Forest garden ODP64FP Quick Start Manual

This article contains biocidal products to give protection against
wood destroying insects & wood rotting fungi. Contents may vary.
May contain : Basic copper carbonate (Copper (II) carbonate –
Copper (II) hydroxide (1:1), Cupric oxide, Copper hydroxide
carbonate, oxyethyl, ammoniumpropionate, Copper HDO,
Propiconazole, Tebuconazole, Boric acid, Benzalkonium chloride.
Wear gloves when handling freshly treated wood. Avoid breathing
dust when cutting treated or untreated wood. Dispose of off-cuts
responsibly – do not burn.

Tools Required

Not Supplied
Hammer
Drill/Pozi Drive
Sharp Knife
Screwdriver
Tape Measure
Spirit Level
Fixing Pack Code = ODP64FP
Not to Scale
a d
a a
Hasp And Staple Qty 1
a e
b
Z' Bracket Qty 2
c
f
Flush Hinge Qty 2
Forest Garden Ltd. | Unit 288 | Oak Drive | Hartlebury Trading Estate | Hartlebury | Worcestershire | DY10 4JB
Pre-drill
for each screw
used.
Item
1
2
3
4
5
6
g 7
8
9
10
11
12
13
14
h
15
16
17
18
Please check all parts prior to assembly.
Important:
I
Assembly of this product requires a minimum of
two adults.
Attention:
For Domestic Use Only.
n
Must be built on a
n
Regularly check that all fixing are tight and secure.
n
Regularly check the felt for damage.
n
6' x 4' PENT SHED
ODP64FP
Part Code
ODP6BK OLAP PENT SHED 6' BACK SECTION
ODP6FR OVERLAP PENT SHED 6' FRONT
ODP4LHS
ODP4RHS
SDRDT
SFL46
44161717DTR CORNER STRIP 44x16x1717mm DTREAT
44161828DTR CORNER STRIP 44x16x1828mm DTREAT
37281791
37281699
179112808
PCWIN1 POLYCARB WINDOW 671x555mm
20121710PDT STRIP 20x12x1710mm DTREAT
28120675PDT STRIP 28x12x675mm PAR DTREAT
59121280PDT BARGE BOARD 59x12x1280mm PAR DTREAT
59121815PDT BARGE BOARD 59x12x1815mm PAR DTREAT
84996 PLASTIC "L" STRIP 12x12x675mm BROWN
85052
This building
storage and transit. We recommend that you treat your new building as soon
as possible after assembly using a wood preservative treatment. Apply in
accordance with the manufacturers instructions.
Please keep all plastic bags and small parts away from children.
n
The roof of this product is not a load bearing structure.
n
Timber is a natural material and will shrink and swell as a result of
n
varying moisture content.
Assembly of damaged parts may be deemed to be acceptance and this may
affect the remedies you are entitled to.
solid and level base.
If the product is not constructed in accordance with the instructions, or is
altered in anyway (e.g. painted), the manufacturer cannot be held liable for
any resulting damage.

PARTS LIST

Part Description
OLAP PENT SHED 4' LH SIDE
OLAP PENT SHED 4' RH SIDE
SINGLE SHED DOOR DTREAT
4x6 SHED FLOOR
BATTEN 37x28x1791mm
BATTEN 37x28x1699mm
OSB 1791x1280x8mm
BLACK FELT 4 x 1 METRE
is pre-treated with a factory base coat for protection during
Quantity
1
1
1
1
1
1
2
2
2
1
1
1
1
1
2
1
2
1
Issue 0317
