Forest garden HW0079 Quick Start Manual

ULTIMA DECK Kit
8' x 8' & 16' x 8'

IMPORTANT, RETAIN FOR FUTURE REFERENCE;

READ CAREFULLY
Check all parts prior to assembly
- The timber in this product is pressure treated to
ensure longevity and protection against rot. This may
leave colour variations, but these will even out as the
moisture content stabilises.
- Timber is a natural material. It will shrink and swell as
a result of varying moisture content.
- Please keep all plastic bags and small parts away
from children
- This product must be built on a solid level base.
Technical Help line: 0333 7777 089 8.30 am and 5.00
pm Monday to Friday.
In line with your statutory rights, please check all parts
prior to assembly, as assembly of damaged parts may
be deemed to be acceptance and this may affect the
remedies you are entitled to. If the product is not
Fixing Pack (HW0079)
Not to Scale
4.0 x 60mm SCREW
QTY 24
3.0 x 25mm SCREW
QTY 40
M10 x 180mm Coach Bolt

REQUIRED TOOLS :

(NOT SUPPLIED)
POZI DRIVE SCREWDRIVER
SPIRIT LEVEL

Parts:

Please note the Hw0079 is a
supplementry fixing pack for
the installation of the Pergola.
The decking requires the
PAT88FP
QTY 10
U'bracket
QTY2
TAPE MEASURE
HAMMER
Assembly of this
deck requires a
minimum of two
DRILL
SAW
A
UCBCBI
QTY 8
Important :
adults.
B
Profile
HR2966BI
QTY 2
C
URCB10BI
QTY 7
D
DR7028BI
QTY 4
E G
BAL900PK10
QTY 4
USU84BI
QTY 4
F
E
Profile
PATDB1BI
QTY 28
H
75750120PTR
QTY 4
ISSUE 0116
