D G F r
6000-3970-0000-1XX 39700-0000 V100 09 ⁄ 2022
KFTF-35
HYGRASREG
®
D
Bedienungs- und Montageanleitung
Betauungsgeschützer Kanal- Feuchte- und Temperaturfühler
für „Hochfeuchte", inkl. Montageflansch,
kalibrierfähig, mit Mehrbereichsumschaltung,
mit aktivem und schaltenden Ausgang
G
Operating Instructions, Mounting & Installation
Condensation-protected duct humidity and temperature sensor
for "high humidity", incl. mounting flange,
calibratable, with multi-range switching,
with active and switching output
F
Notice d'instruction
Sonde de température et d'humidité pour montage en gaine
protégée contre la condensation pour « humidité élevée »,
y compris bride de montage, étalonnable,
avec commutation multi-gamme,
avec sortie active et en tout ou rien
r
Руководство по монтажу и обслуживанию
Защищенный от образования конденсата канальный датчик
влажности и температуры для высокой влажности,
включ. присоединительный фланец, калибруемый,
с переключением между несколькими диапазонами,
с активным и релейным выходом
S+S REGELTECHNIK GMBH
THURN-UND-TAXIS - STR. 22
90411 NÜRNBERG ⁄ GERMANY
FON +49 ( 0 ) 911 ⁄ 5 19 47- 0
mail@SplusS.de
www.SplusS.de
CARTONS
ET EMBALLAGE
PAPIER À TRIER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYGRASREG KFTF-35 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for S+S Regeltechnik HYGRASREG KFTF-35

  • Page 1 влажности и температуры для высокой влажности, включ. присоединительный фланец, калибруемый, с переключением между несколькими диапазонами, с активным и релейным выходом S+S REGELTECHNIK GMBH THURN-UND-TAXIS - STR. 22 90411 NÜRNBERG ⁄ GERMANY CARTONS FON +49 ( 0 ) 911 ⁄ 5 19 47- 0 ET EMBALLAGE mail@SplusS.de...
  • Page 2 D G F r M16x1.5 ø32.3 KFTF-35 HYGRASREG ® Maßzeichnung KFTF-35 Dimensional drawing Plan coté Габаритный чертеж [mm] M16x1.5 ø32.3 ø 20 M16x1.5 ø 20 MFT - 20 - K Montageflansch aus Kunststoff Mounting flange, plastic Bride de montage en matière plastique Присоединительный...
  • Page 3: Technische Daten

    ® HYGRASREG KFTF-35 Rev. Data - V20 Betauungsgeschützer Kanalfühler HYGRASREG ® KFTF-35 mit aktivem und schaltendem Ausgang, Gehäuse aus schlagfestem Kunststoff mit Schnellverschlussschrauben, Kabelverschraubung, Kunststoff- Sinterfilter (austauschbar), wahl weise mit ⁄ ohne Display, zur Erfassung der relativen Feuchte (0…100 % RH) und der Temperatur (4 umschaltbare Mess bereiche, max. 0...+100 °C) sowie zur Ermittlung diverser Kenn größen der Feuchte messtechnik.
  • Page 4 ® HYGRASREG KFTF-35 Rev. Data - V20 TECHNISCHE DATEN (Fortsetzung) FUNKTION Durch eine stetige Übertemperatur des Feuchtesensors wird dessen Betauen maßgeblich erschwert bzw. im Rahmen der Systemgrenzen verhindert. Es wird eine schnellere Reaktionsgeschwindigkeit bei Feuchteschwankungen, auch im Bereich oberhalb von 95 % RH erreicht. Der Sensor (kombiniertes Feuchte- und Temperaturmesselement) wird ca.
  • Page 5 ® HYGRASREG KFTF-35 Rev. Data - V20 Schaltbild KFTF-35 - xx Anschlussbild KFTF-35 - I 1 +UB 24V AC/DC –UB GND Ausgang Feuchte 4...20mA Ausgang Temperatur 4...20mA Ausgang altern. Kenngröße 4...20mA Öffner offset offset TEMP Wurzel Schließer thershold 1 2 3 4 5 6 Anschlussbild KFTF-35 - U Relais...
  • Page 6 Montage und Inbetriebnahme VERSORGUNGSSPANNUNG: Schaltbild Einzelbetrieb Als Verpolungsschutz der Betriebsspannung ist bei dieser Gerätevariante eine Einweggleichrichtung bzw. Verpolungschutzdiode integriert. Diese interne Einweggleichrichtung erlaubt auch den Betrieb mit AC-Versorgungs- spannung. Das Ausgangssignal ist mit einem Messgerät abzugreifen. Hierbei wird Schaltung das Ausgangssignal gegen das Nullpotenial (O V) der Eingangsspannung Versorgung mit ge messen! AC 24V~...
  • Page 7 Wichtige Hinweise – Dieses Gerät darf nur in schadstofffreier, nicht kondensierender Luft, ohne Über- oder Unterdruck am Sensorelement eingesetzt werden. – Bei Aussen- und Kanalfühlern schützt der Sinterfilter des Sensorelementes den Feuchtesensor vor eventuellen Staub belastungen. Dieser Filter sollte bei Verunreinigung ⁄ Verschmutzung regelmäßig gewartet werden. –...
  • Page 8: Technical Data

    ® HYGRASREG KFTF-35 Rev. Data - V20 Condensation-protected ductsensor HYGRASREG ® KFTF-35 with active and switching output, housing made of impact-resistant plastic with quick-locking screws, cable gland, plastic sinter filter (replaceable), optionally with ⁄ without display, for detecting relative humidity (0…100 % RH) and temperature (4 switchable measuring ranges, max.
  • Page 9 ® HYGRASREG KFTF-35 Rev. Data - V20 TECHNICAL DATA (continued) FUNCTION A constant overtemperature of the humidity sensor makes its dewing considerably more difficult or prevents its formation within the limits of the system. A faster reaction speed is achieved in the case of humidity fluctuations, even in the range above 95 % RH.
  • Page 10 ® HYGRASREG KFTF-35 Rev. Data - V20 Schematic diagram KFTF-35 - xx Connecting diagram KFTF-35 - I +UB 24V AC/DC –UB GND Output Humidity 4...20mA Output Temperature 4...20mA Output altern. parameters 4...20mA NC Normally Closed offset offset TEMP M Common NO Normally Open thershold 1 2 3 4 5 6...
  • Page 11 Installation and Commissioning SUPPLY VOLTAGE : Connecting scheme Individual operation For operating voltage reverse polarity protection, a one-way rectifier or reverse polarity protection diode is integrated in this device variant. This internal one-way rectifier on AC supply voltage. The output signal is to be tapped by a measuring instrument. The output signal is measured her against zero potential (O V) of the input voltage! Circuitry When this device is operated on DC supply voltage , the operating voltage...
  • Page 12 General notes – This unit must only be used in non-precipitating air without positive or negative pressure at the sensor element. – With outdoor and duct sensors, the sinter filter of the sensor element protects the humidity sensor against potential dust exposure. In case of contamination/soiling, this filter should be cleaned on a regular basis.
  • Page 13: Caractéristiques Techniques

    ® HYGRASREG KFTF-35 Rev. Data - V20 Sonde de mesure pour montage en gaine protégée contre la condensation HYGRASREG ® KFTF-35 avec sortie active et en tout ou rien, avec boîtier en plastique résistante aux chocs et vis de fermeture rapide, presse-étoupe, filtre fritté en plastique (remplaçable), au choix avec/sans écran, pour détecter l’humidité...
  • Page 14 ® HYGRASREG KFTF-35 Rev. Data - V20 CARAC TÉRISTIQUES TECHNIQUES (continued) FONCTION Une surchauffe constante de la sonde d’humidité rend la formation de condensation beaucoup plus difficile et peut même l’empêcher dans les limites du système. On obtient une vitesse de réaction plus rapide en cas de variations d’humidité, même dans une plage supérieure à...
  • Page 15 ® HYGRASREG KFTF-35 Rev. Data - V20 Schéma de connexion KFTF-35 - xx Schéma de raccordement +UB 24V AC/DC –UB GND Output Humidity 4...20mA Output Temperature 4...20mA Output altern. parameters 4...20mA NC Normally Closed offset offset TEMP M Common NO Normally Open thershold 1 2 3 4 5 6 Schéma de raccordement...
  • Page 16 Montage et mise en service TENSION D’ALIMENTATION : Schéma de raccordement individuel Cette variante d’appareil est dotée d’une protection contre l’inversion de polarité, c’.-à.-d. elle comprend un redressement demi-onde (diode de redresse ment). Grâce à cette diode de redressement intégrée, les appareils 0 -10 V peuvent également être alimentés en courant alternatif.
  • Page 17 Généralités – Cet appareil ne doit être utilisé que dans un air non pollué, sans risque de condensation, sans risque de surpression ou dépression sur l’élément capteur. – Dans le cas des sondes extérieures et des sondes de mesure pour montage en gaine, le filtre fritté...
  • Page 18: Технические Данные

    ® HYGRASREG KFTF-35 Rev. Data - V20 Защищенный от образования конденсата канальный датчик HYGRASREG ® KFTF-35 активным и релейным выходом, корпус из ударопрочного пластика с быстрозаворачиваемыми винтами, кабельный ввод, пластиковый спеченный фильтр (сменный), на выбор с дисплеем или без дисплея, для измерения относительной влажности (0…100 %) и температуры (4 переключаемых диапазона измерения, макс.
  • Page 19: Принцип Работы

    ® HYGRASREG KFTF-35 Rev. Data - V20 ТЕ ХНИЧЕСКИЕ Д АННЫЕ (продолжение) ПРИНЦИП РАБОТЫ Постоянный нагрев датчика влажности в значительной степени затрудняет или предотвращает образование на нем конденсата в пределах системных ограничений. Обеспечивается более быстрая реакция при колебаниях влажности даже в диапазоне выше 95 % отн. вл. Датчик...
  • Page 20 ® HYGRASREG KFTF-35 Rev. Data - V20 Схема подключения KFTF-35 - xx Схема соединения +UB 24V AC/DC –UB GND Output Humidity 4...20mA Output Temperature 4...20mA Output altern. parameters 4...20mA NC Normally Closed offset offset TEMP M Common NO Normally Open thershold 1 2 3 4 5 6 Схема...
  • Page 21: Напряжение Питания

    Монтаж и ввод в эксплуатацию НАПРЯЖЕНИЕ ПИТАНИЯ: Схема соединения Одиночное подключение В качестве защиты от неправильного подключения рабочего напряжения в данный вариант прибора интегрирован однополупериодный выпрямитель или диод защиты от напряжения обратной полярности. В случае приборов, рассчитанных на напряжение 0 – 10 В, этот встроенный выпрямитель допускает...
  • Page 22 Указания к продуктам – Прибор можно использовать только в воздухе без конденсата и вредных веществ, без повышенного или пониженного давления возле чувствительного элемента. – В датчиках для наружной и канальной установки спеченный фильтр защищает чувствительный элемент датчика влажности от возможного запыления.
  • Page 23 Reprint in full or in parts requires permission from S+S Regeltechnik GmbH. La reproduction des textes même partielle est uniquement autorisée après accord de la société S+S Regeltechnik GmbH. Перепечатка, в том числе в сокращенном виде, разрешается лишь с согласия S+S Regeltechnik GmbH.
  • Page 24 D G F r KFTF-35 HYGRASREG ® Montageschema KFTF-35 Mounting diagram Schéma de montage Схема монтажа Hinweis: Die Einbautiefe des Gerätes ist so zu wählen, dass die seitlichen Öffnungen des PLEUROFORM-Rohres innerhalb des Kanals liegen. Note: The mounting depth of the unit must be selected in such way that the lateral openings of the PLEUROFORM pipe are inside the duct. Remarque : la profondeur de montage de l’appareil doit être choisie de manière à...
