxygen analyser

Pin connection
PIN Contact
1 Supply ground
2 Controller on/off 24 V
MB-20-G/MB-200G-W_MB-LABmaster_MB-200 MOD_TP700
Operating Manual - V5.0 - 04/2018 - STD
1
:
2
8A O2 and H2O analysers
190 mm x 80 mm x 58 mm (L x H x D)
Length 45 mm, Diameter 26 mm
NW 40 KF
0.7 kg
24 V DC ± 10%
+15 to +27 °C
800 to 1200 mbar (max. differential pres-
sure between sensor and electronics 200
mbar)
<1.0 ... 1000 ppm oxygen
10 mV / ppm
Approx. 10 sec. (0–90%)
10 min. (for < 10 ppm approx. 6 h)
+/- (2% of dsplayed value + 1 ppm)
< 10% / year
Approx. 5 years
O and CO
