CWE CAPSTAR-100 Instruction Manual

End-tidal co2 analyzer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction Manual
C
AP
End-Tidal CO
Read instructions carefully before operating this device.
 This device is not to be used for Human Life Support applications.
 To avoid possible electrical shock, do not operate this device if is wet or has had liquids spilled onto it.
 Service or calibration procedures should only be performed by qualified personnel familiar with the
electrical hazards of line-powered devices.
S
TAR
Analyzer
2
Ardmore PA 19003 U.S.A.
(610)642-7719
info@cwe-inc.com
©CWE 2023
www.cwe-inc.com
-100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAPSTAR-100 and is the answer not in the manual?

Questions and answers

Related Manuals for CWE CAPSTAR-100

Summary of Contents for CWE CAPSTAR-100

  • Page 1  To avoid possible electrical shock, do not operate this device if is wet or has had liquids spilled onto it.  Service or calibration procedures should only be performed by qualified personnel familiar with the electrical hazards of line-powered devices. Ardmore PA 19003 U.S.A. (610)642-7719 info@cwe-inc.com ©CWE 2023 www.cwe-inc.com...
  • Page 2 STATEMENT OF WARRANTY IF THIS INSTRUMENT FAILS WITHIN A PERIOD OF ONE YEAR FROM THE DATE OF DELIVERY OR INSTALLATION, CWE, INC. WILL, AT ITS OPTION, REPAIR OR REPLACE IT FREE OF CHARGE TO THE PURCHASER. THIS WARRANTY EXCLUDES DAMAGE INCURRED THROUGH ABUSE OR ACCIDENT AND CONSUMABLE ITEMS OR COMPONENTS SUCH AS BATTERIES.

  • Page 3: Table Of Contents

    -100 Instruction Manual TABLE OF CONTENTS 1.0 INTRODUCTION .................... 4 3.0 SETTING UP THE CAPSTAR-100 ..............6 4.0 OPERATION ....................7 4.1 SAMPLE FLOW ..................... 7 4.11 MINIMIZING SAMPLE TUBING VOLUME ..........7 4.12 CONDITIONING THE SAMPLE ..............8 4.2 LCD DISPLAY ....................8 4.3 CALIBRATE FUNCTIONS ................

  • Page 4: Introduction

    -100 Instruction Manual 1.0 INTRODUCTION The CAPSTAR-100 is a high-performance respiratory gas analyzer for the routine monitoring of expired carbon dioxide and respiratory rate. The CO sensor is a temperature-controlled, infrared optical bench, which features fast response, excellent accuracy, and long-term stability. End-tidal CO...
  • Page 5 Serial data output format ....... 9600 baud, 8 data, no parity, 1 stop bit Power adapter (supplied) ................ 5VDC@4A Mains requirements for power adapter......120VAC/220VAC universal Dimensions ............9W x 4H x 9D in. (23 x 10 x 23cm) Weight ....................4 lbs. (1.8kg) © 2023 CWE, Inc.

  • Page 6: Setting Up The Capstar-100

    -100 Instruction Manual 3.0 SETTING UP THE CAPSTAR-100  Place the CAPSTAR-100 control unit in a stable location close to the subject or animal being monitored. When monitoring small animals, it is desirable to locate the unit as close to the animal as possible, to minimize sample tube volume.

  • Page 7: Operation

    SAMPLE INLET endotracheal tube as close to the animal as possible, ALWAYS using a small hydrophobic in-line filter at the CAPSTAR-100 port. Several centimeters of small-bore tubing is SAMPLE INLET acceptable between the sample port and the tracheal connection if the sample rate is kept reasonably high.

  • Page 8: Conditioning The Sample

    The third line shows the alarm low and high settings for ETCO2 (left) and Respiratory Rate (right). The box at the bottom of the screen shows a bar graph of the ETCO reading, updated once per second. This serves as a quick visual indicator of changing CO over time. © 2023 CWE, Inc.

  • Page 9: Calibrate Functions

    -100 Instruction Manual 4.3 CALIBRATE FUNCTIONS Calibrating the CAPSTAR-100 is straightforward. Because of the inherent linearity of the sensor, only a two-point calibration is required. For CO calibration, a 5% CO in air calibration mixture is ideal. Zero: With the instrument fully warmed-up, and the...

  • Page 10: Miscellaneous Functions

    2, 4, 6, 8, 10, 12, 14, or 16 breaths LCD Brightness: The user can set the brightness of the backlight on the lCD graphic display. The range of setting is: 100 (dim) to 255 (bright) © 2023 CWE, Inc.

  • Page 11: Co2 Output Signal

    Serial Format setting of the functions. The serial protocol is as follows: 9600,N,8,1 If your computer does not have a standard serial port, a USB-Serial Adapter is available that effectively creates a virtual serial COM port (see Ordering Information). © 2023 CWE, Inc.

  • Page 12: Co2 Calibration Procedure

    -100 Instruction Manual 5.0 CO2 CALIBRATION PROCEDURE When calibrating the Capstar-100 it is important to avoid applying pressure to the SAMPLE INLET port. The diagram below illustrates a simple means of coupling a calibration gas source while calibrating. Note that the gas just flows around the distal end of the sample tubing, allowing the instrument to draw in the gas at its own flow rate.

  • Page 13: Maintenance

    NEVER OPERATE THE INSTRUMENT WITHOUT THIS IN- LINE HYDROPHOBIC FILTER. THIS FILTER PREVENTS LIQUIDS AND OTHER CONTAMINENTS FROM ENTERING THE SAMPLE CELLS. 7.0 ORDERING INFORMATION Accessories and replacement parts for the CAPSTAR-100 are available from CWE, Inc. PART NO. DESCRIPTION...

  • Page 14: Typical Sample Connection Diagram

    -100 Instruction Manual Typical Sample Connection Diagram © 2023 CWE, Inc.
