- Page 1 A PPLIANCES FO R LIV IN G ACG600X, ACG700X, ACG900X OPERATION MANUAL...
- Page 2 Congratulations, you are now the proud owner of an ARTUSI cooking appliance. Dear Artusi Customer, please read this user manual carefully before using the Thank you for purchasing ARTUSI and welcome to the ARTUSI Family. product and, keep it permanently at your disposal. Note: This user manual is prepared for more than one model.
-
Page 3: Information And Advice
Information and advice CAUTION: Accessible parts may become hot when used with cooking appliances. In certain circumstances electrical appliances may be a hazard. Please pay attention to the following points: A. Always have air circulating through the room when the hood is in use especially if other appliances burning gas or other fuels are in use. - Page 4 Know your cooker hood Please read these instructions before using your cooker hood. Congratulations on the purchase of our cooker hood which is designed to include many superior features. Before installing and using the hood carefully read all the instructions. 1.
-
Page 5: Installation
Installation Ensure the power is turned off before beginning the installation Check the voltage and frequency on the rating plate located inside the hood. The hood must not be installed and connected to flues where other appliances are installed. Ensure the hood is installed so that the bottom of the hood is no less than 600-750mm... - Page 6 Installation Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable laws, regulations and safety standards. Fig. 3 Attach the damper flap on the air outlet as shown.
- Page 7 Installation You will need two people to install this hood Using the drill hole stencil mark the screw positions on the wall. Drill four 8mm holes into the wall. Put one expansion plug and one 10mm screw into each of the holes.
- Page 8 Installation Hang the hood body onto the screws. First screw in the top 2 screws then the bottom 2 screws. Adjust the level of the hood on the wall to be straight horizontally.
-
Page 9: Horizontal Discharge
Installation Ensure the power is turned off before beginning the installation venting direction. into a fuel Attach the Vertical discharge of Horizontal discharge ducting hose to air. Run the ducting of air. Run the ducting the air duct. through a cupboard through the eaves and/or into a space (soffit) and the outside... - Page 10 Installation Attaching the chimney flues Assemble the 2 flues, inner top to outer bottom.Place them onto the hood body covering the air duct assembly and screw into place. Measure the height for the chimney flue bracket. Pull the inner chimney to the desired height.
- Page 11 Installation Attaching the chimney flues 2 x wood screws the chimney flue bracket into place as measured. Connect the chimney flues to the bracket using four 10mm 2 ST4x10 screws.
-
Page 12: Hood Operation
Hood Operation Caution Never cover the lamp with thermal Ensure the hood is OFF when first installed. insulation or Insert the power plug when all previous installation steps are any other completed. material. Press the Light button for the lights to turn ON. Warning The lamp is Press again to turn OFF... - Page 13 Replacement & maintenance Clean the filters and ventilating fan at least once every 3 months or earlier as required. Recirculation mode filter instructions Install a charcoal filter as shown. Note: The charcoal filter cannot be washed or cleaned and must be replaced as necessary.
-
Page 14: Cleaning Instructions
Cleaning instructions Turn off the hood before cleaning. 1. Clean the surface of the hood frequently using mild soap or detergent at least once every 3 months. Never let water enter the motor 2. Avoid the use of harsh cleaning agents as it may spoil the hood’s or electrical appearance. - Page 15 The manufacturer shall decline all responsibility when the recommendations and instructions regarding installation, maintenance and use are not observed.
- Page 16 Card. Please contact artusi on 1300 694 handling in transit (other than when Worldwide 583 should you not wish to be contacted by Appliances is responsible); Worldwide Appliances. (f) damage through exposure to chemicals, dusts, residues, excessive voltage, heat, WARRANTY atmospheric conditions or other forces or environmental factors outside the control or 1.
- Page 17 5. Proof of Purchase (c) Worldwide Appliances excludes indirect or major failure. consequential loss of any kind (including, without Customers must retain proof of purchase in order limitation, loss of use of the artusi product) and to be eligible to make a warranty claim in respect 8.
- Page 19 DISCLAIMER Worldwide Appliances PTY LTD, trading as ARTUSI, is continually seeking ways to improve the design specifications, aesthetics and production techniques of its products. As a result alterations to our products and designs take place continually. Whilst every effort is made to produce information and literature that is up to date, this brochure should not be regarded as an infallible guide to the current specifications, nor does it constitute an offer for the sale of any particular product.
