CONTENTS 1. Safety warnings 1.1 Warning 1.2 Meaning of safety warning symbols 1.3 Electricity related warnings 1.4 Warnings for using 1.5 Warnings for placement 1.6 Warnings for energy 1.7 Warnings for disposal 2. Proper use of the refrigerator 2.1 Placement 2.2 Leveling feet 2.3 Door right-left change 2.4 Changing the Light...
1. Safety warnings READ SAFETY PRECAUTIONS BEFORE INSTALLATION To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. 1.1 Warning WARNING Warning: risk of fire /flammable materials WARNING: Risk of fire disaster and explosion...
Page 8
WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer. WARNING: Please abandon the refrigerator according to local regulators for it use flammable cyclopentane foaming material and refrigerant. WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
Page 9
If noise, odor and smoking happens, please unplug the power plug immediately, and contact the distributor or local service agent. Please do not put your hands under or behind the appliance to prevent from being hurt. Please leave the packing materials and other parts out of the reach of children to prevent from risk of suffocation.
1.2 Meaning of safety warning symbols This is a prohibition symbol. Any incompliance with instructions marked with this symbol may result in damage to the product or endanger the personal safety of the user. Prohibition symbol This is a mandatory action symbol. It is required to operate in strict observance of instructions marked with this symbol, otherwise damage to the product or personal injury may be caused.
Please ensure that the grounding electrode of the power socket is equipped with a reliable grounding line. Please ask for help from persons with professional qualification to examine whether the socket is with reliable grounding line or not. lt is the user's responsibility to change the ungrounded socket into grounded socket.
Do not pick foods or containers with wet hands in the freezing chamber when the refrigerator is running, especially metal containers in order to avoid frostbite. Do not allow any child to get into or climb the refrigerator; otherwise su ocation or falling injury of the child may be caused.
1.6 Warnings for energy Refrigerating appliances might not operate consistently (possibility of defrosting of contents or temperature becoming too warm in the freezing chamber) when sited for an extended period of time below the cold end of the range of temperatures for which the refrigerating appliance is designed.
2.2 Leveling feet Schematic dia gram of the leveling feet (The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor) Adjusting procedures: a. Turn the feet clockwise to raise the refrigerator; b.
Page 16
2. Remove the upper left hinge cover decorative cover, upper right hinge cover and upper right hinge, and disconnect the right signal line(signal line terminal 1,2) at the top of the box body Upper hinge cover Upper hinge Decorative cover 3.
Page 17
5. Change the refrigerator door: 1) Remove the cover plate of the upper end cover of the refrigeration door and the left decorative cover. Install the upper shaft sleeve and the signal line of the door body to the other side and cover the upper end cover plate.
Page 18
7. Install the replaced freezing door on the lower hinge then install the middle hinge and cover the hinge hole decorative cover. Decorative cover Middle hinge 8. Remove the upper left hinge cover and upper left hinge from the accessory bag. Place the refrigerated door body on the middle hinge and install the upper left hinge.
2.4 Changing the Light Any replacement or maintenance of the LED lamps is intended to be made by the manufacture, its service agent or similar qualified person. 2.5 Starting Before initial start, keep the refrigerator still for two hours before connecting it to power supply. Before putting any fresh or frozen foods, the refrigerator shall have run for 2-3 hours, or for above 4 hours in summer when the ambient temperature is high.
3. Structure and functions 3.1 Key components Door switch LED light Shelf Shelf LED light Door tray (for some models) Shelf Fruits & vegetables box Meat & fish box Drawer Glass board (Do not place foods and etc on Glass board.) (The picture above is only for reference.
Page 21
Refrigerating chamber The Refrigerating chamber is suitable for storage of a variety of fruits, vegetables, beverages and other food consumed in the short term. suggested storage time 3days to 5days. Cooking foods shall not be put in the refrigerating chamber until cooled to room temperature.
3.2 Functions (The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor) Displayscreen 1. Refrigerating chamber termperature display area 2. Quick cool icon 3. Variable chamber display area 4. Freezing chamber temperature display area 5.
Page 23
When there is a "fault code visible" type of fault or when the door is opened for a long time, the light bar is flashing red. Lock/unlock In the non locked state, press and hold the "TEMP SELECT" for 3 seconds to enter the locking state.
Page 24
Mode setting Quick cooling mode setting In the non fast cooling mode, press the "-" button for 3s, will light up, and the refrigeration display will be 2°C, enter the fast cooling mode. In the quick cooling mode, press the "-" button for 3s or short press the "+", "-" button, will go out, the refrigeration display will set the temperature before the quick cooling, and exit the quick cooling mode.
Page 25
Opening warning and alarm control When open the refrigerator door, the door open music will play. If the door is not closed in two minutes, the buzzer will sound until the door closed. Press any one button to stop the buzzer alarm. Fault indication The following warnings appearing on the display indicate corresponding faults of the refrigerator.
4. Maintenance and care of the appliance 4.1 Overall cleaning Check the door seals regularly to make sure there are no debris. Clean the door seals with a soft cloth dampened with soapy water or diluted detergent. The interior of the refrigerator should be cleaned regularly to avoid odor. Please turn o the power before cleaning interior, remove all foods, drinks, shelves, drawers, etc.
4.3 Defrosting The refrigerator is made based on the indirect cooling system and thus has automatic defrosting function. Frost formed due to change of season or temperature may also be manually removed by disconnection of the appliance from power supply or by wiping with a dry towel. 4.4 Out of operation Power failure: In case of power failure, even if it is in summer, foods inside the appliance can be kept for several hours;...
5. Troubleshooting You may try to solve the following simple problems by yourself. If them cannot be solved, please contact the after-sales department. Occurrence Possible cause/inspection items Operation failure Check whether the appliance is connected to power or whether the plug is in well contact.
6. Disposal of your appliance Correct Disposal of this product: This marking indicates that this product should not be disposed with other house hold wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
Page 31
Orient Household Appliances Ltd. Novodmitrovskaya st., 2, bld.1 17th floor, office 04, Moscow Russia 127015 MIDEA Middle East Room 402, LOB16, Jebel Ali Free Zone, Dubai,U.A.E. Tel:971-48873890 Fax:971-48873891 Hubei Midea Refrigerator Co., Ltd. No.38 Oriental Road, 434000, Jingzhou, Hubei, P.R. China MADE IN CHINA...
Page 89
Orient Household Appliances Ltd. Novodmitrovskaya st., 2, bld.1 17th oor, o ce 04, Moscow Russia 127015 MIDEA Middle East Room 402, LOB16, Jebel Ali Free Zone, Dubai,U.A.E. Tel:971-48873890 Fax:971-48873891 Hubei Midea Refrigerator Co., Ltd. No.38 Oriental Road, 434000, Jingzhou, Hubei, P.R. China MADE IN CHINA...
Page 92
MUNDARIJA 1. Xavfsizlik ogohlantirishlari 1 . 1 Ogohlantirish 1 . 2 Xavfsizlik ogohlantirish belgilari mazmuni 1 . 3 Elektrga aloqador ogohlantirishlar 1 . 4 Foydalanish uchun ogohlantirishlar 1 . 5 Joylashtirish uchun ogohlantirishlar 1 . 6 Energiya uchun ogohlantirishlar 1 . 7 Chiqitga chiqarish bo yicha ogohlantirishlar 2.
1. Xavfsizlik ogohlantirishlari O RNATISHDAN AVVAL EHTIYOT CHORALARINI O QIB CHIQING Foydalanuvchi yoki boshqa odamlar shikastlanishi va mulkka ziyon 1.1 Ogohlantirish OGOHLANTIRISH qilish kerak: Elektr shnuri shikastlanganida almashtirilishi kerak. Almashtirish uchun Jihozni tozalashda yoki uzoq vaqt davomida ishlatilmasa, vilkani Uzatma shnur yoki yerga ulanmagan (ikki kontaktli) adapterlardan foydalanmang.
Page 94
OGOHLANTIRISH: Ishlab chiqaruvchi tavsiya etgan turdan boshqa elektr OGOHLANTIRISH: Sovitkich yonuvchan siklopentan va sovituvchi utilizatsiya qiling. portativ elektr manbalarini joylamang. boshqa issiq suv yoki suyuqliklar, masalan sharbat quymang. XAVF: Bolalarning tiqilib qolishi xavfi. Eski sovitkich yoki muzlatkichni tashlab yuborishingizdan avval: - Eshiklar va eshik zichlagichlarini oling.
Page 95
murojaat qiling. boshqa qismlarni bolalar ololmaydigan joyda qoldiring. amal qiling: sirtlarni tez-tez tozalang. - Agar suv baklari 48 (1-eslatma) uchun ularni sovitkichda alohida idishlarda saqlang. mahsulotlarni saqlash, muzqaymoqni saqlash yoki tayyorlash va muz kublarini tayyorlash uchun mos keladi. (2-eslatma) - Bir, ikki va uch yulduzli bo‘linmalar yangi ovqatni muzlatish uchun mos emas.
1.2 Xavfsizlik ogohlantirish belgilari mazmuni Bu taqiqlash belgisi. mahsulot shikastlanishi yoki foydalanuvchining shaxsiy Taqiqlash belgisi Bu majburiy harakat belgisi. yetishi yoki shaxsiy jarohat olish mumkin. Majburiy harakat belgisi Bu ehtiyotkorlik belgisi. Ehtiyotkorlik belgisi zarar yetkazishi mumkin. Ushbu qo llanma foydalanuvchilar amal qilishi kerak bo lgan ko plab muhim xavfsizlik ma lumotlarini o z ichiga oladi.
Elektr rozetkasining yerga ulangan elektrodi ishonchli yerga ulash liniyasi bilan jihozlanganiga ishonch hosil qiling. Rozetka ishonchli yerga ulash liniyasi bilan jihozlangan yoki jihozlanmaganini aniqlash uchun professional Yerga ulanmagan rozetkani yerga ulangan rozetkaga va boshqa yonuvchan gazlar sizib chiqsa, eshik va oynalarni oching.
1.6 Energiya uchun ogohlantirishlar mumkin (qismlardagi muzlarning erishi yoki muzlatish kamerasidagi harorat juda ilib ketganida). qilinmasligi kerak. Har qanday turdagi oziq-ovqat va ayniqsa, sotish uchun tezkor muzlatilgan mahsulotlarni mahsulot muzlatkichi va muzlatilgan mahsulotlarni saqlash Sovitish jihozining muzini eritishda muzlatilgan oziq-ovqat mahsulotlari haroratining haddan oshib ketishining oldini olish choralariga, masalan mumkin.
2.2 Tekislovchi oyoq Tekislovchi oyoqning sxematik diagrammasi Rostlash tartibi: 2.3 Eshikni o ng-chapga o zgartirish Philips otvertkasi Kurakcha (Philips vintini yechish va yupqa uchli otvyortka qotirish uchun ishlating) sharnir qoplamasini yechish uchun ishlating) 5 16" rozetka va xrapovik Tasma (Oltiqirrali vintlarni yechish (Eshikni vaqtinchalik qotirish va qotirish uchun ishlating) uchun ishlating)
Page 102
liniyasini (signal liniyasining 1, 2 klemmasi) uzing Yuqori sharnir qoplamasi Yuqori sharnir Bezak qoplama 3. Sovitkich eshigi korpusini yechib oling (val vtulkasi va eshikning stopori kabi qoplamasini yechib oling. Bezak qoplama 4. Muzlatkich eshigi korpusini yechib oling (val vtulkasi va eshikning stopori kabi Sharnirni yechib oling va burchakni rostlang.
Page 103
1) Sovitkich eshigining yuqori uchidagi qoplamasining qoplama plastinasini va chap dekorativ qoplamasini yechib oling. Yuqori val vtulkasini va eshik korpusining signal liniyasini boshqa tomonga oling, uni sovitkich eshigining pastki uchidagi qoplamasining chap tomoniga qoplamasining chap tomoniga almashtiring. 1) Muzlatkich eshigining yuqori uchidagi qoplamasining val vtulkasi va oling, uni muzlatkich eshigining pastki uchidagi qoplamasining chap tomoniga qoplamasining chap tomoniga almashtiring.
Page 104
Bezak qoplama sharnir 8. Yordamchi moslamalar xaltasidan yuqori chap sharnir qoplamasi va yuqori chap sharnirni oling. 4-signal liniyasini eshik korpusi 1-signal liniyasiga ulang va 2-signal liniyasini 3-signal liniyasiga ulang. tomoniga almashtirishda sharnir dekorativ qoplamasidagi ikki uchi (rasmda Yuqori sharnir qoplamasi Bezak qoplama Yuqori sharnir Uchlar...
2.4 Chiroqni almashtirish oshirilishi belgilangan. 2.5 Boshlash Dastlabki ishga tushirishdan avval sovitkichni elektr tokiga ulashdan oldin sovitkichni ikki soat ishlatmang. sovitkich 2-3 soat yoki tashqi muhit harorati yuqori 595mm Eshik va tokchalarning qulay ochilishi uchun yetarli 135° 998mm 2.6 Energiyani tejash bo yicha maslahatlar Jihoz xonaning eng sovuq, issiqlik ishlab chiqaruvchi jihozlar yoki isitish kerak.
Shisha taxta (Shisha idishga oziq-ovqat va boshqalarni qo'ymang.)
Page 107
Sovitish kamerasi Sovitish kamerasi turli mevalar, sabzavotlar, ichimliklar va qisqa muddatda etilgan saqlash vaqti 3 kundan 5 kungacha. Pishiriladigan oziq-ovqatlar xona haroratida sovitilmagunicha sovitish tavsiya etiladi. tepaga yoki pastga rostlanishi mumkin. Muzlatish kamerasi Sovitish kamerasi mahsulotlarni uzoq vaqt yangi saqlashi mumkin va bu asosan muzlatilgan mahsulotlar va muz yasash uchun ishlatiladi.
3.2 Funksiylar Displey ekrani 1. Sovitish kamerasi harorat datchigi nosozligi 2. Tezkor sovitish belgisi 3 5. Tezkor muzlatish belgisi 6. Tanaffus belgisi 7. Aqlli rejimi 8. Qulflash belgisi Ish tugmasi A. Harorat hududini tanlash tugmasi B. Harorat + C. Harorat - D.
Page 109
uzoq vaqt ochiq tursa, chiroq paneli qizil rangda yonadi. Qulflash/qulfni ochish Qulflanmagan holatda, qulflash holatiga kirish uchun “TEMP SELECT 3 soniya bosib turing. Qulflangan holatda, qulflanmagan holatga kirish uchun “TEMP SELECT 3 soniya bosib turing. yonadi va qulfdan ochish signali chalinadi. 30 soniya ishlamasa, u avtomatik quflash holatiga kiradi va bir vaqtda qulflash signali chalinadi.
Page 110
Harorat -24 16°C 24°C deb belgilaydi. Sovuqlikni saqlash xonasining sozlash diapazoni -16~-24°C, sozlama qulflanganidan keyin ishga tushadi. Rejimni sozlash Tezkor sovitish rejimini sozlash 3 soniya bosib turing, yonadi va sovitish displeyi 2 qisqa bosing, holatga sozlaydi va tezkor sovitish rejimidan chiqadi. Tanaffus rejimini sozlang va tezkor sovitish rejimidan chiqing.
Page 111
Ochilishning ogohlantirish va signalini boshqarish Sovitkichning eshigi ochilsa, eshik ochilishi musiqasi jaranglaydi. Agar eshik ikki daqiqada yopilmasa, eshik yopilguncha signal chalib turadi. Xatoni ko rsatish Xato kodi Sovitish kamerasining harorat datchigi nosozligi Muzlatish kamerasining harorat datchigi nosozligi Muzni eritish datchigining aniqlash zanjiri xatoligi Aloqa xatoligi Tashqi harorat datchigi xatoligi...
5. Nosozliklarni aniqlash Siz quyidagi oddiy muammolarni hal qilishingiz mumkin. Agar ularni hal qilib bo‘lmasa, iltimos, sotuvdan keyingi bo‘limga murojaat qiling. Muvaffaqiyatsiz ishlash Kuchlanish juda past ekanini tekshiring. Elektr nosozligi yoki qisqa zanjirlarning ishlab ketganini tekshiring. Aynib qolgan mahsulot mavjudligini tekshiring. Sovitkichning ichini tozalang.
1. A++ (yuqori samaradorlik) dan G (past samaradorlik) gacha 2. GR-RB449WE-PM*(**): Yiliga 248 kVt/soat 24 soatlik standart tezkshiruvning natijalariga (0.680 kVt soat/24) asoslangan. Haqiqiy energiya sar ishlatiladigan harorat sozlamalari va jihozning joylashuviga bog liq bo ladi. GR-RB500WE-PM*(**): Yiliga 260 kVt/soat 24 soatlik standart tezkshiruvning natijalariga (0.712 kVt soat/24) asoslangan.
