ATN IR940 User Manual

A L I G N I N G T H E I R B E A M
In order to Align the IR940 illuminator to your scope. After the IR940 is
assembled into the mount. Place it on the X-Sight 5 side accessory rail or on
your rifl es accessory Picatinny rail. Once mounted securely, slightly loosen
the two screws on top of the mounting ring.
While looking through the X-Sight 5 at night with night mode activated.
Move the IR940 around in the mount until you see the IR light covering your
entire fi eld of view in the X-Sight 5 view fi nder. Once you have adjusted your
IR light to be aligned with your X-Sight 5 FOV, gently tighten the two screws
on top of the mounting ring with an Allen wrench.
M A I N T E N A N C E
To prevent wear and retain water-resistance it is a good idea to lubricate
the threads and o-rings if they become dry.
T R O U B L E S H O O T I N G
Light Doesn't Turn On
• Check that the battery tube is fully threaded, as well as the tail cap.
Light Dimming
• If the output is declining rapidly unexpectedly, please try another fully
charged battery and/or charge your battery and retry.
• If output is not fi xed with other charged batteries, please contact ATN for
further assistance.
For customer service and technical support, please contact
American Technologies Network Corp.
2400 NW 95 Ave, Doral, FL 33172
phone: 800-910-2862, 650-989-5100
e-mail: service@atncorp.com
www.atncorp.com
©2023 ATN Corporation
ATN IR940
LONG RANGE INFRA-RED ILLUMINATOR
USER'S GUIDE (IR940) REVISION 1 – FEBRUARY 2023
