Owner's Manual
REFRIGERATOR FREEZER
For Home Use Only
GR-RB410WE-PMM(06)
Thank you very much for purchasing this Toshiba product.
Read this Owner's Manual and become completely familiar with the product
before use in order to use this product safely and correctly.
Keep this Owner's Manual in a handy place for future reference.
Make sure that you received your warranty.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GR-RB410WE-PMM(06) and is the answer not in the manual?

Questions and answers

Related Manuals for Toshiba GR-RB410WE-PMM(06)

Summary of Contents for Toshiba GR-RB410WE-PMM(06)

  • Page 1 REFRIGERATOR FREEZER For Home Use Only GR-RB410WE-PMM(06) Thank you very much for purchasing this Toshiba product. Read this Owner’s Manual and become completely familiar with the product before use in order to use this product safely and correctly. Keep this Owner’s Manual in a handy place for future reference.

  • Page 3: Table Of Contents

    CONTENTS 1. Safety warnings 1.1 Warning 1.2 Meaning of safety warning symbols 1.3 Electricity related warnings 1.4 Warnings for using 1.5 Warnings for placement 1.6 Warnings for energy 1.7 Warnings for disposal 2. Proper use of the refrigerator 2.1 Placement 2.2 Leveling feet 2.3 Door Right-Left Change (optional) 2.4 Changing the Light...

  • Page 4: Safety Warnings

    1. Safety warnings READ SAFETY PRECAUTIONS BEFORE INSTALLATION To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. 1.1 Warning WARNING Warning: risk of fire /flammable materials WARNING: Risk of fire disaster and explosion...
  • Page 5 WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer. WARNING: Please abandon the refrigerator according to local regulators for it use flammable cyclopentane foaming material and refrigerant. WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
  • Page 6 If noise, odor and smoking happens, please unplug the power plug immediately, and contact the distributor or local service agent. Please do not put your hands under or behind the appliance to prevent from being hurt. Please leave the packing materials and other parts out of the reach of children to prevent from risk of suf focation.

  • Page 7: Meaning Of Safety Warning Symbols

    1.2 Meaning of safety warning symbols This is a prohibition symbol. Any incompliance with instructions marked with this symbol may result in damage to the product or endanger the personal safety of the user. Prohibition symbol This is a mandatory action symbol. It is required to operate in strict observance of instructions marked with this symbol, otherwise damage to the product or personal injury may be caused.

  • Page 8: Warnings For Using

    Please ensure that the grounding electrode of the power socket is equipped with a reliable grounding line. Please ask for help from persons with professional qualif ication to examine whether the socket is with reliable grounding line or not. lt is the user's responsibility to change the ungrounded socket into grounded socket.

  • Page 9: Warnings For Placement

    Do not pick foods or containers with wet hands in the freezing chamber when the refrigerator is running, especially metal containers in order to avoid frostbite. Do not allow any child to get into or climb the refrigerator; otherwise suf focation or falling injury of the child may be caused.

  • Page 10: Warnings For Energy

    1.6 Warnings for energy Refrigerating appliances might not operate consistently (possibility of defrosting of contents or temperature becoming too warm in the freezing chamber) when sited for an extended period of time below the cold end of the range of temperatures for which the refrigerating appliance is designed.

  • Page 11: Proper Use Of The Refrigerator

    The top space of the refrigerator shall be greater than 0cm, and the refrigerator should be placed against a wall with a free distance more than 10cm to facilitate heat dissipation. 10cm 10cm...

  • Page 12: Leveling Feet

    2.2 Leveling feet Schematic diagram of the leveling feet (The picture above is only for reference. The actual conf iguration will depend on the physical product or statement by the distributor) Adjusting procedures: a. Turn the feet clockwise to raise the refrigerator; b.

  • Page 13: Door Right-Left Change (Optional)

    2.3 Door Right-Left Change (optional) List of tools to be provided by the user Putty knife Cross screwdriver thin-blade screwdriver 5/16" Masking tape socket and ratchet Parts to be used for door reverse Number Name Quantity Note Pre-installed on the refrigerator, removed when the door Right upper hinge is reversed, and kept for future use Pre-installed on the refrigerator, removed when the door...
  • Page 14 4. Remove the freezing door body (be careful not to lose small parts such as the shaft sleeve and stop on the door); Remove the hinge and adjust the angle. Remove and install the lower hinge shaft to the other side of the hinge, and install the modified lower hinge to the other side of the box.
  • Page 15 7. Install the replaced freezing door on the lower hinge, then install the middle hinge and cover the hinge hole decorative cover. decorative cover middle hinge 8. Remove the upper left hinge cover and upper left hinge from the accessory bag. Place the refrigerated door body on the middle hinge and install the upper left hinge.

  • Page 16: Changing The Light

    2. Changing the Light Any replacement or maintenance of the LED lamps is intended to be made by the manufacture, its service agent or similar person. 2. Starting Before initial start, keep the refrigerator still for two hours before connecting it to power supply. Before putting any fresh or frozen foods, the refrigerator shall have run for 2-3 hours, or for above 4 hours in summer when the ambient temperature is high.

  • Page 17: Structure And Functions

    3. Structure and functions 3.1 Key components Temperature control & LED lighting panel Door Tray Shelf Deodorizer Door Tray Shelf Fruits and vegetables box Flex Zone Drawer (The picture above is only for reference. The actual conf iguration will depend on the physical product or statement by the distributor)
  • Page 18 Refrigerating chamber The Refrigerating chamber is suitable for storage of a variety of fruits, vegetables, beverages and other food consumed in the short term. Cooking foods shall not be put in the refrigerating chamber until cooled to room temperature. Foods are recommended to be sealed up before putting into the refrigerator. The glass shelf can be adjusted up or down for a reasonable amount of storage space and easy use.

  • Page 19: Functions

    3.2 Functions (The picture above is only for reference. The actual conf iguration will depend on the physical product or statement by the distributor) 1) Operation button A : Temperature setting button of refrigerator compartment 2) Temperature control panel LED1：setting 1 (6°C) LED2：setting 2 (4°C) LED3：setting 3 (3°C) LED4：setting 4 (2°C)
  • Page 20 5) Super freeze mode Long press temperature setting button for 3s, after LED ② and LED ③ light up for 30s, it will enter into Super freeze mode. Long press temperature setting button for 3s, it will cancel Super freeze mode. 6) Temperature adjustment knob for freezer chamber This knob is located at left side behind of Fruits and vegetables box.

  • Page 21: Flex Zone

    3.3 Flex Zone Flex Zone can change position from left to right as shown in the f igure below...

  • Page 22: Maintenance And Care Of The Refrigerator

    4. Maintenance and care of the refrigerator 4.1 Overall cleaning Check the door seals regularly to make sure there are no debris.Clean the door seals with a soft cloth dampened with soapy water or diluted detergent. The interior of the refrigerator should be cleaned regularly to avoid odor. Please turn of f the power before cleaning interior, remove all foods, drinks, shelves, drawers, etc.

  • Page 23: Cleaning The Glass Shelf

    4.3 Cleaning the glass shelf Lift up the rear of the glass shelf slightly and pull it out. Fully open the door and take it out so that the inside of the door and the shelf do not bump. Take out the glass shelf and clean it as needed. Install the glass shelf in the reverse method of the removal.

  • Page 24: Large Particle Ice Tray(Optional)

    4.5 Large particle ice tray (optional) Ice cube tray should be cleaned before use. Add an appropriate amount of water to the water level line on the ice cube tray, and then place the ice tray in the ice making area . After ice making, remove and twist the ice cube tray to remove the ice cube.

  • Page 25: Trouble Shooting

    You may try to solve the following simple problems by yourself. If them cannot be solved, please contact the after-sales department. Occurrence Possible cause/inspection items Operation failure Check whether the appliance is connected to power or whether the plug is in well contact.

  • Page 26: Disposal Of Your Appliance

    6. Disposal of your appliance Correct Disposal of this product: This marking indicates that this product should not be disposed with other house hold wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
