GENASUN
c/o BLUE SKY ENERGY
2598 FORTUNE WAY • SUITE K
VISTA, CA 92081 • USA
https://sunforgellc.com/genasun
IMPORTANT SAFETY INSTRUCTIONS | SAVE THESE INSTRUCTIONS
GVB-8-WP (Boost) Manual
Waterproof Voltage Boosting Solar Charge Controllers with
Maximum Power Point Tracking
For models:
GVB-8-Pb-12V-WP:
GVB-8-Pb-24V-WP:
GVB-8-Pb-36V-WP:
GVB-8-Pb-48V-WP:
GVB-8-Li-14.2V-WP:
GVB-8-Li-28.4V-WP:
GVB-8-Li-41.7V-WP:
GVB-8-Li-54.2V-WP:
GVB-8-Li-56.8V-WP:
GVB-8-Li-58.4V-WP:
8A Input - 105W/210W/325W/350W
GENASUN GV-BOOST WP (ALL MODELS) MANUAL, REVISION 5.0 | 2019
12V Lead-Acid/AGM/Gel/Sealed/Flooded
24V Lead-Acid/AGM/Gel/Sealed/Flooded
36V Lead-Acid/AGM/Gel/Sealed/Flooded
48V Lead-Acid/AGM/Gel/Sealed/Flooded
12V (4s) Lithium Iron Phosphate
24V (8s) Lithium Iron Phosphate
36V (10s) Lithium Cobalt/Magnesium/Nickel
48V (13s) Lithium Cobalt/Magnesium/Nickel
48V (16s) Lithium Iron Phosphate
52V (14s) Lithium Cobalt/Magnesium/Nickel
Advertisement
Table of Contents
Related Manuals for Genasun GVB-8-WP Series
Summary of Contents for Genasun GVB-8-WP Series
- Page 1 52V (14s) Lithium Cobalt/Magnesium/Nickel c/o BLUE SKY ENERGY 2598 FORTUNE WAY • SUITE K 8A Input - 105W/210W/325W/350W VISTA, CA 92081 • USA https://sunforgellc.com/genasun GENASUN GV-BOOST WP (ALL MODELS) MANUAL, REVISION 5.0 | 2019 IMPORTANT SAFETY INSTRUCTIONS | SAVE THESE INSTRUCTIONS...
-
Page 2: Safety Instructions
Safety Instructions: This manual contains important instructions for the GV-Boost GVB-8-Pb-**V-WP and GVB-8-Li-**.*V-WP solar charge controllers that shall be followed during installation and maintenance. Various models of the GVB-WP are available to charge different battery types as follows: • GVB-8-Li-24.8V-WP: 24V (8s) Lithium Iron Phosphate •... -
Page 3: Product Certifications
Failure to do so may result in property damage, injury or death. Genasun highly recommends the use of a BMS with cell balancing. Cell balancing is mandatory for lithium iron phosphate. Use only copper conductors suitable for a minimum of 60 degrees C. - Page 4 Installation & System Connections: • Connections should be made according to Article 690 of the National Electrical Code (NFPA 70) Note: GVB is Negative Common, "-Panel" and "-Battery" (both black or the standards in force at the installation location. cables) are interchangeble. •...
- Page 5 PANEL BATTERY CONNECTING THE SOLAR PANEL Connect the solar panel to the +PANEL and –PANEL terminals. • In most applications, the panel should be connected only to the GVB-WP. • The LED may blink red until a battery is connected. •...
-
Page 6: Status Indication
Status Indication: ERROR INDICATION Overheat: The controller’s internal temperature is too high. SETS OF 2 RED BLINKS The GVB has a MULTICOLOR Overload: The GVB has been overloaded. RUN/CHARGE INDICATION This could be caused by changing the solar panel connections while the Standby: The battery is connected properly and ready to charge when solar controller is operating. -
Page 7: Specifications
Troubleshooting Note: The most common causes of blown fuses are: If the LED Indicator will not light, or displays an indication not listed in this manual: • Connecting the GVB-8-WP to the battery backwards; • Verify correct battery polarity; • Shorting the solar panel input while the GVB-8-WP is charging. In this case, •... - Page 8 Specifications (cont.): GVB-8-WP, All Models Weight: 10.3 oz. , 290 g Dimensions: 5.5 x 3.2 x 2.2”, 14 x 8.1 x 5.5 cm Warranty: 5 years GVB-8-Pb-12V-WP GVB-8-Pb-24V-WP GVB-8-Pb-36V-WP GVB-8-Pb-48V-WP Charge Profile: Multi-Stage with Temperature Compensation Nominal Battery Voltage: Maximum Recommended Panel Vmp: Maximum Recommended Panel Power 105W 210W...
