Genasun GV-5 Manual

Solar charge controllers with maximum power point tracking

Advertisement

Quick Links

SUNFORGE LLC
2598 FORTUNE WAY • SUITE K
VISTA, CA 92081 • USA
h ttps ://s unfo rg ellc .com
IMPORTANT SAFETY INSTRUCTIONS | SAVE THESE INSTRUCTIONS
GV-5 Manual
Solar Charge Controllers with Maximum Power Point Tracking
For models:
GV-5-Pb-12V:
GV-5-Pb-CV:
GV-5-Li-10.7V (-SP):
GV-5-Li-12.5V:
GV-5-Li-14.2V:
GV-5-Li-16.7V:
GV-5-Li-CV:
5 A Rated Output
GENASUN GV-5 (ALL MODELS) MANUAL, REVISION 4.1 | 2021
12 V Lead-Acid/AGM/Gel/Sealed/Flooded
12 V Custom Multi-Stage Lead-Acid/AGM/Gel/
Sealed/Flooded
9 V (3S) Lithium Iron Phosphate
11.1 V (3S) Lithium Cobalt/Manganese/Nickel
12 V (4S) Lithium Iron Phosphate
14.8 V (4S) Lithium Cobalt/Manganese/Nickel
Custom CC/CV or Multi-Stage Lithium

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Genasun GV-5

  • Page 1 5 A Rated Output SUNFORGE LLC 2598 FORTUNE WAY • SUITE K VISTA, CA 92081 • USA h ttps ://s unfo rg ellc .com GENASUN GV-5 (ALL MODELS) MANUAL, REVISION 4.1 | 2021 IMPORTANT SAFETY INSTRUCTIONS | SAVE THESE INSTRUCTIONS...
  • Page 2: Safety Instructions

    CIRCUIT CURRENT of the array while connected to the controller. Grounding is not necessary for operation and is at the user's discretion. If the GV-5 is to be used with a solar array electrically connected to earth ground, please note the following:...
  • Page 3: Product Certifications

    LITHIUM WARNING: Use caution when working with lithium systems. Genasun Li controllers use the CC/CV charging profile indicated on the controller. Check the specifications of the battery pack to ensure that the CV voltage is correct. Further check that the power supplied by the solar array and Genasun controller is within the battery specified design limits.
  • Page 4 Caution, p.2). GV-5 • The GV-5 can be mounted in any orientation on the floor or wall. We recommend a position in which all labels are clearly visible. Although the GV can be used in any orientation, for marine or other applications where liquid water may be nearby, the GV should be mounted with the terminal block down (or where not possible, to the side).
  • Page 5: Connecting The Battery

    85 °C ambient. If the GV-5 will be used with a solar panel or array with a short circuit current (Isc) of more than 8 A, the GV-5 input should be protected with a fast-acting fuse or circuit breaker of 10 A and rated for the maximum solar panel voltage.
  • Page 6: Status Indication

    Battery voltage too low: The controller cannot begin charging normally due 8-10 SEC. BETWEEN GREEN BLINKS to low battery voltage. Check the battery connections, wait for the GV-5's trickle function to charge the battery, or charge the battery by another means.
  • Page 7: Specifications

    0.125 mA (125 uA) (2) Panel Isc. Inputs exceeding this rating may cause damage to the GV-5 if the input or battery voltage changes abruptly. (3) Maximum steady-state current that the controller could draw from an unlimited source. This specification is intended for sizing input circuit protection.
  • Page 8 (5) Max ambient temperature for full operating power. Test conditions: 16 V input, 13 V output, GV-5 vertically (wall) mounted. (6) This specification does not apply to GV-5-PCB. Specifications for the GV-5-PCB are as follows: Weight: 0.8 oz (23 g); Dimensions: 3.3" x 1.9" x 0.9" (8.3 cm x 4.8 cm x 2.3 cm); Environmental Protection: IP00.
